Makita General Catalogue

Quick and effortless

rebar cutting for

maximum jobsite

productivity

and safety

LITHIUM-ION

makita.ca

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

DBN500Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

NoseAdapter (424121-8), Safety Goggles (195246-2), Hex Wrench 3 (783201-2),

Hook (346449-3)

Bump & Sequential Fire Operating Modes

• Reduced reaction force enables maximum operator control and reduced operator fatigue

• Anti-dry fire mechanism prevents added wear on the drive pin

• Easy to see, low profile contact tip for maximum fastening precision

• Battery protection system provides over-discharge, temperature and current protection for enhanced

performance, battery cycle life and overall battery life

• LED battery capacity warning light indicates ideal time to recharge battery

18 ga Brad Nailer

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Magazine Capacities

100 nails

Gauge

18 ga

Nail Length 5/8˝ - 2˝ (15 mm - 50 mm)

Dimensions (L x W x H)

11-5/8˝ x 3-13/16˝ x 12-1/2˝

(294 mm x 97 mm x 318 mm)

Net Weight

6.4 lbs (2.9 kg)

DST221RFEX

STANDARD EQUIPMENT INCLUDES:

DST221RFEX:

Two 18V (3.0Ah) Li-Ion Batteries

BL1830B (194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8),

Safety Goggles (195246-2), Hook (346449-3), 14˝Tool Bag (821010-X) .

DST221Z:

Tool Only. Batteries and Charger Sold Separately.

Safety Goggles (195246-2), Hook (346449-3)

Machined Aluminum Magazine Ensures Smooth Staple Loading And Feeding

• Contact Arm enables bump firing for quick operation

• Depth Control Dial enables precise setting of staple depth

• Belt Clip for operator convenience

• Easy to Repair Construction

• Magazine Window shows quantity of staples remaining

Stapler

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Staple:

Width

3/8˝ (10 mm)

Length 3/8˝ - 7/8˝ (10 mm - 22 mm)

Gauge 1/32˝ x 1/16˝ (0.6 mm x 1.2 mm)

Magazine Capacity:

Pcs. Per Sheet

Maximum

Overall Length

9-7/8˝ (251 mm)

Net Weight

5.3 lbs (2.4 kg)

DST221Z

STANDARD EQUIPMENT INCLUDES:

DGD800RFE:

Two 18V (3.0Ah) Li-Ion Batteries

BL1830B (194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8),

1/4˝ Collet Cone (763673-7), Collet Nut (763668-0),Two Wrenches 13 (781039-9), Plastic Carrying Case (141482-8)

DGD800Z:

ToolOnly.BatteriesandChargerSoldSeparately.

1/4˝ColletCone(763673-7),ColletNut(763668-0),TwoWrenches13(781039-9)

Compact And Lightweight Die Grinder

• Anti-Restart feature prevents accidental start up of tool during battery changing when switch is

locked in the on position

• Low Battery Capacity Light indicates ideal time to recharge battery

• Vent Slots direct exhaust towards opposite side of operator

• Easy to Grip Motor Housing for easier handling

• Ergonomic Soft Rubber Grip design for vibration

absorption and comfortable operation

1/4˝ Die Grinder

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Collet Capacity

1/4˝ (8 mm)

Maximum Wheel Diameter 1-7/16˝ (36 mm)

No Load Speed

26,000 RPM

Overall Length

15-3/4˝ (402 mm)

Net Weight

4.4 lbs (2.0 kg)

DGD800RFE

DGD800Z

DPT351RFE

STANDARD EQUIPMENT INCLUDES:

DPT351RFE:

Two 18V (3.0Ah) Li-Ion Batteries

BL1830 (194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8),

NoseAdapter (419525-7), Safety Goggles (195246-2), Hex Wrench 3 (783201-2), Hook (346449-3), Plastic Carrying Case (141134-1)

DPT351Z:

Tool Only. Batteries and Charger Sold Separately.

NoseAdapter (419525-7), Safety Goggles (195246-2),

Hex Wrench 3 (783201-2), Hook (346449-3)

Hose-Free Maneuverability And Control

• Double Trigger enables accuracy, precision and prevents accidental firing for increased operator safety

• Anti-Dry Fire Mechanism prevents added wear on drive pin

• On-Board Depth Control for quick and easy adjustment

• LED Job Light illuminates work area

• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation

23 ga Pin Nailer

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Magazine Capacities

130 nails

Gauge

23 ga

Pin Length

11/16˝, 1-3/8˝

Overall Length

9-3/4˝ (249 mm)

Net Weight

4.6 lbs (2.1 kg)

DPT351Z

DSC191Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Hex. Wrench 3 (783201-2), Hex Wrench 4 (783202-0), Hex Wrench 5 (783203-8),

Hex Wrench 6 (783204-6), Hex Wrench 17-19 (781212-1), Special Blade Set (SC09002030), Oil Supply (SC00000142),

Plastic Carrying Case (SC09009190)

• Spark free cutting ideal for use in sensitive areas

• 360º rotating cutting head enables operator to adjust cutting position for maximum

efficiency and precision

• 360º rotating side handle allows operator to hold tool at most comfortable position

• Adjustable stopper secures rebar at 90º

to ensure smooth cutting

• Battery protection system provides over-discharge,

temperature and circuit protection for enhanced

performance, battery cycle life

and overall battery life

Rebar Cutter

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Cutting Capacity #6 Rebar 3/4˝ (19 mm)

Cutting Speed

6.5 sec

Overall Length

16-1/5˝ (412 mm)

Net Weight

22.5 lbs (10.2 kg)

Makita offers a wide variety of

ACCESSORIES!

DSC191Z

For

ACCESSORIES

see pages 142 - 143
