STANDARD EQUIPMENT INCLUDES:
PinEnd 15TPIScrollSawBlade (351011-000),HexWrenchM3 (040005-003),
HexWrenchM4 (040006-001),BladeChangeRod (040026-001)
Accepts Pin End And Plain Type Scroll Saw Blades
• Bevel Cuts up to 45° Left and 15° Right
• Blade Tension Lever enables quick adjustment of blade tension
• Cast Iron Base provides stability and enables vibration-free cutting
SPECIFICATIONS
Blade Type
Plain or Pin End
Blade Length
5" (127 mm)
Maximum Capacities:
Length Of Stroke
7/8" (22.2 mm)
Throat
16" (406.4 mm)
Thickness Of Cut
2" (50.8 mm)
Strokes Per Minute
400 - 1,600 SPM
AMPS (120V)
1.2 A
Table Size
14-3/4" x 9-3/8" (365 mm x 238 mm)
Net Weight
31.1 lbs (14.1 kg)
SJ401
Scroll Saw
Variable
Speed
STANDARD EQUIPMENT INCLUDES:
4" CTCutter Blade 6T (A-95118),Angle Guide (123148-2), Dust Bag (123150-5),
Lock Nut Wrench 20 (782401-1), Set Plate (415579-2), Plastic Carrying Case (821509-7)
Lightweight And Compact Design With Enhanced
Ergonomics For Maximum Maneuverability
• Depth Adjustment Knob enables quick adjustment
for #0, #10 and #20 biscuits
• Rack-and-Pinion Angle Guide enables precise
adjustment of fence
• Cast Aluminum Adjustable Fence with positive
stops at 0°, 45° and 90°
SPECIFICATIONS
Blade Diameter
4" (100 mm)
Maximum Cutting Depth
3/4" (20 mm)
No Load Speed
11,000 RPM
AMPS (120V)
5.6 A
Overall Length
11-7/8" (302 mm)
Net Weight
5.6 lbs (2.5 kg)
PJ7000
4" Plate Joiner
PLATE JOINERBISCUITS
Size
Material
Dimensions
For
Model
100 / Pk
Part No.
#0
Biscuit
Compressed
Beechwood
5/8" x 1-7/8"
3901
PJ7000
DPJ180
441001A
#10
Biscuit
3/4" x 2-1/8"
441002A
#20
Biscuit
15/16" x 2-1/4"
441003A
WHEEL SANDERABRASIVEWHEELS
Description
Grit
Application For Model Part No.
Slit Paper
Wheel
40G
Sanding
9741
794380-1
Wire Brush
Wheel
-
Metal Finishing
794382-7
Cotton Buff
Wheel
-
Polishing
794381-9
Nylon Brush
Wheel
80G Coarse Sanding
794384-3
100G Medium Sanding
794379-6
240G Fine Sanding
794383-5
Unique Design - Fast, Easy And Controlled Operation
• Fast and efficient paint and rust removal
• Well balanced design with a low center of
gravity and large front
loop handle for
easy handling
SPECIFICATIONS
Wheel Size
3-15/16" x 4-23/32" (100 mm x 120 mm)
No Load Speed
3,500 RPM
AMPS (120V)
7.8 A
Overall Length
12-1/4˝ (310 mm)
Net Weight
9.3 lbs (4.2 kg)
4-3/4" Wheel Sander
9741
STANDARD EQUIPMENT INCLUDES:
Joint (P-80014),Two Hex Wrenches 6 (783204-6), Nylon Brush Wheel 120-100 (794379-6)
Perfect For Timber Framing And Log Home Building
• Cuts lap joints up to 5-1/8˝
• Notches or cuts holes in thick wood stock quickly
cleanly and accurately
• Quick horizontal chain lever for widening holes
SPECIFICATIONS
Capacities:
Max. Hole Width:
(Longitudinal)
5-1/8" (130 mm)
Max. Hole Width:
(Transverse)
1-1/4" (31.5 mm)
Max. Hole Depth
6-1/8" (155 mm)
No Load Speed
3,200 RPM
AMPS (120V)
10.5 A
Dimensions
20-1/8" x 11-3/4" x 20-1/4"
(512 mm x 298 mm x 513 mm)
Net Weight
38.1 lbs (17.3 kg)
Chain Mortiser
STANDARD EQUIPMENT INCLUDES:
5/8" Cutting Chain (A-16570), Chain BarAssy (133571-3),
Wrench 13-17 (781204-0), Oil Supply (182229-1)
7104L
CHAINMORTISERACCESSORIES
Part No.
Description
Dimensions For Model
122235-4
Chain Bar for 30 mm Gauge Chain
-
7104L
133571-3 Chain Bar Assembly for All Other Gauge Chain
-
123028-2
Sharpening Holder Assembly
-
221502-5
Chain Sprocket
1-3/16" / 30 mm
A-16564
Cutter Chain
9/16" / 15 mm
A-16570
5/8" / 16.5 mm
A-16586
11/16" / 18 mm
A-16592
51/64" / 21 mm
A-16601
15/16" / 24 mm
A-16617
1-3/16" / 30 mm
