STANDARD EQUIPMENT INCLUDES:
DepthAdjustment Knob (158980-5), 1/4˝ Collet Sleeve (763803-0), 1/2˝ Collet Cone (763622-4), Wrench 24 (781030-7)
• Electronic Speed Control maintains constant speed under heavy load
• Linear Bearing Slide Mechanism allows extremely smooth plunge action
• Labyrinth Retainers and Fan prevent contamination of motor
• Plunge Depth can be adjusted from the bottom of the router when mounted in a router table
• Trigger Switch with Lock-On / Off Button located on handle for operator convenience
• 3 Stage Depth Adjustments ideal for use when performing deep or repetitive cutting operations
• Four Raised Ribs on top of Motor Housing provide a stable platform during bit changes
• Dual LED Job Lights with Afterglow
• Sub-Base accepts industry standard template guides
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
• Can be used with 55˝ (194368-5) or 118˝ (194367-7) Guide Rails and Router Guide Rail Adapter (194579-2)
for precision routing applications
Electronic Speed Control, Electric Brake,
Variable Speed
3-1/2 H.P. Plunge Router
SPECIFICATIONS
Collet Capacity
1/2˝ (12.7 mm)
Plunge Capacity
2-3/4˝ (70 mm)
No Load Speed
9,000 - 22,000 RPM
AMPS (120V)
15.0 A
Overall Height
12-1/4˝ (312 mm)
Net Weight
13.4 lbs. (6.1 kg)
RP2301FC
STANDARD EQUIPMENT INCLUDES:
DepthAdjustment Knob (158980-5), 1/4˝ Collet Sleeve (763803-0), 1/2˝ Collet Cone (763622-4), Wrench 24 (781030-7)
• Linear Bearing Slide Mechanism allows extremely smooth plunge action
• Larger Ball Bearings on Armature enhance durability of tool
• Labyrinth Retainers and Fan prevent contamination of motor
• Plunge Depth can be adjusted from the bottom of the router when mounted in a router table
• Trigger Switch with Lock-On / Off Button located on handle for operator convenience
• 3 Stage Depth Adjustments ideal for use when performing deep or repetitive cutting operations
• Four Raised Ribs on top of Motor Housing provide a stable platform during bit changes
• Dual LED Job Lights with Afterglow
• Sub-Base accepts industry standard template guides
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
• Can be used with 55˝ (194368-5) or 118˝ (194367-7) Guide Rails and Router Guide Rail Adapter (194579-2)
for precision routing applications
Electric Brake
3-1/2 H.P. Plunge Router
SPECIFICATIONS
Collet Capacity
1/2˝ (12.7 mm)
Plunge Capacity
2-3/4˝ (70 mm)
No Load Speed
22,000 RPM
AMPS (120V)
15.0 A
Overall Height
12-1/4˝ (312 mm)
Net Weight
13.2 lbs. (6.0 kg)
RP1801F
• Electronic Speed Control maintains constant speed under heavy load
• Variable Speed Dial adjusts motor speed based on materials or application
• Soft Start feature gradually increases speed to eliminate start up shock
• Flat Top Design for increased stability when changing bits
• Industrial Cam-Lock enables fast and easy depth adjustment
and removal of motor
• Sub-Base accepts industry standard template guides
D-Handle Design
Side Handle Design
SPECIFICATIONS
Collet Capacities
1/4˝ & 1/2˝
(6.4 mm & 12.7 mm)
No Load Speed
8,000 - 24,000 RPM
AMPS (120V)
11.0 A
Overall Height
8-3/4˝ (223 mm)
Net Weight
7.3 lbs. (3.3 kg)
STANDARD EQUIPMENT INCLUDES:
1/4˝ Collet Cone (193214-9), 1/2˝ Collet Cone (193215-7), 2 Ea. Wrench 27 (781031-5)
RD1101
STANDARD EQUIPMENT INCLUDES:
1/4˝ Collet Cone (193214-9), 1/2˝ Collet cone (193215-7), 2 Ea. Wrench 27 (781031-5),
Wrench 8 (781213-9)
RF1101
Variable Speed, Constant Speed
Control, Soft Start
RD1101, RF1101
2-1/4 H.P. Routers
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Fixed Base
• Industrial Cam-Lock enables fast and easy depth adjustment and removal of motor
Plunge Base
• 3 Stage Depth Adjustments ideal for use when performing deep or repetative cutting operations
• Convenienty located Plunge Locking Lever for easy engagement during operation
SPECIFICATIONS
Collet Capacities
1/4˝ & 1/2˝
(6.4 mm & 12.7 mm)
Plunge Capacity
2-19/32˝ (66 mm)
No Load Speed
8,000 - 24,000 RPM
Center Hole Diameter
1-3/16˝ (30.5 mm)
Base Diameter
5-3/4˝ (146 mm)
AMPS (120V)
11.0 A
Overall Height:
Fixed
8-3/4˝ (223 mm)
Plunge
11-1/2˝ (292 mm)
Net Weight
7.3 lbs. (3.3 kg)
RF1101KIT
2-1/4 H.P. Router Kit
STANDARD EQUIPMENT INCLUDES:
2-1/4H.P.RouterMotorRF1101,PlungeBase(193457-3),1/4˝Collet(193214-9),1/2˝Collet(193215-7),DustNozzle(P-80009),StraightGuide(193073-1),
Base Plate (193155-9), 2 Ea. Wrench 27 (781031-5), Wrench 8 (781213-9), Hex Wrench 4 (783202-0), Plastic Carrying Case (125153-5)
Electronic
Speed Control,
Variable Speed,
Soft Start
