97 / 220
Electric
Power Tools
makita.ca
95
Unique Plunge Action For Specialized Cuts
• Depth Stopper enables splinter-free cutting
• PrecisionBevelCut featuremaintainsexactbladeposition forquickandeasybevelcutting
withoutcompensatingadjustments
• Soft Start feature gradually increases speed to eliminate start up shock
• Constant Speed Control maintains constant speed under heavy load
• Overload Protection prevents motor burnout due to current overload
• Variable Speed Dial adjusts cutting speed based on materials or application
• Close to Wall Cut of just 11/16˝
SPECIFICATIONS
Blade Diameter
6-1/2" (165 mm)
Arbor
13/16" (20 mm)
Maximum Cutting Capacity:
0°
2-3/16" (56 mm)
45°
1-9/16" (39 mm)
48°
1-1/2" (38 mm)
No Load Speed
2,200 - 6,400 RPM
AMPS (120V)
12.0 A
Overall Length
13-3/8" (341 mm)
Net Weight
9.7 lbs (4.4 kg)
55" Guide Rail
(139.7 cm)
STANDARD EQUIPMENT INCLUDES:
6-1/2" C.T. Blade 48T (A-99932),
Hex Wrench 5 (783203-8),
Front Cuff 24 (195546-0),
55˝ (139.7 cm) Guide Rail (194368-5)
SP6000X1
STANDARD EQUIPMENT INCLUDES:
6-1/2" C.T. Blade 48T (A-99932),
Hex Wrench 5 (783203-8),
Front Cuff 24 (195546-0),
118˝ (299.7 cm) Guide Rail (194367-7)
SP6000X2
+
STANDARD EQUIPMENT INCLUDES:
6-1/2" C.T. Blade 48T (A-99932), Hex Wrench 5 (783203-8),
Front Cuff 24 (195546-0)
SP6000
+
+
SP6000, SP6000X1, SP6000X2
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
Two 5" Diamond Wheels, D-Style Front Handle (417665-5), Lock Nut Wrench 35 (782407-9), Hex Wrench 6 (783204-6),
Interlocking Case (197213-3)
Cuts Two Parallel Lines In Concrete Or Masonry To Enable Recessing Of
Conduit Pipe, Wiring And More!
• "SJS" (Super-Joint System) prevents kickback during wheel lock-up for optimal tool and operator protection
• Soft start feature gradually increases speed to eliminate start up shock
• Constant speed control maintains constant speed under heavy load
• Electronic current limiter prevents motor burnout due to overloading
• 360° rotatable dust extraction port
• Adjustable depth scale enables fast and accurate depth setting
"SJS" Technology,
Electronic Current
Limiter, Soft Start,
Constant Speed
Control
5" Wall Chaser
SPECIFICATIONS
Blade Diameter
5" (125 mm)
Arbor
7/8" (22.23 mm)
Blade Thickness
5/64" (2.1 mm)
Cutting Depth 0 - 1-3/16" (0 - 30 mm)
Cutting Width
Every 1/8" from 1/8" to 1-3/16"
(Every 3 mm from 6 to 30 mm)
No Load Speed
10,000 RPM
AMPS (120V)
12.0 A
Overall Length
13-3/4" (350 mm)
Net Weight
9.9 lbs (4.5 kg)
SG1251J
118" Guide Rail
(299.7 cm)
4101RH
Ideal For Wet Cutting Of Tile, Masonry,
Concrete And More
• Special Cover Design prevents water from entering motor housing
• Equipped with a Ground Fault Circuit
Interrupter (GFCI) plug for
operator safety
• Lock-On Button for
easy continuous
operation
• Bevel Capacity of 45°
• Includes 15 ft. of
Tubing, Water
Pressure Regulator
and Water Valve
5" Masonry Saw
SPECIFICATIONS
Blade Diameter
5" (125 mm)
Arbor
3/4" (20 mm)
Maximum Cutting Capacities:
0°
1-5/8" (41.5 mm)
45°
1" (26 mm)
No Load Speed
