123 / 220
Electric
Power Tools
makita.ca
121
When
QUALITY&SERVICE
Counts – ChooseMakita
STANDARD EQUIPMENT INCLUDES:
SDS-PLUS Scaling Chisel (A-87052), Plastic Carrying Case (824523-2)
SDS-PLUS Shank
• Ideal for removing tile, linoleum, cleaning out mortar or detailed chiseling
• Factory Grease Packed for maintenance free operation
• Variable Speed Dial allows operator to adjust speed based on materials or application
• One-Touch Sliding Chuck for easy bit installation and removal
• 12 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
Variable Speed
Power Scraper
SPECIFICATIONS
Bit Type
SDS-PLUS
Blows Per Minute
2,000 - 3,500 BPM
Impact Energy
2.8 J (2.1 ft. lbs)
AMPS (120V)
5.0 A
Overall Length
18-13/32" (468 mm)
Net Weight
7.1 lbs (3.2 kg)
HK0500
STANDARD EQUIPMENT INCLUDES:
Hex Wrench 4 (783202-0), Straight Side Handle (273472-4), D-Style Side Handle (134887-9), Plastic Carrying Case (150589-9)
Spline or 3/4˝ Hex, 21/32˝ Round Shank
Hammer & Rotation / Hammer Only
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Large Comfortable Grip swivels 360° for easy handling
• Factory Packed Grease for reduced maintenance
• Auto-Shut Off Carbon Brushes shut off motor when carbon brushes require replacement
2" Rotary Hammer
SPECIFICATIONS
Bit Type:
Spline Shank
3/4" Hex, 21/32" Round
Maximum Capacity:
Concrete (TCT)
2" (50 mm)
Concrete (Core Bit)
5-7/8" (150 mm)
No Load Speed
260 RPM
Blows Per Minute
2,100 BPM
Impact Energy
11.8 J (8.7 ft. lbs)
AMPS (120V)
11.0 A
Overall Length
18-3/4" (476 mm)
Net Weight
21.8 lbs (9.9 kg)
HR5000
SDS-PLUS Shank
• Auto-Shut Off Carbon Brushes shut off motor when carbon brushes require replacement
• Factory Grease Packed for approximately 200 hours of maintenance free operation
• Variable Speed Dial allows operator to adjust speed based on materials or application
• One-Touch Sliding Chuck for easy bit installation and removal
• 12 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• Vibration Absorbing Handle with Ergonomic Soft Rubber Grip for vibration absorption
and comfortable operation
• Rear Extension Handle and Wheel Assembly ideal for scraping floor tiles, linoleum, etc.
from a standing position (HK1820L Only)
SPECIFICATIONS
Bit Type
SDS-PLUS
Blows Per Minute
0 - 3,200 BPM
AMPS (120V)
5.0 A
HK1820:
Impact Energy
3.9 J (2.9 ft. lbs)
Overall Length
13-3/4" (351 mm)
GD0800C
Net Weight
7.5 lbs (3.4 kg)
HK1820L:
Impact Energy
3.7 J (2.7 ft. lbs)
Overall Length
51.0" (1.3 m)
Net Weight
11.7 lbs (5.3 kg)
HK1820, HK1820L
Power Scrapers
Variable Speed
STANDARD EQUIPMENT INCLUDES:
Cord Hook (158024-1),
Plastic Carrying Case (824789-4)
HK1820
STANDARD EQUIPMENT INCLUDES:
Hex Wrench 5 (783203-8)
(Shown with Optional Scraping BladeAssembly)
HK1820L
Rear Extension Handle
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
SDS-MAX Shank
Hammer & Rotation / Hammer Only
• Low noise and vibration level for maximum operator comfort and safety
• Advanced Anti-Vibration Technology (AVT
TM
) system incorporates vibration absorbing housing,
active dynamic vibration absorber and damper spring to actively counteract the vibration
of the tool for greatly reduced transmission to the operator
• Incorporates both trigger and locking switches for ease of operation
in intermittent drilling and prolonged demolition applications
SPECIFICATIONS
Bit Type
SDS-MAX
Maximum Capacities:
Concrete (TCT)
2-1/16" (52 mm)
Concrete (Core Bit) 6-5/16" (160 mm)
No Load Speed
150 - 310 RPM
Blows Per Minute
1,100 - 2,250 BPM
Impact Energy
21 J (15.5 ft.lbs)
AMPS (120V)
15.0 A
Overall Length
23-1/2" (599 mm)
Net Weight
26.2 lbs (11.9 kg)
HR5212C
2" Rotary Hammer
STANDARD EQUIPMENT INCLUDES:
BitGrease (194683-7),D-StyleSideHandle (135283-4),StraightSideHandle (135629-4),CleaningCloth (443122-7),DepthGauge (331955-1),PlasticCarryingCase (142296-8)
Highest
Impact Energy
Rating (21 J)
In-Class!
HR5212C
Variable Speed,
Constant Speed Control,
Soft Start, Soft No-Load
