EA6100PRGE 21˝ / 60 cc 2 Stroke Chainsaw
Perfect saw for felling and debranching in one machine
21˝ Bar
• Intake air pre-cleaning significantly removes dirt particles at an early stage
• Extended working time with Long Life Air Filter system. No tools required and cleaning is easy
• Equipped with 'Easy Start' features to facilitate easy starting with much less pulling effort required
• 'Touch & Stop' one lever control takes care of the starting, running and shut down operations
• Up to 20% less fuel consumption and lower emissions due to Makita's advanced engine technologies
• Vibration dampening is controlled by oil and fuel resistant steel springs adding to the operator's comfort
• Side mounted chain tensioner adds easier adjustments to the saw chain when required
SPECIFICATIONS
Displacement 60.7 cc (3.7 )
Chain Pitch / Gauge 3/8" / . 058”
Max. Engine Speed 13,800 RPM
Power Rating 3.4 kW / 4.5 hp
Fuel Tank Capacity 800 ml
Oil Tank Capacity 480 ml
Fuel / Oil Mixture 50:1
Net Weight: Dry w/o Bar & Chain 13.2 lbs (6.0 kg)
STANDARD EQUIPMENT INCLUDES:
20-21˝ Chain (523 099 072), 21˝ Guide Bar (443 053 651), Chain Cover (952 020 660),Tool Kit (957 004 002)
Stratified scavenging system to
comply with many exhaust
emission regulations
Longlife Air Filter system
'Easy Start' Features
'Touch & Stop' one lever control
STANDARD EQUIPMENT INCLUDES:
20-21˝ Chain (523 099 072), 20˝ Guide Bar (445 050 655),
Chain Cover (952 020 660),Tool Kit (957 004 002), Starter Rope (108 164 020), Spark Plug (965 603 021)
20˝ Bar
• Scavenging Losses Rejection (SLR) muffler
recycles exhaust emissions for increased
operational efficiency and cleaner emissions
• Throttle-lock start position with decompression
valve for reduced start up force
• External access holes allow easy
carburetor adjustment
• Automatic chain oiler
• Inertia chain brake
Scavenging
Losses Rejection
(SLR) Muffler
20˝ / 73 cc 2 Stroke Chainsaw
SPECIFICATIONS
Displacement 72.6 cc (4.4 )
Chain Pitch / Gauge 3/8˝ / . 058˝
Maximum Engine Speed 12,800 RPM
Power Rating 4.0 kW / 5.4 hp
Fuel Tank Capacity 750 ml
Oil Tank Capacity 420 ml
Fuel / Oil Mixture 50:1
Net Weight 13.8 lbs (6.3 kg)
EA7300PRFE
When QUALITY & SERVICE Counts – Choose Makita
EA6100
DCS5121REJ
STANDARD EQUIPMENT INCLUDES:
18˝ Chain (523 686 072),18˝ Guide Bar (445 045 631), Chain Cover (952 020 650), Starter Rope (108 164 020),
Spark Plug (965 603 021),Tool Kit (957 004 002)
18˝ Bar
• Throttle-lock start position
• External access holes allow easy carburetor
adjustment
• Primer pump for easy starting
• Automatic chain oiler
• Electronic ignition
• Inertia chain brake
• Large diameter fuel / oil caps with external
fuel indicator
• Handles and grips proportioned for
optimum comfort
Efficient
Cold Weather
Operation
18˝ / 50 cc 2 Stroke Chainsaw
SPECIFICATIONS
Displacement 50 cc (3.1 .)
Chain Pitch / Gauge .325˝ / .058˝
Maximum Engine Speed 13,800 RPM
Power Rating 2.5 kW / 3.3 hp
Fuel Tank Capacity 470 ml
Oil Tank Capacity 269 ml
Fuel / Oil Mixture 50:1
Net Weight: Dry w/o Bar & Chain
12.1 lbs (5.4 kg)
Outdoor Power Equipment
18˝ Rescue Bar
& Chain Kit
Sold Separately
(Part No. 957 415 060)
See page 160
All Makita Gasoline Powered Chainsawsnow feature
New HIGH VISIBILITY SAFETY COLOUR!
