100 / 220
SAWS
makita.ca
98
STANDARD EQUIPMENT INCLUDES:
JR3070CT:
Blade Set (194068-7), Steel Carrying Case (154609-1)
JR3070CTZ:
Blade Set (194068-7), Steel Carrying Case (154609-1)
Anti-Vibration Technology,
Variable Speed
Reciprocating Saws
SPECIFICATIONS
Length of Stroke
1-1/4" (32 mm)
Strokes Per Minute
0 - 2,800 SPM
AMPS (120 V)
15.0 A
Overall Length
19-1/8" (485 mm)
Net Weight
10.1 lbs (4.6 kg)
MASONRYRECIPROCATINGSAWBLADES
NoGas Fumes
*
•
LessNoise
*
•
LessDust
*
•
Cuts Square Corners
*
Description
• Ideal for Aerated Concrete, Concrete Block & Brick,
Low Aggregate Concrete & Masonry and Abrasive Materials
• Ideal alternative to gas saws in sensitive environments
• Solid Blade Construction due to 2" (12" Blade) or
1" (9-1/2" Blade) Height and 1/16" (0.0625") Blade Thickness
• Universal Shank with a long clearance compatible with
all reciprocating saws
• Anti-Kick Back Design for less tear and increased operator safety
• High Quality, Extra Large Carbide Teeth for long operational life
• 2 Carbide TPI
• Recommended for use with Makita Reciprocating Saw
models JR3060T and JR3070CT
*
compared to gas saws
Part No. Material Length TPI Width Thickness Type
Application
B-10394
Masonry
12"
2
2"
.0625" Straight
Back
Aerated Concrete,
Concrete
Block & Brick,
Low Aggregate
Concrete & Masonry,
Abrasive Materials
B-12809
9-1/2"
1"
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
JR3050TY:
6˝ 6TPI Reciprocating Saw Blade (1 Ea. 723054-A-5)
JR3050T:
Blade Set (194068-7), Plastic Carrying Case (821621-3)
• Variable Speed Trigger adjusts cutting speed based on materials or application
• Tool-Less Blade Change System enables fast, one-handed blade changes
• Tool-Less Shoe Adjustment allows operator to quickly adjust shoe position
• Blade can be inverted for flush cutting applications
• Accepts standard Tang Shank blades
• Ergonomic Soft Rubber Grip design for vibration absorption
and comfortable operation
Reciprocating Saws
SPECIFICATIONS
Length of Stroke
1-1/8" (28 mm)
Strokes Per Minute
0 - 2,800 SPM
AMPS (120V)
11.0 A
Overall Length
17-3/4" (452 mm)
Net Weight
7.3 lbs (3.3 kg)
JR3050TY JR3050T
RECIPROCATINGSAWBLADES
Tooth Configurations
Description
Progressive
Ideal for Fast and Clean cutting. Progressive tooth blades move from high to low
TPI and are ideal for cutting a variety of materials or thicknesses with a single blade.
Tungsten Carbide Grit
This is an abrasive blade intended for use with brick, tile, marble, stone, chalkboard, cast iron, melamine, veneer and fiberglass
Types
Description
Straight
These blades have a straight back to maximize stability during cutting
Taper
Tapered Blades reduce in height closer to the tip of the blade in order to eliminate friction and increase cutting speed.
Tapered blades are also ideal for starting cuts in inaccessible locations.
Scroll
Scroll blades are narrow to enable quick turning during cutting for detailed applications
Standard Tang Shank
Length, TPI and Materials listed on each
blade for quick reference
Tooth Design enables aggressive but clean cutting
7/8" Width increases blade life
0.062" Thickness resists bending
BIM or HCS Construction
Cobalt content maximizes durability and wear of
blades in high impact applications
B-10394
B-12809
STANDARD EQUIPMENT INCLUDES:
Blade Set (194068-7), Plastic Carrying Case (821621-3)
• 3 Orbital Settings enable operator to obtain a more aggressive cut
• Variable Speed Trigger adjusts cutting speed based on materials or application
• Torque Limiter prevents damage to operator and tool if blade jams
• Tool-Less Blade Change System enables fast, one-handed blade changes
• Tool-Less Shoe Adjustment allows operator to quickly adjust shoe position
• Blade can be inverted for flush cutting applications
• Accepts standard Tang Shank blades
• Ergonomic Soft Rubber Grip design for vibration
absorption and comfortable operation
Variable Speed,
Lock-On Button
Reciprocating Saw
SPECIFICATIONS
Length of Stroke
1-1/4" (32 mm)
Strokes Per Minute
0 - 2,800 SPM
AMPS (120 V)
12.0 A
Overall Length
19-1/8" (485 mm)
Net Weight
9.7 lbs (4.4 kg)
JR3060T
Variable Speed,
Lock-On Button
With Lock-On
Button
JR3070CT
No Lock-On
Button
JR3070CTZ
Features Anti-Vibration
Technology (AVT)
• 3 Orbital Settings enable operator to obtain a
more aggressive cut
• Variable Speed Dial adjusts cutting speed
based on materials or application
• Torque Limiter prevents damage to operator
and tool if blade jams
• Tool-Less Blade Change System enables fast,
one-handed blade changes
• Tool-Less Shoe Adjustment allows operator
to quickly adjust shoe position
• Blade can be inverted for
flush cutting applications
