STANDARD EQUIPMENT INCLUDES:

Wheel Kit (HY00000212)

Advanced High Pressure Pneumatic Technology

• Low noise level - Just 90 dB

• Oil-less design requires no day to day maintenance

• Features dual high pressure and dual 90-130 PSI fittings enables use of multiple pneumatic tools

• Unique High Pressure fittings eliminates confustion with 90-130 PSI fittings

• Internal breaker and reset function eliminates overload of main electrical source

High Pressure Air Compressor

SPECIFICATIONS

Maximum Pressure:

High Pressure

375 PSI

Regular Pressure

130 PSI

Performance:

(90 PSI) 3.6 CFM

(300 PSI) 2.7 CFM

Pump

Oil-less

Output Power

1,500 W

Motor

2.5 hp

Tank Size

1.6 gal. (6.2 L)

Dimensions (L x W x H)

18-3/4˝ x 14-3/4˝ x 20˝

(476 mm x 375 mm x 507 mm)

Net Weight

79.4 lbs (36.0 kg)

AC310HX

STANDARD EQUIPMENT INCLUDES:

Safety Glasses (192517-8), Hex Wrench 4 (783202-0), Oil Supply (194381-3), Bit (194708-7), Plastic Carrying Case (824864-6)

Compact And Lightweight Design For Easy Handling

• 2 mode - Sequential Fire / Bump Fire or Lock-off

• Low noise air exhaust creates optimum operation for residential jobsites

• Easy to use driving depth adjustment

• Convenient Adjustable Belt Hook

Drives Coil Type Drywall Screws Into

Wood / Metal Studs

1-5/8˝ High Pressure Autofeed Coil Screwdriver

SPECIFICATIONS

Screw Size 1˝ - 1-5/8˝ (25 mm - 41 mm)

Diameter: Steel

1/8˝ (3.5 mm)

Wood

5/32˝ (3.8 mm)

Magazine Capacity

100 Screws

Operating Pressure

260 – 320 PSI

Dimensions (L x W x H)

11-5/8˝ x 4-9/16˝ x 12˝

(296 mm x 116 mm x 305 mm)

Net Weight

4.2 lbs (1.9 kg)

AR410HR

HIGH PRESSURE PNEUMATIC ACCESSORIES

Description

Contents

Application

Part No.

Middle Joint

Repair Kit

Hose Joint (1 each), Heat Shrink Tubing (1 each),

Nylon Sleeves (2 each)

Repairing leaks in High Pressure Hoses

A-46676

Female Hose Joint

Female Quick Connect Coupler (1 each),

Hose Protector (1 each), Nylon Sleeve (1 each)

Replacement Female Hose Fittings

A-46470

Male Hose Joint

Male Quick Connect Coupler (1 each),

Hose Protector (1 each), Nylon Sleeve (1 each)

Replacement Male Hose Fittings

A-46486

Nylon Sleeve

Nylon Sleeve (1 each)

Replacement Nylon Sleeves

KN00008978

Female Quick Connect Coupler (High Pressure)

AC310H (High Pressure)

HY00000351

Female Quick Connect Coupler (90-135 PSI)

AC310H (Regular Pressure)

HY00000337

HIGH PRESSURE COLLATED AUTOFEED SCREWS

Length Shank

Diameter

Shank /

Thread

Head

Diameter

Notes

Application Box Qty.

For Model

Part No.

0.139"

Fine

0.322" PH2 Recess /

Ultra-Coated

Drywall to

Steel

2,000

(20 Strips

of 100)

AR410HR

F-32830

1-1/8"

F-32843

1-5/8"

F-32856

0.146"

Coarse

Drywall to

Wood

F-32869

1-1/8"

F-32872

1-1/4"

F-32885

1-5/8"

F-32898

HIGH PRESSURE PNEUMATIC HOSE

Length

Inner Diameter (I.D.)

Maximum Operating Pressure Part No.

25' (7.5 m)

1/4" (6 mm)

470 PSI (3.25 Mpa)

B-80036

50' (15 m)

B-80014

100' (30 m)

B-80020

HIGH PRESSURE PNEUMATIC

MAINTENANCE ACCESSORIES

Description

For Model(s)

Part No.

Air Leak

Repair Set

AN450H, AN610H

194735-4

AN250HC, AN911H

194737-0

AR410HR

194738-8

Pneumatic

Oil 30 mL

All Makita High

Pressure Tools

194381-3