13,800 RPM
AMPS (120V)
7.9 A
Overall Length
9-1/4" (236 mm)
Net Weight
6.5 lbs (3.0 kg)
STANDARD EQUIPMENT INCLUDES:
5" ContinuousRimDiamondWheel (A-90934),HexWrench 5 (783203-8),Wrench 22 (781011-1),
WrenchHolder 5.6 (410047-0),WaterSupplyPlug (165263-6),PressureRegulator (165264-4)
4100NH2ZX1
Dry Cutting Masonry Saw For Stone, Masonry,
Tile, Concrete And More
• Wide Blade Case enables use of Curved Diamond Wheel
• Heavy Duty Aluminum Gear Housing for increased durability
• 14 ga Steel Baseplate ensures accuracy and durability
• Leading Edge of Baseplate indicates precise line of cut
• Dust Proof Switch and Labyrinth
Construction prevents
contamination of motor
• Flat Motor Housing
allows tool to stand
upright when
changing blades
• Bevel Capacity
of 45°
4-3/8" Masonry Saw
SPECIFICATIONS
Blade Diameter
5" (125 mm)
Arbor
3/4" (20 mm)
Maximum Cutting Capacities:
0°
1-1/4" (32.5 mm)
45°
7/8" (21.5 mm)
No Load Speed
12,200 RPM
AMPS (120V)
10.0 A
Overall Length
9-3/8" (238 mm)
Net Weight
6.6 lbs (3.0 kg)
STANDARD EQUIPMENT INCLUDES:
4"Turbo Rim Diamond Blade (A-94546), 4-3/8" Curved Diamond Blade (D-36968),
Wrench 22 (781041-2), Hex. Wrench 5 (783217-7)
4100NH3ZX
Dry Cutting Masonry Saw For Stone, Masonry,
Tile, Concrete And More
• Wide blade case enables use of curved diamond wheels
• Heavy duty aluminum gear housing for increased durability
• 14 ga steel baseplate ensures accuracy and durability
• Leading edge of baseplate indicates precise line of cut
• Dust proof switch and
labyrinth construction
prevents contamination
of motor
• Flat motor housing
allows tool to
stand upright when
changing blades
4-3/8" Masonry Saw
SPECIFICATIONS
Blade Diameter
4-3/8" (110 mm)
Arbor
3/4" (20 mm)
Maximum Cutting Capacity:
0°
1-1/4" (32 mm)
No Load Speed
13,000 RPM
Amps (120V)
9.5 A
Overall Length
8-15/16" (227 mm)
Net Weight
6.4 lbs (2.9 kg)
STANDARD EQUIPMENT INCLUDES:
4"Turbo Rim Diamond Blade (A-94546), Wrench 22 (781041-2),
Hex. Wrench 5 (783217-7)
Blade Left,
Cutting
Capacity
of 1-1/4"
(32.5 mm)
6-1/2
"
Plunge Cut Circular Saws
STANDARD EQUIPMENT INCLUDES:
5" Diamond Blade (A-94568), Dust BagAssembly (126738-0), Wrench 22 (781041-2), Hex Wrench 5 (783203-8)
Dry Cutting Masonry Saw for Stone, Masonry, Tile, Concrete and More!
• Wide Blade Case enables use of Curved Diamond Wheel
• 360° rotatable dust collecting port
• Works with Makita guide rails when using the guide rail adapter
• Dust cover prevents the spread of dust
• Dust Proof Switch and Labyrinth Construction prevents contamination of motor
• Steel baseplate ensures accuracy and durability
5" Masonry Saw
SPECIFICATIONS
Blade Diameter
5" (125 mm)
Arbor
13/16" (20 mm)
Maximum Cutting Capacities:
0°
1-9/16" (40 mm)
No Load Speed
12,200 RPM
Amps (120V)
10.0 A
Overall Length
9-1/8" (231 mm)
Net Weight
6.6 lbs (3.0 kg)
4100KB
Blade Left,
Cutting
Capacity
of 1-1/4"
(32.5 mm)
Blade Left,
Cutting Capacity of 1-9/16" (40 mm)
Cutting Capacity
of 2-3/16"
(56 mm)
Blade Left,
Cutting
Capacity of
1-1/4" (32.5 mm)
