When

QUALITY & SERVICE

Counts – Choose Makita

5 Position Adjustable Rear Handle for

Vertical or Angle Trimming

• 28-3/4" Cutting Length with 3 Edge Tooth Design and High Anti-Abrasion Coated Surface for Stain Free Long Lasting Operation

• Double Sided Stainless Steel Blades for Extended Life, Clean Trimming and Cutting on Both Sides of Blade

• Extended 50 Hour Long Life Gear Case Lubrication System

offers Minimal Service Maintenance by circulating grease in

the gear housing.

• 5 Position Adjustable Rear Handle for Vertical or Angle Trimming

• Anti-vibration design for Less Operator Fatigue

• Forward Facing Exhaust redirects away from the operator

SPECIFICATIONS

Displacement

22.2 cc

Maximum Engine Power

0.68 kW / 0.91 hp

Cutting Length

28-3/4˝ (728 mm)

Carburetor

Diaphragm type

Fuel / Oil Mixture

50:1

Fuel Tank Capacity

400 ml

Overall Length

49-1/2˝ (1,259 mm)

Net Weight

11.4 lbs (5.2 kg)

STANDARD EQUIPMENT INCLUDES:

Two Shear Blades, Blade Cover (454277-3), End Cover Set (196969-5),

Tool Set (195259-3), Starter Rope (444028-2), Spark Plug (0650109950)

EH7500W

28-3/4

/ 22.2 cc 2-Stroke Hedge Trimmer

EH7500W

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Shear BladeAssembly Set (196689-1), Blade Cover (450490-1)

Reduced Noise And Emissions Versus

Competitive Gas Models

• Accepts two x 18V Li-Ion batteries without a battery converter

for use with existing 18V Li-Ion battery platform

• eXtreme Protection Technology (XPT) offers

maximum protection against dust, debris and liquids

for optimal performance in extreme conditions

• Electric brake stops blade 3-5 seconds after

trigger is released for increased operator safety

• Battery capacity warning light indicates

approximate remaining battery power

• 5 position rotating rear handle with

positive stops at 0

, 45

and 90

enables optimal positioning

when cutting vertical

or angled hedges

25-1/2˝ / 18Vx2 LXT Cordless Hedge Trimmer

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

Strokes Per Minute (min-1)

1,000 - 1,800 SPM

Cutting Length

25-1/2˝ (650 mm)

Maximum Cutting Thickness

11/16˝ (18 mm)

Overall Length

48-1/2˝ (123 cm)

Net Weight

8.9 lbs (4.0 kg)

DUH651Z

Dual Blade Action

DUH523Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Blade Cover (453723-3), Shear Blade Complete Set (195846-8)

Designed for Maximum Versatility and Ease of Operation

• Battery Protection System provides Over-Discharge, Temperature

and Current Protection for enhanced performance,

battery cycle life and overall battery life

• Anti-Vibration Structure features five cushions

linking handle and motor sections for significantly

reduced vibration transmission to operator

• Non-Electrolyzed Nickel Plated Blades

reduce staining and rusting

• Tool-less Blade Changing System enables

simple and easy blade changes

• Ergonomic Soft Rubber Grip design for vibration

absorption and comfortable operation

22˝ / 18V LXT Cordless Hedge Trimmer

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Strokes Per Minute (min-1)

1,350 SPM

Cutting Length

22˝ (560 mm)

Maximum Cutting Thickness

15/32˝ (12 mm)

Overall Length

38˝ (96 cm)

Net Weight

6.0 lbs (2.7 kg)

Dual Blade Action

28-3/4˝ Bar

(728 mm)

STANDARD EQUIPMENT INCLUDES:

Two Shear Blades, Blade Cover (452327-8), End Cover Set (196969-5),Tool Set (195259-3),

Starter Rope (444028-2), Spark Plug (0650109950)

5 Position Adjustable Rear Handle for

Vertical or Angle Trimming

• 23-1/8" Cutting Length with 3 Edge Tooth Design

and High Anti-Abrasion Coated Surface for

Stain Free Long Lasting Operation

• Double Sided Stainless Steel Blades for

Extended Life, Clean Trimming and Cutting

on Both Sides of Blade

• Extended 50 Hour Long Life Gear Case

Lubrication System offers Minimal Service

Maintenance by circulating grease in the

gear housing.

• 5 Position Adjustable Rear Handle for

Vertical or Angle Trimming

• Anti-vibration design for Less

Operator Fatigue

• Forward Facing Exhaust

redirects away from

the operator

23-1/8˝ / 22.2 cc 2-Stroke Hedge Trimmer

SPECIFICATIONS

Displacement

22.2 cc

Maximum Engine Power 0.68 kW / 0.91 hp

Cutting Length

23-1/8˝ (588 mm)

Carburetor

Diaphragm type

Fuel / Oil Mixture

50:1

Fuel Tank Capacity

400 ml

Overall Length

44˝ (1,119 mm)

Net Weight

11.0 lbs (5.0 kg)

EH6000W

STANDARD EQUIPMENT INCLUDES:

Two Shear Blades, Blade Cover (454279-9), End Cover Set (196969-5),Tool Set (195259-3),

Starter Rope (444028-2), Spark Plug (0650109950)

5 Position Adjustable Rear Handle for

Vertical or Angle Trimming

• 19" Cutting Length with 3 Edge Tooth Design

and High Anti-Abrasion Coated Surface for

Stain Free Long Lasting Operation

• Double Sided Stainless Steel Blades for

Extended Life, Clean Trimming and Cutting

on Both Sides of Blade

• Extended 50 Hour Long Life Gear Case

Lubrication System offers Minimal Service

Maintenance by circulating grease in the

gear housing.

• 5 Position Adjustable Rear Handle for

Vertical or Angle Trimming

• Anti-vibration design for Less

Operator Fatigue

• Forward Facing Exhaust

redirects away from

the operator

19˝ / 22.2 cc 2-Stroke Hedge Trimmer

SPECIFICATIONS

Displacement

22.2 cc

Maximum Engine Power 0.68 kW / 0.91 hp

Cutting Length

19˝ (483 mm)

Carburetor

Diaphragm type

Fuel / Oil Mixture

50:1

Fuel Tank Capacity

400 ml

Overall Length

40˝ (1,014 mm)

Net Weight

10.5 lbs (4.8 kg)

EH5000W

Position

Handle
