HAMMERS
makita.ca
122
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Makita offers a wide variety of
ACCESSORIES!
SDS-MAX Shank
Hammer & Rotation / Hammer Only
• Anti-Vibration Technology (AVT
TM
) actively counteracts vibration of
tool for greatly reduced transmission to operator
• Torque Limiter stops bit rotation if bit jams for increased operator
safety and tool protection
• Soft Start feature gradually increases speed to eliminate start up shock
• Variable Speed Dial allows operator to adjust speed based on
materials or application
SPECIFICATIONS
Bit Type
SDS-MAX
Maximum Capacities:
Concrete (TCT)
1-3/4" (45 mm)
Concrete (Core Bit)
5" (125 mm)
No Load Speed
130 - 280 RPM
Blows Per Minute
1,250 - 2,750 BPM
Impact Energy
12.5 J (9.2 ft. lbs)
AMPS (120V)
13.5 A
Overall Length
18" (458 mm)
Net Weight
19.6 lbs (8.9 kg)
STANDARD EQUIPMENT INCLUDES:
BitGrease (194683-7),D-StyleSideHandle (135531-1),
StraightSideHandle Incl.DepthGauge (135209-6),
CleaningCloth (443122-7),DustExtractionAttachment
(196074-8),PlasticCarryingCase (196192-2)
HR4511CV
Locking Slide Switch For ChiselingApplications
(HR4510CV Only)
STANDARD EQUIPMENT INCLUDES:
BitGrease (194683-7),D-StyleSideHandle (135531-1),
StraightSideHandle Incl.DepthGauge (135209-6),
CleaningCloth (443122-7),DustExtractionAttachment
(196074-8),PlasticCarryingCase (196191-4)
HR4510CV
HR4511CV, HR4510CV
1-3/4
"
Rotary Hammers with Dust Extraction Attachment
Variable Speed, Constant Speed Control,
Soft Start
Locking Slide Switch
Trigger Switch
STANDARD EQUIPMENT INCLUDES:
Straight Side Handle (123138-5), D-Style Side Handle (196792-8), Cleaning Cloth (443122-7), Depth Gauge (331955-1),
Plastic Carrying Case (141977-1)
SDS-MAX Shank
Ultra-Low Vibration At Just 5.0 m/s For Maximum Operator Comfort and Safety!
Hammer & Rotation / Hammer Only
• Advanced Anti-Vibration Technology (AVT
TM
) system incorporates vibration absorbing housing, active
dynamic vibration absorber and damper spring to actively counteract the vibration of the tool for greatly
reduced transmission to the operator
• Incorporates both trigger and locking switches for ease of operation in
intermittent drilling and prolonged demolition applications
• Torque limiter stops bit rotation if bit jams for increased operator safety and tool protection
• Soft start feature gradually increases speed to
eliminate start up shock
1-9/16" Rotary Hammer
SPECIFICATIONS
Bit Type
SDS-MAX
Maximum Capacities:
Concrete (TCT)
1-9/16" (40 mm)
Concrete (Core Bit) 4-1/8" (105 mm)
No Load Speed
250 - 500 RPM
Blows Per Minute 1,450 - 2,900 BPM
Impact Energy
11.4 J (8.4 ft. lbs)
AMPS (120V)
11.0 A
Overall Length 18-11/16" (479 mm)
Net Weight
15.1 lbs (6.8 kg)
HR4013C
Variable Speed,
Constant Speed Control,
Soft Start
Models HR4013C, HR4003C & HR5212C
incorporate both trigger and locking
switches for ease of operation in
intermittent drilling and prolonged
demolition applications
Locking
Switch
Trigger
Switch
SDS-MAX Shank
Hammer & Rotation / Hammer Only
• Anti-Vibration Technology (AVT
TM
) actively counteracts vibration of tool for greatly reduced
transmission to operator
• Torque Limiter stops bit rotation if bit jams for increased operator safety and tool protection
• Soft Start feature gradually increases speed to eliminate start up shock
• Variable Speed Dial allows operator to adjust speed based on materials or application
• 16 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• One-Touch Sliding Chuck for easy bit installation and removal
SPECIFICATIONS
Bit Type
SDS-MAX
Maximum Capacities:
Concrete (TCT)
1-3/4" (45 mm)
Concrete (Core Bit)
5" (125 mm)
No Load Speed
130 - 280 RPM
Blows Per Minute
1,250 - 2,750 BPM
Impact Energy
12.5 J (9.2 ft. lbs)
AMPS (120V)
13.5 A
Overall Length
18" (458 mm)
Net Weight
19.6 lbs (8.9 kg)
STANDARD EQUIPMENT INCLUDES:
BitGrease (194683-7),StraightSideHandle Incl.
DepthGauge (135209-6),D-StyleSideHandle
(134890-0),CleaningCloth (443122-7),
PlasticCarryingCase (196188-3)
HR4511C
Locking Slide Switch For ChiselingApplications
(HR4510C Only)
STANDARD EQUIPMENT INCLUDES:
BitGrease (194683-7),StraightSideHandle Incl.
DepthGauge (135209-6),D-StyleSideHandle
(134890-0),CleaningCloth (443122-7),
PlasticCarryingCase (196187-5)
HR4510C
HR4511C, HR4510C
1-3/4" Rotary Hammers
Variable Speed, Constant Speed Control, Soft Start
Locking Slide Switch
Trigger Switch
