151 / 180
Air blower feature cleans material
of dust and debris
AT638A
Electric
Power Tools
makita.ca151
When
QUALITY & SERVICE
Counts – Choose Makita
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
Oil Supply (181434-7), Safety Glasses (A0908-0171), Wrench (A0913-0011)
1˝ - 2˝ (1˝ Width) 16-Gauge Staples
• 360° exhaust system directs exhaust away from operator
• Dry fire prevention prolongs tool life
• Rubber grip for comfortable handling
• Inlet Filter prevent contamination due to dust or debris
• Quick Release nose enables easy clearing of jammed nails
1˝ Crown Stapler
SPECIFICATIONS
Operating Air Pressure 65 - 120 PSIG
Staple Size: (L x W)
1˝ - 2˝ (1˝ Width)
Nail Type
16ga Crown Staples
Magazine Capacity
140
Dimensions (L x W x H )
14-1/2˝ x 3˝ x 10-1/4˝
(370 mm x 76 mm x 260 mm)
Net Weight
4.9 lbs (2.2 kg)
AT2550A
STANDARD EQUIPMENT INCLUDES:
Oil Supply (181434-7), Safety Glasses (A0908-0171), Wrench (A0913-0011)
1˝ - 2˝ (7/16˝ Width) 16-Gauge Staples
• 360° exhaust system directs exhaust away from operator
• Dry fire prevention prolongs tool life
• Rubber grip for comfortable handling
• Inlet Filter prevent contamination due to dust or debris
• Quick Release nose enables easy clearing of jammed nails
7/16˝ Crown Stapler
SPECIFICATIONS
Operating Air Pressure 65 - 120 PSIG
Staple Size: (L x W)
1˝ - 2˝ (7/16˝ Width)
Nail Type
16ga Crown Staples
Magazine Capacity
140
Dimensions (L x W x H)
14-1/2˝ x 3-7/16˝ x 11-3/8˝
(370 mm x 87 mm x 290 mm)
Net Weight
4.0 lbs (1.8 kg)
AT1150A
STANDARD EQUIPMENT INCLUDES:
Oil Supply (181434-7), Safety Goggles (195246-2), NoseAdapter (HY00000378), Plastic Carrying Case (HY00000090)
Features Slim Contact Tip Design For Precise Woodworking
Fastening Applications
• Slim contact tip design enables precise fastening in wood trim, crown moulding, baseboard, casing,
cabinetry and other woodworking applications!
• 360° exhaust system directs exhaust air away from operator
• Quick release noise enables fast and easy clearing of jammed nails
• Quick release, side loading magazine holds up to 100 18-gauge brad nails
• Dual windows enable fast identification of remaining nail capacity
• Convenient, adjustable belt hook for operator convenience
2˝ Brad Nailer
SPECIFICATIONS
Operating Air Pressure 60 - 115 PSIG
Nail Size (18 ga)
5/8˝ - 2˝ (15 - 50 mm)
Nail Type
18 ga Brad Nails
Magazine Capacity
100
Dimensions (L x W x H)
10-1/4˝ x 2-1/2˝ x 9-3/8˝
(260 mm x 64 mm x 237 mm)
Net Weight
3.0 lbs (1.4 kg)
AF505N
STANDARD EQUIPMENT INCLUDES:
Two NoseAdapter (HY00000378), Oil Supply, Plastic Carrying Case, Safety Goggles
18-Gauge Narrow Crown Stapler
• 2 mode - sequential & bump fire
• 360° exhaust system directs exhaust away from operator
• Air blower feature cleans material of dust and debris
• Toolless depth adjustment for quick and easy adjustment
• Quick release toolless nose enables easy clearing of jammed nails
• Contact arm design prevents accidental engagement of trigger for maximum operator safety
• High visibility slim nose tip enables precise positioning of nails
1/4˝ Crown Stapler
SPECIFICATIONS
Operating Air Pressure 70 - 120 PSIG
Staple Size (18 ga)
1/2˝ - 1-1/2˝ (13- 38 mm)
Magazine Capacity
100
Dimensions ( L x W x H)
9˝ x 2-15/16˝ x 9-7/8˝
(230 mm x 75 mm x 251 mm)
Net Weight
2.7 lbs (1.2 kg)
AT638A
STANDARD EQUIPMENT INCLUDES:
Two NoseAdapter (HY00000561), Hex. Wrench 3 (HY00000395), Oil Supply, Plastic Carrying Case, Safety Goggles
23-Gauge Pin Nailer
• Air blower feature cleans material of dust and debris
• Double trigger design prevents accidental engagement of trigger
for maximum operator safety
• High visibility slim nose tip enables precise positioning of nails
• Anti-dry fire mechanism prevents added wear on drive pin
• Nail view window enables fast identification of remaining nail capacity
• Protective rubber bumpers guard housing against wear and damage
1-3/8˝ Pin Nailer
SPECIFICATIONS
Operating Air Pressure 65 - 100 PSIG
Nail Size (23 ga) 5/8˝ - 1-3/8˝ (15 - 35 mm)
Nail Type
23 ga Pin Nails
Magazine Capacity
130
Dimensions (L x W x H)
8-3/16˝ x 2-5/8˝ x 7-1/2˝
(208 mm x 66 mm x 191 mm)
Net Weight
2.0 lbs (0.9 kg)
AF353
