General Catalogue

Electric

Power Tools

makita.ca

123

When

QUALITY&SERVICE

Counts – ChooseMakita

STANDARD EQUIPMENT INCLUDES:

Straight Side Handle Incl. Depth Gauge (135209-6), Bit Grease (194683-7), Plastic Carrying Case (824798-3)

SDS-MAX Shank

Hammer & Rotation / Hammer Only

• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection

• 12 Angle Bit Positions enable chisels to be positioned at optimum angle of operation

• One-Touch Sliding Chuck for easy bit installation and removal

• Ergonomic Soft Rubber Grip for vibration absorption and comfortable operation

1-9/16" Rotary Hammer

SPECIFICATIONS

Bit Type

SDS-MAX

Maximum Capacities:

Concrete (TCT)

1-9/16" (40 mm)

Concrete (Core Bit) 4-1/8" (105 mm)

No Load Speed

680 RPM

Blows Per Minute

2,500 BPM

Impact Energy

6.2 J (4.6 ft.lbs)

AMPS (120V)

10.0 A

Overall Length

18" (458 mm)

Net Weight

14.6 lbs (6.6 kg)

HR4002

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

SDS-PLUS Shank

Hammer & Rotation / Hammer Only / Rotation Only

• Anti-Vibration Technology (AVT

) actively counteracts vibration of tool for greatly reduced transmission to operator

• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection

• Constant Speed Control maintains constant speed under heavy load

• Soft Start feature gradually increases speed to eliminate start up shock

• Variable Speed Dial allows operator to adjust speed based on materials or application

• 24 Angle Bit Positions enable chisels to be positioned at optimum angle of operation

• One-Touch Sliding Chuck for easy bit installation and removal

STANDARD EQUIPMENT INCLUDES:

Bit Grease (194683-7), Side Handle (135197-7),

Depth Gauge(321248-4),

Plastic Carrying Case (824825-6)

HR3210C

STANDARD EQUIPMENT INCLUDES:

BitGrease (194683-7),SideHandle (135197-7),

DepthGauge (321248-4),

QuickChangeDrillChuck (194568-7),

PlasticCarryingCase (824825-6)

HR3210FCT

HR3210C, HR3210FCT

1-1/4" Rotary Hammers

Constant Speed Control,

Variable Speed,

Soft Start

SPECIFICATIONS

Bit Type

SDS-PLUS

Maximum Capacities:

Concrete (TCT)

1-1/4" (32 mm)

Concrete (Core Bit)

3-1/2" (90 mm)

No Load Speed

315 - 630 RPM

Blows Per Minute

1,650 - 3,300 BPM

Impact Energy

5.5 J (4.1 ft. lbs)

AMPS (120V)

8.2 A

HR3210C:

Overall Length

15-5/8" (398 mm)

Net Weight

11.5 lbs (5.2 kg)

HR3210FCT:

Overall Length (with SDS-PLUS Chuck) 16-3/4" (424 mm)

Net Weight

11.9 lbs (5.4 kg)

With

Quick Change

Drill Chuck

194568-7

STANDARD EQUIPMENT INCLUDES:

HR2811F:

Side Handle (158057-6), Depth Gauge (324219-0), Plastic Carrying Case (824789-4)

HR2811FT:

Side Handle (158057-6), Depth Gauge (324219-0), Quick Change Drill Chuck (194079-2), Plastic Carrying Case (824789-4)

SDS-PLUS Shank

Hammer & Rotation / Hammer Only / Rotation Only

• Compact L-Shaped Motor Housing for high

maneuverability and better handling

• Torque Limiter stops bit rotation if bit jams

for increased operator safety and enhanced

tool protection

Variable Speed,

Reversible

1-1/8" Rotary Hammers

SPECIFICATIONS

Bit Type

SDS-PLUS

Maximum Capacities:

Concrete

1-1/8" (28 mm)

Steel

1/2" (13 mm)

Wood

1-1/4" (32 mm)

No Load Speed

0 - 1,100 RPM

Blows Per Minute

0 - 4,500 BPM

Impact Energy

2.9 J (2.1 ft. lbs)

AMPS (120V)

7.0 A

HR2811F:

Overall Length

12-5/8" (320 mm)

Net Weight 7.7 lbs (3.5 kg)

HR2811FT:

Overall Length

(with SDS-PLUS Chuck)

13-5/8" (345 mm)

Net Weight 7.9 lbs (3.6 kg)

HR2811F

HR2811FT

STANDARD EQUIPMENT INCLUDES:

Straight Side Handle (123138-5), D-Style Side Handle (196792-8), Cleaning Cloth (443122-7), Depth Gauge (331955-1),

Bit Grease (194683-7), Plastic Carrying Case (141976-3)

SDS-MAX Shank

Hammer & Rotation / Hammer Only

• Incorporates both trigger and locking switches for ease of operation in

intermittent drilling and prolonged demolition applications

• Constant speed control maintains constant speed under heavy load

• Torque limiter stops bit rotation if bit jams for increased operator safety and tool protection

• Soft start feature gradually increases speed to eliminate start up shock

• Variable speed dial allows operator to adjust speed based on materials or application

• Auto-shut off carbon brushes shut off motor when carbon brushes require replacement

1-9/16" Rotary Hammer

SPECIFICATIONS

Bit Type

SDS-MAX

Maximum Capacities:

Concrete (TCT)

1-9/16" (40 mm)

Concrete (Core Bit) 4-1/8" (105 mm)

No Load Speed

250 - 500 RPM

Blows Per Minute 1,450 - 2,900 BPM

Impact Energy

11.4 J (8.4 ft. lbs)

AMPS (120V)

11.0 A

Overall Length 18-11/16" (479 mm)

Net Weight

13.8 lbs (6.2 kg)

HR4003C

Variable Speed,

Constant Speed Control,

Soft Start

STANDARD EQUIPMENT INCLUDES:

Straight Side Handle (158131-0), Depth Gauge (321248-4), Plastic Carrying Case (158257-8)

Spline Shank

Hammer & Rotation / Hammer Only

• Constant speed control maintains constant speed under heavy load

• Torque limiter stops bit rotation if bit jams for increased operator safety and tool protection

• Soft start feature gradually increases speed to eliminate start up shock

• Variable speed dial allows operator to adjust speed based on materials or application

• Auto-shut off carbon brushes shut off motor when carbon brushes require replacement

• No load motor suppression limits vibration and bit deflection when idling

• Ergonomic soft rubber grip design for vibration absorption and comfortable operation

1-9/16" Rotary Hammer

SPECIFICATIONS

Bit Type

Spline

Maximum Capacities:

Concrete (TCT)

1-9/16" (40 mm)

Concrete (Core Bit) 4-5/8" (118 mm)

No Load Speed

230 - 460 RPM

Blows Per Minute 1,300 - 2,600 BPM

Impact Energy

9.2 J (6.8 ft. lbs)

AMPS (120V)

10.0 A

Overall Length

16-7/8" (428 mm)

Net Weight

14.8 lbs (6.7 kg)

HR4041C
