122 / 220
HM1214C
HAMMERS
makita.ca
120
STANDARD EQUIPMENT INCLUDES:
Bit Grease (194683-7), Side Handle (135332-7), Cleaning Cloth (443122-7), Plastic Carrying Case (824904-0)
SDS-MAX Shank
• Anti-Vibration Technology (AVT
TM
) actively counteracts vibration of tool for greatly reduced
transmission to operator
• Constant Speed Control maintains constant speed under heavy load
• Soft Start feature gradually increases speed to eliminate start up shock
• Variable Speed Dial allows operator to adjust speed based on materials or application
• No-Load Motor Suppression limits vibration and bit deflection when idling
• Auto-Shut Off Carbon Brushes shut off motor when carbon brushes require replacement
• Slide Style On / Off Switch for easy continuous use applications
• 12 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• One-Touch Sliding Chuck for easy bit installation and removal
Constant Speed Control,
Variable Speed, Soft Start
12 lbs Demolition Hammer
SPECIFICATIONS
Bit Type
SDS–MAX
Blows Per Minute 1,100 - 2,650 BPM
Impact Energy
11.6 J (8.6 ft. lbs)
AMPS (120V)
10.0 A
Overall Length
18-3/8" (466 mm)
Net Weight
12.3 lbs (5.6 kg)
HM0871C
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
Bit Grease (194683-7), Side Handle (135332-7), Cleaning Cloth (443122-7), Plastic Carrying Case (824904-0)
SDS-MAX Shank
• Constant Speed Control maintains constant speed under heavy load
• Soft Start feature gradually increases speed to eliminate start up shock
• Variable Speed Dial allows operator to adjust speed based on materials or application
• No-Load Motor Suppression limits vibration and bit deflection when idling
• Auto-Shut Off Carbon Brushes shut off motor when carbon brushes require replacement
• Slide Style On / Off Switch for easy continuous use applications
• 12 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• One-Touch Sliding Chuck for easy bit installation and removal
• LED Service Light indicates appropriate time to change carbon brushes
• LED Power Light indicates active power supply
Constant Speed Control,
Variable Speed, Soft Start
11 lbs Demolition Hammer
SPECIFICATIONS
Bit Type
SDS–MAX
Blows Per Minute 1,100 - 2,650 BPM
Impact Energy
11.4 J (8.4 ft. lbs)
AMPS (120V)
10.0 A
Overall Length
17-3/4" (449 mm)
Net Weight
11.1 lbs (5.1 kg)
HM0870C
Makita offers a wide variety of
ACCESSORIES!
STANDARD EQUIPMENT INCLUDES:
D-Style Side Handle (134890-0), SDS-MAX Bull Point (751423-A),
Bit Grease (194683-7), Cleaning Cloth (443122-7), Plastic Carrying Case (140561-9)
SDS-MAX Shank
• Anti-Vibration Technology (AVT
TM
) actively counteracts vibration of tool for greatly reduced
transmission to operator
• Constant Speed Control maintains constant speed under heavy load
• Soft Start feature gradually increases speed to eliminate start up shock
• Variable Speed Dial allows operator to adjust speed based on materials or application
• No-Load Motor Suppression limits vibration and bit deflection when idling
• Auto-Shut Off Carbon Brushes shut off motor when carbon brushes require replacement
• Slide Style On/Off Switch for easy continuous use applications
• 12 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• One-Touch Sliding Chuck for easy bit installation and removal
• Extra long carbon brushes for extended service life
• LED Service Light indicates appropriate time to change carbon brushes
Constant Speed Control,
Variable Speed, Soft Start
17 lbs Demolition Hammer
SPECIFICATIONS
Bit Type
SDS-MAX
Blows Per Minute 1,100 - 2,650 BPM
Impact Energy
17 J (12.5 ft. lbs)
AMPS (120V)
14.0 A
Overall Length
20-3/4" (528 mm)
Net Weight
17.3 lbs (7.8 kg)
HM1111C
STANDARD EQUIPMENT INCLUDES:
SDS-MaxBullPoint (751423-A),BitGrease (194683-7),CleaningCloth (443122-7),D-StyleSideHandle (135269-8),PlasticCarryingCase (824908-2)
SDS-MAX Shank
• Anti-Vibration Technology (AVT
TM
) actively counteracts vibration of tool for greatly reduced
transmission to operator
• Constant Speed Control maintains constant speed under heavy load
• Soft Start feature gradually increases speed to eliminate start up shock
• Variable Speed Dial allows operator to adjust speed based on materials or application
• No-Load Motor Suppression limits vibration and bit deflection when idling
• Auto-Shut Off Carbon Brushes shut off motor when carbon brushes require replacement
• Slide Style On / Off Switch for easy continuous use applications
• 12 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• One-Touch Sliding Chuck for easy bit installation and removal
• LED Service Light indicates appropriate time to change carbon brushes
Constant Speed Control,
Variable Speed, Soft Start
24 lbs Demolition Hammer
SPECIFICATIONS
Bit Type
SDS-MAX
Blows Per Minute 950 - 1,900 BPM
Impact Energy
25.5 J (18.8 ft. lbs)
AMPS (120V)
14.0 A
Overall Length
22-3/4" (576 mm)
Net Weight
23.8 lbs (10.8 kg)
HM1213C
STANDARD EQUIPMENT INCLUDES:
SDS-MAXBullPoint (751423-A),BitGrease (194683-7),CleaningCloth (443122-7),D-StyleSideHandle (135283-4),PlasticCarryingCase (824882-4)
SDS-MAX Shank
• Anti-Vibration Technology (AVT
TM
) actively counteracts vibration of tool for greatly reduced
transmission to operator
• Constant Speed Control maintains constant speed under heavy load
• Soft Start feature gradually increases speed to eliminate start up shock
• Variable Speed Dial allows operator to adjust speed based on materials or application
• No-Load Motor Suppression limits vibration and bit deflection when idling
• Auto-Shut Off Carbon Brushes shut off motor when carbon brushes require replacement
• Slide Style On / Off Switch for easy continuous use applications
• 12 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• One-Touch Sliding Chuck for easy bit installation and removal
• LED Service Light indicates appropriate time to change carbon brushes
Constant Speed Control,
Variable Speed, Soft Start
27 lbs Demolition Hammer
SPECIFICATIONS
Bit Type
SDS-MAX
Blows Per Minute 950 - 1,900 BPM
Impact Energy
26.0 J (19.2 ft. lbs)
AMPS (120V)
14.0 A
Overall Length
27-1/2" (700 mm)
Net Weight
27.1 lbs (12.3 kg)
HM1214C
