BHX2500CA
STANDARD EQUIPMENT INCLUDES:
Long Nozzle (125729-8), Round End Nozzle (450966-8),Tool Kit (194717-6), Starter Rope (444019-3), Spark Plug (0650109950)
Air Speed 145 MPH, Max. Air Volume 316 CFM
• Exceeds Government Clean Air Emission Ratings
• 4-Stroke, for low noise and low emission
• Quick-start - low compression engine
for easy starting
• Auto decompression for easy starting
• Easy access to spark plug and air filter
• Light weight design
Improved Fuel Tank Coating Is EPA Phase II
And CARB III Compliant
24.5 cc 4 Stroke Blower
SPECIFICATIONS
Displacement
24.5 cc
Maximum Air Flow
145 MPH
Maximum Air Volume (End Of Nozzle)
316 CFM
Power Rating
0.81 kW / 1.1 hp
Carburetor All Position Diaphragm Type
Tank Capacity
520 ml
Overall Length
13-3/4˝ (350 mm)
Dry Weight
9.9 lbs (4.5 kg)
EB7650TH
STANDARD EQUIPMENT INCLUDES:
Long Pipe 90 (454895-7), End Nozzle 90-60 (454896-5),
Flat Nozzle (454916-5), End Nozzle 90-70 (455128-3),
Flexible Pipe (454934-3), Swivel Pipe (168832-2),
Tool Kit (196771-6), Shoulder Harness L(166125-1),
Shoulder Harness R (166126-9), Hose Clamp (282025-8),
Spark Plug (0650109950), Starter Rope (444043-6)
200 MPH Air Speed with
682 CFM Volume
• 4 Damper springs mounted between the engine and
the backpack frame reduce the vibration on the
back of operator even during long hours
• Cushioned back padding and shoulder straps,
in addition to being well-ventilated, aid in effective
sweat evaporation and to to provide
more operator comfort
• MM4 4 stroke engine for lower
emissions and longer run time
75.6 cc 4 Stroke Backpack Blower
BLOWER ACCESSORIES FOR EB7650TH
Description
For Model No.
Part No.
Long Pipe
EB7650TH
454895-7
Short Pipe
455127-5
End Nozzle
454896-5
End Nozzle
455128-3
Flat Nozzle
454916-5
BLOWER ACCESSORIES FOR BHX2500CA
Description
For Model No.
Part No.
Straight Pipe #1
BHX2500CA
455462-1
Straight Pipe #2
454188-2
Pipe #3
454241-4
Round End Pipe
450966-8
Curved End Pipe
451753-8
Elbow
453720-9
Vacuum Assembly
197234-5
Dust Bag
166114-6
Grip
6609008000
Tool Kit
194717-6
Reliable & Environment Friendly Makita
4-STROKE ENGINE SERIES
Makita’s 4-Stroke Engines offer the following advantages compared
with the equivalent size of 2-Stroke Engines:
High Performance, Compact and Light Weight Design
•
Clean Exhaust Emissions
Low Running Cost
•
Easy Maintenance
•
Low Noise
SPECIFICATIONS
Displacement
75.6 cc
Maximum Air Flow
(Long Pipe, End Nozzle 90-60) 200 MPH
Maximum Air Volume
(Long Pipe, End Nozzle 90-70) 682 CFM
Power Rating
2.7 kW / 3.7 hp
Carburetor
Diaphragm Type
Fuel / Oil Mixture
Not Required
Tank Capacity
1.9 L
Overall Length
13 -1/8˝ ( 332 mm)
Dry Weight
23.8 lbs (10.8 kg)
4 Stroke MM4 engine for
lower emissions and greater
fuel economy
Outdoor
Power Equipment
EB7650TH
BHX2500CA
Shown With Optional
Curved End Pipe
Sold Separately
(Part No. 451753-8)
