182 / 220
METALWORKING
makita.ca
180
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
9237C
STANDARD EQUIPMENT INCLUDES:
9237C:
Hookand LoopBackingPad (743052-5),HexWrench6 (783204-6),LoopHandle (455292-0),Sleeve (262542-4),SideHandle (153489-2)
9237CX1:
Hook and LoopBackingPad (743052-5),HexWrench 6 (783204-6), LoopHandle (455292-0),Sleeve (262542-4),SideHandle (153489-2),
MediumCCSFoamPolishingPad (T-01236X),SoftCCSFoamPolishingPad (T-01242X),HardCCSFoamPolishingPad (T-01220X), 21˝ToolBag (821007X)
Designed As The Premium Polisher For Professional Polishing Applications
• Variable speed dial and trigger enables operator to adjust speed based on exact polishing application
• Ideal for maximum control during slow polish applications.
• Electronic speed control maintains constant speed under load
• Soft Start feature gradually increases speed to eliminate start up shock
• Improved power cord guard protects cord against damage and excessive wear
• Soft rubber tool rest enables tool to be set down without damaging underlying materials
• Protective rubber head cover prevents damage to materials caused by impact or abrasion during operation
7" Electronic Polisher
SPECIFICATIONS
Maximum Capacities:
Sanding Disc
7" (180 mm)
Wool or Foam Polishing Pad
7" (180 mm)
No Load Speed
0 - 3,200 RPM
AMPS (120V)
10.0 A
Spindle Thread
5/8"-11 UNC
Overall Length
17" (431 mm)
Net Weight
7.5 lbs (3.4 kg)
Soft Start,
Electronic
Speed Control,
Variable Speed
9237CX1
PO5000C
STANDARD EQUIPMENT INCLUDES:
Hook & Loop Backing Pad (197923-2), Hex Wrench 5 (783203-8), Wrench Holder (410047-0)
Random Orbit (FINE) and Random Orbit with Forced Rotation (Coarse) Modes
• Ideal for compounding, polishing, waxing and buffing stages
• Angled design and power cord increases maneuverability and prevents damage to materials
• Variable speed dial and trigger enables operator to adjust speed based on exact polishing application
• Ideal for maximum control during slow polish applications.
• Electronic speed control maintains constant speed under load
• Soft Start feature gradually increases speed to eliminate start up shock
• Improved power cord guard protects cord against damage and excessive wear
• Soft rubber tool rest enables tool to be set down without damaging underlying materials
• Protective rubber head cover prevents damage to materials caused by impact or abrasion during operation
5" Electronic Polisher
SPECIFICATIONS
Pad Size
5" (125 mm)
Orbital Diameter
7/32" (5.5 mm)
No Load Speed
0 - 780 RPM
(Random orbit w/forced rotation)
AMPS (120V)
7.8 A
Overall Length
17-34" (451 mm)
Net Weight
6.2 lbs (2.8 kg)
Variable Speed,
Constant Speed
Control, Soft Start
COLLAPSEDCELL SYSTEM (CCS) FOAMPOLISHING PADS
Diameter
Density
Colour
Application Backing Pad Part No.
For Model
Part No.
5-1/2"
Soft
Black
Finishing
197923-2
PO5000C
T-02680
Medium
White
Polishing
T-02668
Hard
Orange
Cutting
T-02674
7-1/2"
Soft
Black
Finishing
743052-5
9237C
T-01242
Medium
White
Polishing
T-01236
Hard
Yellow
Cutting
T-01220
9" DOUBLE-SIDEDWOOL POLISHINGBONNETS
• Double-sided bonnets offer 2x longer life versus traditional
single-sided bonnets
• Multiple bonnet densities suitable for various applications,
including compounding and polishing
• Threaded arbour adapter allows fast and easy pad changes
without the need for centering devices
• Usable edges enable effective performance in tight spaces,
around vehicle side mirrors, door handles and more!
• Use with D-57087 5/8"-11 Adapter
• For models: 9237C / X1
Part No.
Description
Material
Max. RPM
D-57071
9" Double Wool Polishing Bonnet (Coarse)
100% Wool
4,000 RPM
D-57152
9" Double Wool Polishing Bonnet (Fine)
50% Wool / 50% Polyester
D-57087
5/8"-11 Double Wool Bonnet Adapter
-
-
Coarse
D-57071
Fine
D-57152
D-57087
9237C
Ideal for
maximum
control during
slow polish
applications!
