12 / 180
LITHIUM-ION
makita.ca12
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
DHR241RFE
STANDARD EQUIPMENT INCLUDES:
DHR241RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8), Depth Gauge
(324219-0), Side Handle (158057-6), Plastic Carrying Case (141643-0)
DHR241Z:
Tool Only. Batteries and Charger Sold Separately.
Depth Gauge (324219-0), Side Handle (158057-6)
Lightweight, 3 Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Rubber Joint Construction suppresses transmission of vibration to battery, minimizing battery failures
due to terminal breakage or poor electrical contact
• 40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• Rubber Housing Bumper protects mode selector switch and gear housing from damage
• One Touch Sliding Chuck enables quick
and easy bit changes
Variable Speed, Reversible
15/16˝ Rotary Hammer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
15/16˝ (24 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/16˝ (26 mm)
Impact Energy
1.9 J (1.4 ft.lbs.)
No Load Speed
0 - 1200 RPM
Blows Per Minute
0 - 4000 BPM
Overall Length
16-3/8˝ (417 mm)
Net Weight
7.7 lbs (3.5 kg)
DHR241Z
DHR202RFE
STANDARD EQUIPMENT INCLUDES:
DHR202RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3),
Rapid Charger (DC18RC), Battery Cover (450128-8), Depth Gauge (324219-0), Side Handle (158057-6), Plastic Carrying Case (141642-2)
DHR202Z:
Tool Only. Batteries and Charger Sold Separately.
Depth Gauge (324219-0), Side Handle (158057-6)
Lightweight, 3 Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Rubber Joint Construction suppresses transmission of vibration to battery, minimizing battery failures
due to terminal breakage or poor electrical contact
• 40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• LED Light with Afterglow feature
• One touch sliding chuck enables quick and easy bit changes
Variable Speed, Reversible
15/16˝ Rotary Hammer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
15/16˝ (24 mm)
Steel
1/2˝ (13 mm)
Wood
1˝ (26 mm)
Impact Energy
1.9 J (1.4 ft. lbs.)
No Load Speed
0 - 1,100 RPM
Blows Per Minute
0 - 4,000 BPM
Overall Length
14-1/8˝ (358 mm)
Net Weight
7.7 lbs (3.5 kg)
DHR202Z
• DX01 - Use with models DHR242RMEV / DHR242ZVX
• DX02 - Use with model DHR243Z
Rotary Hammer HEPA Filter Dust Extraction System
DHR243Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Depth Gauge (324219-0), Drill Chuck Set (194079-2), Side Handle (158057-6)
Lightweight 3-Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
Features Quick Change Drill Chuck
• Brushless DC Motor generates less heat buildup and is ideal for prolonged use
in high production applications
• Quickly attaches to Makita's DX02 Dust Extraction System for dustless drilling applications in sensitive
work environments (DX02 sold separately)
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
15/16˝ Rotary Hammer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
15/16˝ (24 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/16˝ (27 mm)
Impact Energy
2.4 J (1.8 ft. lbs.)
No Load Speed
0 - 950 RPM
Blows Per Minute
0 - 4,700 BPM
Overall Length
13-7/8˝ (353 mm)
Net Weight
6.4 lbs (2.9 kg)
Variable Speed, Reversible
Quick Change Drill Chuck
194079-2
DHR242RMEV
STANDARD EQUIPMENT INCLUDES:
DHR242RMEV:
Two18V(4.0Ah)Li-IonBatteries
BL1840B(196401-9), Rapid Charger (DC18RC), Battery Cover (450128-8),
Depth Gauge (324219-0), Side Handle (158057-6), Dust Extraction System (DX01), Plastic Carrying Case (141402-2)
DHR242ZVX:
Tool Only. Batteries and Charger Sold Separately.
Depth Gauge (324219-0), Side Handle (158057-6),
Dust Extraction System (DX01), 21˝Tool Bag (821007X)
15/16˝ Rotary Hammer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
15/16˝ (24 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/16˝ (27 mm)
Impact Energy
2.4 J (1.8 ft. lbs.)
No Load Speed
0 - 950 RPM
Blows Per Minute
0 - 4,700 BPM
Overall Length
12-7/8˝ (328 mm)
Net Weight
7.3 lbs (3.3 kg)
Variable Speed,
Reversible
Lightweight, 3-Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Brushless DC Motor generates less heat buildup and is ideal for prolonged use in high production applications
• Includes DX01 HEPAFilter Dust Extraction System for dustless drilling applications in sensitive work environments
• DX01 HEPA Filter Dust Extraction System features
One-Touch Attachment / Removal System,
Adjustable Depth Gauge and Large Capacity
Dust Box for maximum
efficiency and
versatility
DHR242ZVX
Makita offers a wide variety of
ACCESSORIES!
For
ACCESSORIES
see pages 99 - 101
For
ACCESSORIES
see pages 99 - 101
For
ACCESSORIES
see pages 99 - 101
For
ACCESSORIES
see pages 99 - 101
HEPA
filter
• Provides effective dust extraction for drilling applications in sensitive work environments
• Transparent Dust Box allows operator to quickly reference current dust level
• One Touch Attachment/Removal system enables canister to be quickly emptied of accumulated dust
• Large Dust Canister provides extended operating time between cleaning
• Easily removable HEPA Filter for fast and effective cleaning
• Integrated Depth Gauge is fully adjustable for precise depth setting
• Easily removable from Rotary Hammer when not immediately required
• Double Lock Function prevents accidental removal from Rotary Hammer
• Automatic Operation in conjunction with Rotary Hammer using integrated DC Motor
DX01 (Shown)
Dust Extraction System
196810-2
Direct Connect Style BCV03
Use with models HRH01, HRU01ZX2, HKU01ZX2
• Enables the use of Two 18V Li-Ion Batteries to operate most 36V Li-Ion Tools and Accessories
• Features Li-Ion Battery Protection System, including Over-Discharge. Temperature and Circuit Protection
for enhanced performance, battery cycle life and overall battery life
• LED Power Lights indicate remaining battery power
Compact Design ideal for direct mounting on
tools and accessories
• Batteries not included
18V to 36V Li-Ion Battery Converters
195512-7
Belt / Shoulder Style BCV01
Use with models HRH01, HKU01ZX2
• Enables the use of Two 18V Li-Ion Batteries to operate most 36V Li-Ion Tools and Accessories
• Features Li-Ion Battery Protection System, including Over-Discharge.
Temperature and Circuit Protection for enhanced performance,
battery cycle life and overall battery life
• LED Power Lights indicate remaining battery power
• Rugged ABS Plastic Cover provides maximum bettery protection
• Heavy Duty 5' Power Cord allows for maximum reach
• Can be worn using Belt Hook and Loops
or with optional Shoulder Strap
(Part No. 166094-6, not shown)
