158 / 220
METALWORKING
makita.ca
156
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
6" Depressed Center Wheel (1 Ea.A-95978-25),Anti-Vibration Side Handle (194514-0), Lock Nut Wrench 28 (782412-6),
Toolless Wheel Cover (123146-6), Inner Flange (224361-6), Lock Nut 5/8-45(224568-4)
Thumb Switch with Lock-On (AC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool and operator protection
• Electronic Current Limiter prevents motor burnout due to overloading
• Soft Start feature gradually increases speed to eliminate start up shock
• Constant Speed Control maintains constant speed under heavy load
• Re-Designed Gear Housing for enhanced shaft lock durability
• Labyrinth Construction features a complex series of channels to prevent penetration of dust and debris
into the field and armature for maximum operational life
• Motor Winding Protection features "Zig-Zag" varnish on the armature and hardened powder on the field
SJS Technology, Variable Speed,
Electronic Current Limiter, Constant
Speed Control, Soft Start
6" Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
6" (150 mm)
Sanding Disc
6" (150 mm)
Diamond Wheel
6" (150 mm)
Wire Cup Brush
3-1/2" (90 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
4,000- 9,000 RPM
AMPS (120V)
12.0 A
Overall length
11-7/8" (303 mm)
Net Weight
5.8 lbs (2.6 kg)
GA6042C01
STANDARD EQUIPMENT INCLUDES:
GA6010:
Side Handle (158237-4), Lock Nut Wrench 28 (782424-9),Toolless Wheel Cover (123146-6), 6" Depressed Center Wheel
(1 Ea.A-95978-25), Inner Flange (224361-6), Lock Nut (224568-4)
GA6010Z:
Side Handle (158237-4), Lock Nut Wrench 28 (782424-9),Toolless Wheel Cover (123146-6), 6" Depressed Center Wheel
(1 Ea.A-95978-25), Lock Nut (224568-4)
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features "Zig-Zag" varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left
or right side of tool
6" Angle Grinders
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
6" (150 mm)
Sanding Disc
6" (150 mm)
Wire Cup Brush
3-1/2" (90 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
10,000 RPM
AMPS (120V)
10.5 A
Overall Length
14" (356 mm)
Net Weight
6.0 lbs (2.7 kg)
Trigger Switch with
Lock-On
Button (AC/DC)
GA6010
Trigger Switch with
No Lock-On
Button (AC/DC)
GA6010Z
Makita offers a wide variety of
ACCESSORIES!
STANDARD EQUIPMENT INCLUDES:
Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Inner Flange 82 (224361-6), Lock Nut 5/8-45(224568-4),
Toolless Wheel Cover (123146-6), 6" Depressed Center Wheel (1 Ea.A-95978-25)
Trigger Switch with Lock-On Button (AC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool and operator protection
• Electronic current limiter prevents motor burnout due to overloading
• Soft start feature gradually increases speed to eliminate start up shock
• Constant speed control maintains constant speed under heavy load
• Anti-Restart feature prevents accidental start up of tool if switch is locked in the on position
• LED Light indicates active power supply and activation of anti-restart feature
• Labyrinth construction features a complex series of channels to prevent penetration of dust and debris
into the field and armature for maximum operational life
SJS Technology,
Electronic Current Limiter,
Constant Speed Control, Soft Start
6" Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Wheel
6" (150 mm)
Sanding Disc
6" (150 mm)
Wire Cup Brush
3-1/2" (90 mm)
Spindle Thread
5/8"- 11 UNC
No Load Speed
9,000 RPM
AMPS (120V)
12.5 A
Overall Length
15-3/8" (390 mm)
Net Weight
6.6 lbs (3.0 kg)
GA6020C
STANDARD EQUIPMENT INCLUDES:
Side Handle (158237-4), Lock Nut Wrench 28 (782424-9),Tool-less Wheel Cover (123146-6), 6" Depressed Center Wheel (1 Ea. A-95978-25),
Inner Flange (224361-6), Lock Nut (224568-4), Dust CoverAttachment (194482-7)
Two Stage Safety Trigger Switch (AC/DC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool and
operator protection
• Electric Brake for increased operator safety
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features "Zig-Zag" varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or right side of tool
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
SJS Technology, Electric Brake
6" Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
6" (150 mm)
Sanding Disc
6" (150 mm)
Wire Cup Brush
3-1/2" (90 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
10,000 RPM
AMPS (120V)
10.5 A
Overall Length
14" (356 mm)
Net Weight
6.6 lbs (3.0 kg)
GA6020Y
STANDARD EQUIPMENT INCLUDES:
Side Handle (158237-4), Lock Nut Wrench 28 (782424-9),Toolless Wheel Cover (135110-5), 6" Depressed Center Wheel (1 Ea.A-95978-25),
Inner Flange (224361-6), Lock Nut (224568-4), Dust CoverAttachment (194482-7)
Trigger Switch with No Lock-On Button (AC/DC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool and
operator protection
• Electric Brake for increased operator safety
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features "Zig-Zag" varnish on the armature and hardened powder on the field
coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or right side of tool
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
SJS Technology, Electric Brake
6" Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
6" (150 mm)
Sanding Disc
6" (150 mm)
Wire Cup Brush
3-1/2" (90 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
10,000 RPM
AMPS (120V)
10.5 A
Overall Length
14" (356 mm)
Net Weight
6.6 lbs (3.0 kg)
GA6020
STANDARD EQUIPMENT INCLUDES:
9566PC:
Side Handle (153489-2), Lock Nut Wrench 28 (782424-9),Toolless Wheel Cover (123146-6), 6" Depressed Centre Wheel
(A-95978), Inner Flange (224361-6), Lock Nut 5/8"-45 (224568-4)
9565PCV:
Side Handle (153489-2), Lock Nut Wrench 28 (782424-9),Toolless Wheel Cover (123146-6), 6" Depressed Centre Wheel
(A-95978), Inner Flange (224361-6), Lock Nut 5/8"-45 (224568-4)
Two Stage Safety Paddle Switch (AC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool
and operator protection
• Electronic current limiter prevents motor burnout due to overloading
• Soft start feature gradually increases speed to eliminate start up shock
• Constant speed control maintains constant speed under heavy load
• Labyrinth construction seals motor and bearings from contamination
• Large paddle switch for easy operation right or left handed
• Removable side handle can be mounted on left
or right side of tool
6" Angle Grinders
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
6" (150 mm)
Sanding Disc
6" (150 mm)
Diamond Wheel
6" (150 mm)
Wire Cup Brush
4" (102 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
10,000 RPM
AMPS (120V)
13.0
Overall Length
12-1/8" (307 mm)
Net Weight
5.5 lbs (2.5 kg)
9566PCV
9566PC
Variable Speed
(9566PCV Only)
SJS
Technology
