Makita General Catalogue

32 / 180

LITHIUM-ION
32
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing And Assembly
DF332DSYE
STANDARD EQUIPMENT INCLUDES:
DF332DSYE:Two 12V MAX (1.5Ah) CXT Li-Ion Batteries BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Keyless Drill Chuck (763238-5), Phillips Bit 2-50 (784244-7), Hook (346909-5), Plastic Carrying Case (821661-1)
DF332DZ: Tool Only. Batteries and Charger Sold Separately. Keyless Drill Chuck (763238-5), Phillips Bit 2-50 (784244-7),
Hook (346909-5)
Compact eXtreme Technology (CXT)
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• 20 clutch settings + drill mode delivers up to 280 in. lbs. of torque
• LED job light with pre-glow
and after-glow
feature
illuminates
work area
Variable 2-Speed,
Reversible
3/8˝ Drill / Driver
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Capacities:
Steel 3/8˝ (10 mm)
Wood 1-1/8˝ (28 mm)
No Load Speed:
Low 0 - 450 RPM
High 0 - 1,500 RPM
Maximum Torque 280 in. lbs (32 Nm)
Overall Length 6-1/16˝ (154 mm)
Net Weight 2.3 lbs (1.0 kg)
DF332DZ
DF331DSYE
STANDARD EQUIPMENT INCLUDES:
DF331DSYE: Two 12V MAX (1.5Ah) CXT Li-Ion BatteriesBL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Phillips Bit 2-50 (784244-7), Hook (346909-5), 3/8˝Keyless Drill Chuck (763228-8), Plastic Carrying Case (821661-1)
DF331DZ: Tool Only. Batteries and Charger Sold Separately. Phillips Bit 2-50 (784244-7), Hook (346909-5),
3/8˝Keyless Drill Chuck (763228-8)
Compact eXtreme Technology (CXT)
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• 18 clutch settings + drill mode delivers up to 250 in. lbs. of torque
• LED job light with pre-glow and after-glow feature illuminates work area
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
3/8˝ Drill / Driver
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Capacities:
Steel 3/8˝ (10 mm)
Wood 13/16˝ (21 mm)
Maximum Torque 250 in. lbs (28 Nm)
No Load Speed:
Low 0 - 450 RPM
High 0 - 1,700 RPM
Overall Length 7-7/16˝ (189 mm)
Net Weight 2.4 lbs (1.1 kg)
DF331DZ
Variable 2-Speed,
Reversible
DF032DSYE
STANDARD EQUIPMENT INCLUDES:
DF032DSYE: Two 12V MAX (1.5Ah) CXT Li-Ion Batteries BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Phillips Bit 2-50 (784244-7), Hook (346909-5), Plastic Carrying Case (821661-1)
DF032DZ: Tool Only. Batteries and Charger Sold Separately. Phillips Bit 2-50 (784244-7), Hook (346909-5)
Compact eXtreme Technology (CXT)
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• 20 clutch settings + drill mode delivers up to 280 in. lbs. of torque
• LED job light with pre-glow
and after-glow
feature illuminates
work area
Variable 2-Speed,
Reversible
1/4˝ Hex Drill / Driver
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Hex Shank 1/4˝ (6.35 mm)
Capacities:
Steel 3/8˝ (10 mm)
Wood 1-1/8˝ (28 mm)
No Load Speed:
Low 0 - 450 RPM
High 0 - 1,500 RPM
Maximum Torque 280 in. lbs (32 Nm)
Overall Length 4-7/8˝ (124 mm)
Net Weight 1.9 lbs (0.88 kg)
DF032DZ
DF031DSYE
STANDARD EQUIPMENT INCLUDES:
DF031DSYE: Two 12V MAX (1.5Ah) CXT Li-Ion BatteriesBL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Phillips Bit 2-50 (784244-7), Hook (346909-5), Plastic Carrying Case (821661-1)
DF031DZ: Tool Only. Batteries and Charger Sold Separately.Phillips Bit 2-50 (784244-7), Hook (346909-5)
Compact eXtreme Technology (CXT)
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• 18 clutch settings + drill mode delivers up to 250 in. lbs. of torque
• LED job light with pre-glow and after-glow feature illuminates work area
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
1/4˝ Hex Drill / Driver
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Hex Shank 1/4˝ (6.35 mm)
Capacities:
Steel 3/8˝ (10 mm)
Wood 13/16˝ (21 mm)
No Load Speed:
Low 0 - 450 RPM
High 0 - 1,700 RPM
Maximum Torque 250 in. lbs (28 Nm)
Overall Length 6-3/16˝ (157 mm)
Net Weight 2.1 lbs (0.94 kg)
DF031DZ
Variable 2-Speed,
Reversible
Makita offers a wide variety of ACCESSORIES!
CLX201S
INCLUDES:
• 3/8˝ Driver Drill
(DF331DZ)
• 1/4˝ Impact Driver
(TD110DZ)
• Two 12V MAX CXT Li-Ion
Batteries BL1016
• Slide Charger (DC10SB)
• Tool Bag (831274-0)
2 Tool Combo Kit
TD111DSYE
STANDARD EQUIPMENT INCLUDES:
TD111DSYE: Two 12V MAX (1.5Ah) CXT Li-Ion BatteriesBL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Phillips Bit 2-50 (784244-7), Hook (346909-5), Plastic Carrying Case (821661-1)
TD111DZ: Tool Only. Batteries and Charger Sold Separately. Phillips Bit 2-50 (784244-7), Hook (346909-5)
Compact eXtreme Technology (CXT)
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
production applications
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• LED job light with pre-glow and after-glow feature illuminates work area
1/4˝ Hex Impact Driver
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Hex Shank 1/4˝ (6.35 mm)
No Load Speed:
Low 0 - 1,300 RPM
High 0 - 3,000 RPM
Impacts Per Minute:
High 0 - 3,900 IPM
Low 0 - 1,600 IPM
Maximum Torque 1,200 in. lbs (135 Nm)
Overall Length 5-5/16˝ (135 mm)
Net Weight 2.1 lbs (0.97 kg)
TD111DZ
Variable Speed,
Reversible
