Ergonomic Soft Rubber Grip For Vibration Absorption
And Comfortable Operation
Three switches are installed in handle, front grip and sub grip
• 2-hand operation switch–motor will run only when grips are held with both hands
• Guard is provided at the tip of blades to prevent kick-back
• Blades are coated particularly to improve durability
• Built in clutch for safety
• Easy blade replacement
• Powerful 550W Motor
• Protection of extension cord from breakage
SPECIFICATIONS
Strokes Per Minute
1,600 SPM
AMPS (120V)
4.8 A
UH6570:
Overall Length 40-1/2˝ (103 cm)
UH6570:
Net Weight
3.8 lbs (8.4 kg)
UH5570:
Overall Length 40-1/2˝ (103 cm)
UH6570:
Net Weight
3.7 lbs (8.2 kg)
STANDARD EQUIPMENT INCLUDES:
Cord Holder Complete Set (194677-2), Hook Complete Set(158024-1), Blade Cover (450490-1),
Shear BladeAssembly Set (194669-1)
UH6570
STANDARD EQUIPMENT INCLUDES:
Cord Holder Complete Set (194677-2), Hook Complete Set(158024-1), Blade Cover (450490-1),
Shear BladeAssembly Set (194665-9)
UH5570
25-1/2˝ Bar
(650 mm)
21-5/8˝ Bar
(550 mm)
UH6570, UH5570
Electric Hedge Trimmers
Electric Brake
EN5950SH
STANDARD EQUIPMENT INCLUDES:
HedgeTrimmer HeadAssy (126281-9), Blade Cover (454278-1), Box Driver (782233-6), Hex Wrench 4 (783223-2),
Starter Rope (444023-2), Spark Plug (168534-0), Oil Set,Accessory Bag (831304-7)
Short Shaft Style Ideal For Vertical Cutting of Tall Hedges and Shrubs
Complies with CARB Tier 3, EPA Phase 2, EU Stage 2 Emissions Requirements
• Multi-position engine lubrication system allows Makita 4-Stroke Pole Hedge Trimmers to be operated at
any angle for maximum vertsaility
• Fixed hedge trimmer head ideal for use in vertical
cutting applications
• 23-1/4
˝
double-sided blades for fast, versatile
cutting of hedges and shrubs
• Wide trigger control and soft rubber grip design for
comfortable operation
23-1/4˝ / 25.4 cc 4-Stroke Short Shaft Pole Hedge Trimmer
SPECIFICATIONS
Displacement
25.4 cc
Maximum Engine Power 0.77 Kw / 1.1 hp
Cutting Length
23-1/4˝ (590 mm)
Carburetor
Diaphragm Type
Fuel Tank Capacity
0.6 L
Overall Length
70˝ (171 cm)
Net Weight
13.2 lbs (6.0 kg)
EN4950H
STANDARD EQUIPMENT INCLUDES:
HedgeTrimmer HeadAssy (135784-2), Blade Cover (452328-6), Box Driver (782233-6), Hex Wrench 4 (783223-2),
Starter Rope (444023-2), Spark Plug (168534-0), Oil Set,Accessory Bag (831304-7)
Long Shaft Style Ideal For Reaching Tall Hedges Or Shrubs
Complies with CARB Tier 3, EPA Phase 2, EU Stage 2 Emissions Requirements
• Multi-position engine lubrication system allows Makita 4-Stroke Pole Hedge
Trimmers to be operated at any angle for maximum vertsaility
• 135
°
hedge trimmer head articulation (-90
°
- 45
°
)
with 13 positive stops (11.25
°
increments)
• Pin style angle securing system provides
added retention at positive stop angles
versus fricton securing systems
• Hedge trimmer blades fold up to
180
°
to provide compact size during
transport or storage
19-1/4˝ / 25.4 cc 4-Stroke Long Shaft Pole Hedge Trimmer
SPECIFICATIONS
Displacement
25.4 cc
Maximum Engine Power 0.77 Kw / 1.1 hp
Cutting Length
19-1/4˝ (490 mm)
Carburetor
Diaphragm Type
Ignition System
Electronic
Fuel Tank Capacity
0.6 L
Overall Length
100-3/8˝ (255 cm)
Net Weight
15.2 lbs ( 6.9 kg)
EY2650H25H
STANDARD EQUIPMENT INCLUDES:
Chain (196142-7), 10˝ Guide Bar (165695-7), Chain Cover (452093-7), Shoulder Harness (125516-5), Box Driver (782233-6), Driver (783020-6),
Hex Wrench 4 (783223-2), Oil Supply, Safety Goggles (195246-2),Accessory Bag (831304-7), Starter Rope (444023-2), Spark Plug (168534-0)
Specialized Saw for Limbing / Pruning in High Reach Areas
• Environment-Freindly MM4 / 4-Stroke Engine in compliance with:
CARB Tier 3, EPA Phase 2 and EU Stage 2 Regulations
• Telescoping shaft easily adjusts from 8 ft. to 13 ft. allowing access
to hard-to-reach branches
• Weighs only 16.0 lbs. with reduced cutting head weight
for improved balance and reduced operator fatigue
• Heavy duty dual-stage air filter with large sealing
areas is easily accessible
• Translucent bar oil tank with adjustable
automatic chain lubrication for
efficient operation
• Engine oil filling port and drain
plug are easily accessible
for fast oil changes
8´ to 13´ / 25.4 cc 4-Stroke 10˝ High Reach Pole Chainsaw
SPECIFICATIONS
Displacement
25.4 cc
Chain Pitch / Gauge
3/8˝ / . 050˝
Maximum Engine Power 0.77 Kw / 1.1 hp
Maximum Engine Speed 10,000 RPM
Cutting Length
10˝ (255 mm)
Carburetor
Diaphragm Type
Fuel Tank Capacity
600 ml
Oil Tank Capacity
120 ml
Overall Length
154-1/2˝ (272 cm)
Net Weight
16 lbs ( 7.2 kg)
Makita offers a wide variety of
ACCESSORIES!
LUBRICATING MAINTENANCE GREASE
FOR HEDGE TRIMMERS
Description Type
For Models
Contents
Part No.
Lubricating
Grease
SG 2
EN401MP, EN420MP
EN4950H, EN5950SH
80g
197439-7
Service Gear
Assembly Every
25 Hours
See Power Tool
Instruction Manual
For Details
197439-7
For Gear
Assembly
Multi-Position Engine
Lubrication System
