Makita General Catalogue

160 / 180

160
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing And Assembly
EA4300FREC
STANDARD EQUIPMENT INCLUDES:
.325˝ Chain 18" 50G (512 484 672), 18˝ Sprocket Nose Bar .325" 50G (444 045 141), Chain Protector Cover (419560-5),
Spike Bar (346301-5), Universal Wrench (782026-1),Torx Wrench (782025-3), Screwdriver (for CarburetorAdjustment) (783012-5),
Spark Plug (0650109950)
18˝ Bar
• Catalytic converter reduces engine emissions for
reduced environmental impact
• Throttle-lock start position with decompression
valve for reduced start up force
• External access holes allow easy
carburetor adjustment
• Primer pump for easy starting
• Automatic chain oiler
• Inertia chain brake
Rapid Start
18˝ / 43 cc 2 Stroke Chainsaw
SPECIFICATIONS
Displacement 42.4 cc (2.6 )
Chain Pitch / Gauge .325˝ / .050˝
Maximum Engine Speed 13,500 RPM
Power Rating 2.1kW / 2.9 hp
Fuel / Oil Mixture (Makita Oil) 50:1
Fuel Tank Capacity 480 ml
Oil Tank Capacity 280 ml
Net Weight: Dry w/o Bar & Chain
10.8 lbs (4.9 kg)
EA3501SRDB / EA3201SRDB FEATURES & BENEFITS
Intelligent Ignition Coil controls stable idling, increases output power,
protects against engine overrun and enables easy restarting
Touch & Stop Switch automatically returns
switch to start position, eliminating
carburetor flooding and enabling
easy intermittent cutting operations
Rapid Start system features spring assisted recoil starter
to reduce the pull force required to start the saw
Primer Bulb allows
operator to load up fuel
system without flooding
the carburetor
Toolless Chain Tensioner
enables quick and easy
adjustment on the jobsite without
the need for additional tools
Catalytic Converter
complies with EPA Phase 2,
EU Stage 2 exhaust
emission regulations
Inertia Chain Brake
EA4300
EA3501SRDB
STANDARD EQUIPMENT INCLUDES:
16˝ Guide Bar (165202-6), 16˝ Chain Chain (531 492 656), Chain Cover 14”-16” (419560-5), Spike Bar (346301-5),
Universal Wrench (782026-1), Starter Rope (444038-9), Spark Plug (0650109950), Screwdriver (783012-5)
16˝ Bar
• Touch & Stop Switch automatically returns switch
to start position, eliminating carburetor flooding
• Intelligent Ignition Coil controls stable idling,
increases output power, protects against engine
overrun and enables easier restarting
• Toolless Chain Tension Adjustment for quick and
easy adjustment on the jobsite
• Throttle-Lock Start Position
• External access holes allow easy
carburetor adjustment
• Primer pump for easy starting
• Automatic Chain Oiler
• Inertia Chain Brake
16˝ / 35 cc 2 Stroke Chainsaw
SPECIFICATIONS
Displacement 35 cc (2.1 )
Chain Pitch / Gauge 3/8˝ / .050˝
Maximum Engine Speed 13,100 RPM
Power Rating 1.7 kW / 2.3 hp
Fuel / Oil Mixture 50:1
Fuel Tank Capacity 400 ml
Oil Tank Capacity 290 ml
Net Weight: Dry w/o Bar & Chain
9.9 lbs (4.5 kg)
EA3201SRDB
STANDARD EQUIPMENT INCLUDES:
16˝ Guide Bar (165202-6), 16˝ Chain (531 492 656), Chain Cover 16˝ (419560-5), Spike Bar (346301-5), Universal Wrench 13/16 (782026-1),
Screwdriver (783012-5), Spark Plug (0650109950), Starter Rope (444038-9)
16˝ Bar
• Touch & Stop Switch automatically returns switch
to start position, eliminating carburetor flooding
• Intelligent Ignition Coil controls stable idling,
increases output power, protects against engine
overrun and enables easier restarting
• Toolless Chain Tension Adjustment for quick and
easy adjustment on the jobsite
• Throttle-Lock Start Position
• External access holes allow easy carburetor
adjustment
• Primer pump for easy starting
New colour for safety
high visibility
16˝ / 32 cc 2 Stroke Chainsaw
SPECIFICATIONS
Displacement 32 cc (1.95 .)
Chain Pitch / Gauge 3/8˝ / .050˝
Maximum Engine Speed 12,800 RPM
Power Rating 1.35 kW / 1.8 hp
Fuel / Oil mixture 50:1
Fuel Tank Capacity 400 ml
Oil Tank Capacity 280 ml
Net Weight: Dry w/o Bar & Chain
9.4 lbs (4.2 kg)
All Makita Gasoline Powered Chainsawsnow feature
New HIGH VISIBILITY SAFETY COLOUR!
New colour for safety
high visibility
