28 / 180
LITHIUM-ION
makita.ca28
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
DUB182Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
NozzleAssembly (132025-7),
Dust Bag (122814-8)
Low / Medium / High Air Volume Settings
• Variable Speed Control within each speed setting
• Anti-Static Design to prevent buildup of static electricity
• Converts to Vacuum quickly and easily
• Ergonomic Soft Rubber Grip design for vibration absorption
and comfortable operation
Blower / Vacuum
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Air Volume 92 CFM (2.6 m
3
/min)
Maximum Air Velocity 179 MPH (80 m/sec)
Maximum Air Pressure
5.4 kpa (550 mm H
2
O)
No Load Speed
0 - 18,000 RPM
Overall Length
20-3/4˝ (525 mm)
Net Weight
2.9 lbs (1.3 kg)
Variable Speed
Optional Long Nozzle
with Curved End
Sold Separately
(Part No. TP00000199)
DVC350Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
NozzleAssembly(132025-7),DustBag
(122918-6),HoseComplete28-2.5M(140456-6),ShoulderHarness(166094-6),FrontCuff(417766-9)
Portable Vacuum Cleaner For Use
With Makita Power Tools
• Push Button Air Volume Selection (Low / High Settings)
• Shoulder Strap for operator convenience
• Can be converted into a blower by
attaching nozzle assembly
Vacuum Cleaner
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Air Flow
120 CFM (3.4 m3/min)
Maximum Air Speed
308 ft./s (94 m/s)
Maximum Capacity
6.3 Pints (3.0 L)
Overall Dimensions (L x W x H)
15-7/8˝ x 7-5/8˝ x 8-7/8˝ (403 mm x 195 mm x 226 mm)
Net Weight
4.9 lbs (2.2 kg)
DCL180Z
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
NozzleAssembly(122859-6),
Sash Nozzle (451243-1), Pipe (451244-9), Sash Nozzle Holder(451245-7),
Cloth Filter (443060-3), Nylon Pre-Filter (451208-3)
Lightweight And Portable Vacuum
Cleaner For Shop, Office Or Home Use
• 2 Stage Nylon and Cloth Filter
• Easy to Empty Dust Canister
• Very Quiet Operation (71 dB)
• On Board Sash Nozzle Storage
• Improved Floor Nozzle Swivel
Joint for easier
maneuverability
650 ml Vacuum Cleaner
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacity
1.4 pints (650 ml)
Overall Length with Straight Pipe and Nozzle
39-1/4˝ (997 mm)
Net Weight
3.1 lbs (1.4 kg)
CORDLESS VACUUM CLEANER
TOOLS & ADAPTERS
Tool Model
Tool Adapter
Front Cuff 22
417765-1
Front Cuff 24
195546-0
Front Cuff 38
417766-9
Front Cuff 22
417765-1
Front Cuff 24
195546-0
Front Cuff 38
417766-9
DHS711PF2 / Z
196843-7
•
–
–
•
•
•
DHS680Z
196952-2
•
•
–
–
•
•
DSS611RFE / Z
P-80012
•
–
–
•
•
•
DJV181RME / Z
DJV182RME / Z
126331-0
•
•
–
–
•
•
DJV180RFE / Z
P-80020
•
–
–
•
•
•
DTM50ZKX1
195965-0
•
–
–
•
•
•
DTM51ZKX7
196765-1
•
–
–
•
•
•
DPJ180Z
No Adapters
Required
–
•
–
–
•
•
•
DCO180Z
P-80010
•
–
–
•
•
•
DSD180Z
No Adapters
Required
–
•
–
–
•
•
•
DBO180Z
No Adapters
Required
–
•
–
–
•
•
•
DHR202RFE / Z, DHR241RFE / Z
DHR242RMEV, DHR263PF2 / Z
DHR264Z
P-80015
•
–
–
•
•
•
DKP180Z
451329-1
–
–
•
–
–
•
DLS714Z
No Adapters
Required
–
–
–
•
–
–
•
DLS713Z
No Adapters
Required
–
–
–
•
–
–
•
DVC861
DVC350
DVC260
