Air blower feature cleans material
of dust and debris
AT638A
Electric
Power Tools
makita.ca
185
When
QUALITY&SERVICE
Counts – ChooseMakita
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
Oil Supply (181434-7), Safety Glasses (A0908-0171), Wrench (A0913-0011)
1" - 2" (1" Width) 16-Gauge Staples
• 360° exhaust system directs exhaust away from operator
• Dry fire prevention prolongs tool life
• Rubber grip for comfortable handling
• Inlet Filter prevent contamination due to dust or debris
• Quick Release nose enables easy clearing of jammed nails
1" Crown Stapler
SPECIFICATIONS
Operating Air Pressure
65 - 120 PSIG
Staple Size: (L x W)
1" - 2" (1˝ Width)
Nail Type
16 ga Crown Staples
Magazine Capacity
140
Dimensions (L x W x H )
14-1/2" x 3˝" x 10-1/4"
(370 mm x 76 mm x 260 mm)
Net Weight
4.9 lbs (2.2 kg)
AT2550A
STANDARD EQUIPMENT INCLUDES:
Oil Supply (181434-7), Safety Glasses (A0908-0171), Wrench (A0913-0011)
1" - 2" (7/16" Width) 16-Gauge Staples
• 360° exhaust system directs exhaust away from operator
• Dry fire prevention prolongs tool life
• Rubber grip for comfortable handling
• Inlet Filter prevent contamination due to dust or debris
• Quick Release nose enables easy clearing of jammed nails
7/16" Crown Stapler
SPECIFICATIONS
Operating Air Pressure
65 - 120 PSIG
Staple Size: (L x W) 1" - 2" (7/16" Width)
Nail Type
16 ga Crown Staples
Magazine Capacity
140
Dimensions (L x W x H)
14-1/2" x 3-7/16" x 11-3/8"
(370 mm x 87 mm x 290 mm)
Net Weight
4.0 lbs (1.8 kg)
AT1150A
STANDARD EQUIPMENT INCLUDES:
Two NoseAdapter (HY00000378), Oil Supply, Plastic Carrying Case, Safety Goggles
18-Gauge Narrow Crown Stapler
• 2 mode - sequential & bump fire
• 360° exhaust system directs exhaust away from operator
• Air blower feature cleans material of dust and debris
• Toolless depth adjustment for quick and easy adjustment
• Quick release toolless nose enables easy clearing of jammed nails
• Contact arm design prevents accidental engagement of trigger for maximum operator safety
• High visibility slim nose tip enables precise positioning of nails
1/4" Crown Stapler
SPECIFICATIONS
Operating Air Pressure 70 - 120 PSIG
Staple Size (18 ga)
1/2" - 1-1/2" (13- 38 mm)
Magazine Capacity
100
Dimensions ( L x W x H)
9" x 2-15/16" x 9-7/8"
(230 mm x 75 mm x 251 mm)
Net Weight
2.7 lbs (1.2 kg)
AT638A
STANDARD EQUIPMENT INCLUDES:
Two NoseAdapter (HY00000561), Hex. Wrench 3 (HY00000395), Oil Supply, Plastic Carrying Case, Safety Goggles
23-Gauge Pin Nailer
• Air blower feature cleans material of dust and debris
• Double trigger design prevents accidental engagement of trigger
for maximum operator safety
• High visibility slim nose tip enables precise positioning of nails
• Anti-dry fire mechanism prevents added wear on drive pin
• Nail view window enables fast identification of remaining nail capacity
• Protective rubber bumpers guard housing against wear and damage
1-3/8" Pin Nailer
SPECIFICATIONS
Operating Air Pressure 65 - 100 PSIG
Nail Size (23 ga) 5/8" - 1-3/8" (15 - 35 mm)
Nail Type
23 ga Pin Nails
Magazine Capacity
130
Dimensions (L x W x H)
8-3/16" x 2-5/8" x 7-1/2"
(208 mm x 66 mm x 191 mm)
Net Weight
2.0 lbs (0.9 kg)
AF353
STANDARD EQUIPMENT INCLUDES:
Safety Goggles (HY00000394), Oil Supply (HY00000396), Hex Wrench 4 (HY00000211)
15° Round Head Coil Roofing Nailer
• Improved trigger valve design provides quick nail driving in bump fire mode
• Operates in bump fire & sequential fire mode
• 6 depth nailing settings with adjustment knob for maximum precision
• Tool-less shingle guide provides easy adjustments and consistent shingle placement
• Nail path magnet prevents last nail from falling out
• Convenient adjustable belt hook
• One touch easy to load magazine
• Easy to remove contact top to clear nail/debris jams
1-3/4" Coil Roofing Nailer
SPECIFICATIONS
Operating Air Pressure 70 - 120 PSIG
Nail Size
3/4 – 1-3/4" (19 - 45 mm)
Nail Type 1/8" (3.0 mm) 15° Round Head
Dimensions (L x W x H)
10-1/8" x 4-5/8" x 10-5/8"
(256 mm x 142 mm x 271 mm)
Net Weight
5.2 lbs (2.4 kg)
AN454
