Makita General Catalogue

LITHIUM-ION

makita.ca

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

DMR107

• Operates on 7.2V - 18V Li-Ion slide and pod style Makita battery (battery not included)

and AC or DC power sources

• IP64 rated for maximum weather and water resistance suitable for jobsite or sports / recreational use

• Rugged protective design ideal for use on the jobsite

• Auxilliary outlet for MP3 players

• LCD digital display indicates AM / FM band, presets, volume level and radio station frequency

• 5 AM / 5 PM preset function

• Push button AM / FM digital tuning feature

• Features two alarm settings for radio or buzzer alarm

• Runs up to 35 hours on a single charge (with 5.0 Ah battery)

• Swivelling carrying

handle with soft

rubber grip

Cordless or Electric Jobsite Radio

SPECIFICATIONS

Battery Capacities

7.2V – 18V Li-Ion

Dimensions (L x W x H)

11˝ x 6-3/8˝ x 11-7/8˝

(280 mm x 163 mm x 302 mm)

Net Weight

9.7 lbs (4.4 kg)

DMR200

Features Bluetooth

Compatibility For Wireless Jobsite Use

• USB charging port enables convenient charging of mobile devices on the jobsite

• Operates on 12V MAX - 18V Li-ion slide style Makita batteries (battery not included)

and AC or DC power sources

• Push button control panel with 3 LED Blueooth

connection lights

• Auxiliary outlet suitable for MP3 players

• IP64 rated for maximum weather and water resistance suitable for jobsite or sports / recreational use

• Rugged protective design with expanded rubber bumpers and flat top

• Runs up to 32 hours on a single charge (with 5.0 Ah battery)

• Swivelling carrying handle with soft rubber grip

Cordless or Electric Jobsite Speaker with Bluetooth

SPECIFICATIONS

Battery Capacities:

18V Li-Ion

14.4V Li-Ion

12V MAX CXT Li-Ion

Dimensions (L x W x H)

8-5/16˝ x 8˝ x 7-7/8˝

(211 mm x 203 mm x 199 mm)

Net Weight

5.6 lbs. (2.6 kg)

DUM168Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Base Frame (326146-7), Change Lever (451813-6), Blade Cover (452055-5)

Compact Design For Added Versatility

• Battery Protection System provides Over-Discharge, Temperature

and Current Protection

for enhanced performance, battery cycle life and overall battery life

• Battery Capacity Warning Light indicates low battery capacity

• Dual Blade action cuts quickly with shearing effect

• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting

• Wire Toboggan Style Base Frame enables quick and easy depth adjustment

• Tool-less Blade Changing System enables simple and easy blade changes

• Left and Right Hand Lock-Off Button for operator safety

• Ergonomic Soft Rubber Grip design for vibration absorption

and comfortable operation

6-5/16˝ Grass Shear

SPECIFICATIONS

Battery Capacities

18V Li-Ion

No Load Speed

1,250 SPM

Cutting Width

6-5/16˝ (160 mm)

Depth Adjustment

3/8˝ / 13/16˝ / 1-3/16˝

(10 mm / 20 mm / 30 mm)

Overall Length

13-7/8˝ (353 mm)

Net Weight

2.9 lbs (1.1 kg)

Dual Blade Action

DMR108

Bluetooth

is a registered trademark of Bluetooth

SIG

Features Bluetooth

Compatibility For Wireless Jobsite Use

• USB charging port enables convenient charging of mobile devices on the jobsite

• Operates on 7.2V - 18V Li-Ion slide and pod style Makita battery (battery not included) and

AC or DC power sources

• Digital AM / FM Tuner with LCD Backlit Display and 10 pre-sets (5 AM / 5 FM)

• Dual auxiliary outlets suitable for MP3 players

• IP64 rated for maximum weather and water resistance suitable

for jobsite or sports / recreational use

• Rugged protective design with expanded rubber bumpers

and front metal cage

• Two alarms, runs up to 35 hours on a single charge

(with 5.0 Ah battery)

• Swivel mount, soft bend antenna prevents breakage

and/or loss

Cordless or Electric Jobsite Radios with Bluetooth

SPECIFICATIONS

Battery Capacities

7.2V – 18V Li-Ion

Dimensions (L x W x H)

10-3/8˝ x 6-3/8˝ x 17˝

(257 mm x 163 mm x 431 mm)

Net Weight

9.7 lbs (4.4 Kg)

Bluetooth

is a registered trademark of Bluetooth

SIG

DCF300Z

High-Performance Fan For Increased Air Circulation Or Cooling

On Heavy Duty Jobsites

• 13˝

diameter fan provides maximum air volume for superior performance on heavy duty jobsites

• Automatic swing feature and manual tilt features allow fan to be positioned at any angle for

maximum jobsite versatility

• Frame design reduces noise and can be easily removed for

cleaning and maintenance

• Low / medium / high air speed settings

• 3-stage automatic timer (1, 2 or 4 hours)

• Rigid metal pipe stand with rubber bumpers provides

stability during operation and protects material or

workpiece from damage

Cordless or Electric Jobsite Fan

Tool Only. Batteries and Charger Sold Separately.

ACAdapter (TE00000110)

SPECIFICATIONS

Battery Capacities:

18V Li-Ion

14.4V Li-Ion

Continuous Run Time:

High up to 70 mins (with Battery BL1840B)

Low up to 255 mins (with Battery BL1840B)

Overall Length

12-3/8˝ (315 mm)

Net Weight

9.0 lbs (4.1 kg)

Makita offers a wide variety of

ACCESSORIES!

Optional Hedge

Trimmer Attachment

for DUM168Z & MU01Z

Hedge Trimmer Blades

195178-3

HedgeTrimmer Cover

195274-7

DCF201Z

Ideal for Providing Increased Air Circulation or Cooling on the Jobsite

• Heavy Duty Design ideal for jobsite use

• 9-7/8" Diameter Fan produces high air volume for optimal performance

• Rubber Bumpers protect tool and materials from damage

• Low / High Air Speed Settings

• 3-Stage Automatic Timer - 1, 2 or 4 hours

• Adjustable up to 45° for optimal positioning

• Carrying Handle for easy transportation

Cordless or Electric Jobsite Fan

Tool Only. Batteries and Charger Sold Separately.

ACAdapter (TEB0000002)

SPECIFICATIONS

Battery Capacities:

18V Li-Ion

14.4V Li-Ion

Continuous Run Time:

High up to 100 mins (with Battery BL1830)

Low up to 200 mins (with Battery BL1830)

Overall Length

10-3/8˝ (263 mm)

Net Weight (no battery)

4.0 lbs (1.8 kg)
