29 / 180
DUC122Z
Cordless
Power Tools
makita.ca29
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
DUH523Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Blade Cover (453723-3), Shear Blade Complete Set (195846-8)
Designed for Maximum Versatility and Ease of Operation
• Battery Protection System provides Over-Discharge, Temperature and Current Protection
for enhanced performance, battery cycle life and overall battery life
• Anti-Vibration Structure features five cushions linking handle and motor sections for significantly
reduced vibration transmission to operator
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Tool-less Blade Changing System enables simple and easy blade changes
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
22˝ Hedge Trimmer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Strokes Per Minute (min-1)
1,350 SPM
Cutting Width
22˝ (560 mm)
Maximum Cutting Thickness
15/32˝ (12 mm)
Overall Length
38˝ (96 cm)
Net Weight
6.0 lbs (2.7 kg)
Dual Blade Action
DUC122Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
4-1/2˝ Chain (791284-8), 4-1/2˝ Guide Bar (158476-6), Chain Cover (416311-7),
Chain File (744003-1), Oil Supply
Ideal For Cutting Small Diameter
Firewood Or Brush, Pruning
Applications And More
• Compact design enables maximum operator
maneuverability and versatility
• Hand guard protects operators hand
during operation
• Lock-off button prevents accidental startup
• Electric brake stops chain within
0.5 seconds for added safety
4-1/2˝ Chainsaw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Guide Bar Length
4-1/2˝ (115 mm)
Chain Pitch / Gauge
1/4˝ / .050”
Chain Speed
980 FPM (300 m/min)
Overall Length
16-5/8˝ (422 mm)
Net Weight
4.2 lbs (1.9 kg)
Electric Brake
DCL500Z
Cyclone Vacuum Cleaner
High Efficiency, Portable Cyclone Vacuum Cleaner
• Removable cyclonic dust canister separates coarse and fine dust to ensure expelled air is
virtually dust free
• Filter offers maximum performance for residential and commercial applications
• Filter cleaning feature clears particulate and debris from clogged filter to maximize filter efficiency
and maintain suction power
• Removable dust canister can be
emptied quickly and eaisly for
minimal downtime
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Air Flow 46 CFM (1.3 m
3
/min)
Maximum Sealed Suction (water lift)
6.6 kPa (660 mm H
2
O)
Maximum Capacity 0.53 Pints (250 ml)
Suction Power (high mode)
75 W
Overall Dimensions (L x W x H)
12-5/8˝ x 7-7/16˝ x 9-7/8˝
(322 mm x 189 mm x 252 mm)
Net Weight
7.1 lbs (3.2 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
PSuction HoseAssembly (SH00000034), Floor NozzleAssembly (SH00000058),
Screw PipeAssembly (SH00000060), Hose Hook (SH00000041),Turbine Crevice Nozzle (SH00000042), Shoulder Harness (166124-3)
2-Speed
DCL182Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
NozzleAssembly (122859-6), Pipe (451244-9), Sash Nozzle (451243-1),
Sash Nozzle Holder (451245-7), Paper Filter Set 5/Pk (194566-1)
Incorporates Makita's Battery Protection System, Lightweight And
Portable Vacuum Cleaner For Shop, Office Or Home Use
• Battery Protection System provides Over-Discharge, Temperature and Current Protection for
enhanced performance, battery cycle life and overall battery life
• Push Button Air Volume Selection (Low / High Settings)
• Improved Front Cover opens with push button for easier access
• On Board Sash Nozzle Storage
• Improved Floor Nozzle Swivel Joint for
easier maneuverability
2-Speed
330 ml Vacuum Cleaner
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacity
0.6 pints (330 ml)
Maximum Air Flow:
Low
27.2 CFM
High
37.8 CFM
Overall Length with Straight Pipe and Nozzle
39-1/2˝ (1,004 mm)
Net Weight
3.5 lbs (1.6 kg)
DUR181Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Nylon Cord
(195864-6), Bump & Feed Spool Set (195858-1), BandAssembly
(125516-5), Safety Cover (453353-0), Safety Goggles (195246-2)
Well Balanced Design With Fully Adjustable Features To Suit Any Operator
• Adjustable Trimmer Head features 5 angled cutting positions for maximum versatility and ease
of operation when trimming around obstacles
• Telescopic Shaft adjusts quickly and easily to suit any operator
• Lock-Off Safety Lever prevents accidental start up
• Battery Capacity Warning Light indicates low battery capacity
10-1/4˝ Line Trimmer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
No Load Speed
7,800 RPM
Cutting Width
10-1/4˝ (260 mm)
Overall Length
56-1/2˝ (143 cm)
Net Weight
5.5 lbs (2.5 kg)
For
ACCESSORIES
see pages 161 - 162
For
ACCESSORIES
see page 167
When
QUALITY & SERVICE
Counts – Choose Makita
Replacement Nylon
Cutting Line 195864-6 (49')
or 195861-2 (98')
180°
Trimmer Head
rotates 180°
to enable easy
edge trimming
Compact design enables
maximum operator
maneuverability and versatility
