161 / 180
Toolless Chain Tension Adjustment for quick and
easy adjustment on the jobsite
makita.ca161
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
• Toolless chain tension adjustment for quick and easy adjustment
on the jobsite
• Soft start feature gradually increases speed to eliminate
start up shock
• Electronic current limiter prevents motor burnout due to overloading
• Electric brake for increased operator safety
• Automatic chain oiler maintains constant oil delivery regardless of
temperature or oil viscosity
• Increased oil tank capacity enables longer operating time between refills
• Soft rubber grip design for comfortable operation
SPECIFICATIONS
Chain Pitch / Gauge
3/8˝ / .050˝
Chain Speed
2,900 FPM
Oil Tank
200 ml
AMPS (120V)
14.5 A
Overall Length
19-7/8˝ (505 mm)
Net Weight:
UC3551A
12.1 lbs (5.5 kg)
UC4051A
12.3 lbs (5.6 kg)
UC3551A, UC4051A
Electric Chainsaws
DUC122Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
4-1/2˝ Chain, 4-1/2˝ Guide Bar (158476-6), Chain Cover (416311-7),
Chain File (744003-1), Oil Supply
Ideal For Cutting Small Diameter
Firewood Or Brush, Pruning
Applications And More
• Compact design enables maximum operator
maneuverability and versatility
• Hand guard protects operators hand
during operation
• Lock-off button prevents accidental startup
• Electric brake stops chain within
0.5 seconds for added safety
4-1/2˝ / 18 V Cordless Chainsaw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Guide Bar Length
4-1/2˝ (115 mm)
Chain Pitch / Gauge
1/4˝ / .050”
Chain Speed
980 FPM (300 m/min)
Overall Length
16-5/8˝ (422 mm)
Net Weight
4.2 lbs (1.9 kg)
Electric Brake
DUC302Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
12˝ Chain (196740-7), 12˝ Guide Bar (165245-8), Chain Cover (419288-5), Spike Bumper Set (197819-7)
Makita's FIRST 18Vx2 Chainsaw! Ideal For Cutting
Firewood Or Brush, Pruning Applications And More!
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris
and liquids for optimal performance in extreme conditions
• Battery capacity warning light indicates ideal time to recharge battery
• Lock-off button prevents accidental startup
• Electric chain brake provides maximum operator safety if kickback occurs
• Tool-less chain tension adjustment for quick and easy adjustment on the jobsite
• Automatic chain oiler
12˝
/ 18Vx2 Cordless Chainsaw
SPECIFICATIONS
Battery
Two 18V Li-Ion
Guide Bar Length
12˝ (300 mm)
Chain Pitch / Gauge
3/8˝ / 0.043˝
Chain Speed
1,650 FPM (500 m/min)
Overall Length
22-3/4˝ (577 mm)
Net Weight
7.7 lbs (3.5 kg)
SAFETY EQUIPMENT
T-01703
FACE SHIELD
T-01638
T-01622
MSP28-30 T-01650 T-01666 T-01672 MSP44-46
Safety Helmet
Complete
Head, hearing & face protection
Forestry Face
Screen
Brush Guard
Visor
Chainsaw
Safety Chaps
One size fits all
Size 28/30 Size 32/34 Size 36/38 Size 40/42 Size 44/46
Chainsaw Safety Pants
Outdoor
Power Equipment
14˝ Bar
(350 mm)
STANDARD EQUIPMENT INCLUDES:
14˝ Chain (528 092 652),
14˝ Guide Bar (165201-8), Chain Cover
(419288-5), Hook Complete (158024-1),
Spike Bumper (345651-5)
UC3551A
STANDARD EQUIPMENT INCLUDES:
16˝ Chain (531 492 656),
16˝ Guide Bar (165202-6), Chain Cover
(419242-9), Hook Complete (158024-1),
Spike Bumper (345651-5)
UC4051A
16˝ Bar
(400 mm)
1
5
Electric Brake
Electric Chain Brake
