STANDARD EQUIPMENT INCLUDES:
16˝ Cutting Disk For Stone (20 mm) (966 161 020),
Tool Kit (957 004 006), WaterAttachment Kit (394 365 630)
16˝ / 5.6 hp 2 Stroke Power Cutter (20 mm Arbor)
SPECIFICATIONS
Displacement 4.9 (81 cc)
Maximum Power 4.2 kW (5.6 hp)
Fuel / Oil Mixture 50:1
Fuel Tank Capacity 1/3 Gal (1.1 L)
No Load Speed (Engine) 9,350 RPM
Max. Spindle Speed 3,820 RPM
Arbor 20 mm
Max. Cutting Depth 5-3/4˝ (147 mm)
Dry Weight 23.4 lbs (10.6 kg)
EK8100
Required to use 2 Cycle Synthetic Oil
(Part No. T-00739C)
16˝ Cutting Wheel
Compliant with CARB Tier 3, EPA Phase 2
and EU Stage 2 Regulations
• NEW Scavenging Losses Rejection (SLR) Muffler
recycles exhaust unburnt gas emissions for increased
operational efficiency and cleaner emissions
• Advanced 5 Stage Air Filtration System for cleaner
operation and enhanced operational life
• Large Air Intake for maximum engine cooling
• Reversible Cutting Arm enables cutting disc to be
side or centre mounted for optimal operational
versatility in a variety of applications
• Electronic Ignition with Rev Limiter
• Always use with 2 Cycle Synthetic Oil
Top Mount Decompression
Valve Reduces Required Start
Up Force By 70%
10L (2.5 Gal)
Pressurized
Water Tank
Sold Separately
Makita offers a wide variety of ACCESSORIES!
SYNTHETIC 2-CYCLE ENGINE OIL
WITH FUEL STABILIZER
Required for all 2 Stroke Makita Power Cutters
For 3.8 L
1 Gallon Mix
For 9.5 L
2.5 Gallon Mix
(T-00745C) hp synthetic 2 Stroke Oil
For distributor: (T-00745-48) (48 Bottles / Case)
(T-00739C) hp synthetic 2 Stroke Oil
For distributor: ( T-00739C-48) (48 Bottles / Case)
T-00745C
T-00739C
2 Stroke Power Cutters
EK6101
STANDARD EQUIPMENT INCLUDES:
EK7301HD:14˝ Cutting Disk For Stone 1˝ (966 144 120),
Tool Kit (957 004 006), WaterAttachment Kit (394 365 630)
EK7301: 14˝ Cutting Disk For Stone (20 mm) (966 141 120),
Tool Kit (957 004 006), WaterAttachment Kit (394 365 630)
14˝ / 5.1 hp 2 Stroke Power Cutters
SPECIFICATIONS
Displacement 4.5 (73 cc)
Maximum Power 3.8 kW (5.1 hp)
Fuel / Oil Mixture 50:1
Fuel Tank Capacity 1/3 Gal (1.1 L)
No Load Speed (Engine) 9,400 RPM
Max. Spindle Speed 4,300 RPM
Arbor: EK7301HD1˝ (25.4 mm) / EK7301 (20 mm)
Max. Cutting Depth 4-13/16˝ (122 mm)
Dry Weight 22.5 lbs (10.2 kg)
EK7301HD (1˝ Arbor)
Required to use 2 Cycle Synthetic Oil
(Part No. T-00739C)
14˝ Cutting Wheel
Compliant with CARB Tier 3, EPA Phase 2
and EU Stage 2 Regulations
• NEW Scavenging Losses Rejection (SLR) Muffler
recycles exhaust unburnt gas emissions for increased
operational efficiency and cleaner emissions
• Advanced 5 Stage Air Filtration System for cleaner
operation and enhanced operational life
• Reversible Cutting Arm enables cutting disc to be
side or centre mounted for optimal operational
versatility in a variety of applications
• Electronic Ignition with rev limiter
• Always use with 2 Cycle Synthetic Oil
Top Mount Decompression
Valve Reduces Required Start
Up Force By 70%
EK7301 (20 mm Arbor)
STANDARD EQUIPMENT INCLUDES:
14˝ Cutting Disk For Stone (966 141 120),Tool Kit (957 004 002),
WaterAttachment Kit (957 341 040), Starter Rope (394 164 020),
Spark Plug (965 603 021)
14˝ / 4.4 hp 2 Stroke Power Cutter (20 mm Arbor)
SPECIFICATIONS
Displacement 3.7 (60.7 cc)
Maximum Power 3.2 kW (4.4 hp)
Fuel / Oil Mixture 50:1
Fuel Tank Capacity 1/6 Gal (0.7 L)
No Load Speed (Engine) 9,850 RPM
Max. Spindle Speed 4,400 RPM
Arbor 20 mm
Max. Cutting Depth 5-1/8˝ (130 mm)
Dry Weight 19.6 lbs (8.9 kg)
EK6101
Required to use 2 Cycle Synthetic Oil
(Part No. T-00739C)
NEW! Lighter weight power cutter
in the 14" class!
Compliant with CARB Tier 3, EPA Phase 2
and EU Stage 2 Regulations
• NEW Scavenging Losses Rejection (SLR) Muffler
recycles exhaust unburnt gas emissions for increased
operational efficiency and cleaner emissions
• Enhanced 5 stage air filtration; cyclone pre-separation
system effectively removes dust particles away from
intake air and reduces dust stuck on the filter
• Rapid start pull force required to start the machine
is drastically reduced
with spring- assisted
recoil starter
Stratified scavenging system
comply’s with exhaust
emission regulations 988 394 610
