STANDARD EQUIPMENT INCLUDES:
Two NoseAdapter (HY00000378), Oil Supply, Safety Goggles (HY00000951)
Features Slim Contact Tip Design For Precise Woodworking
Fastening Applications
• Slim contact tip design enables precise fastening in wood trim, crown moulding, baseboard, casing,
cabinetry and other woodworking applications!
• Air blower feature cleans material of dust and debris
• Quick release nose enables fast and easy clearing of jammed nails
• Quick release, side loading magazine holds up to 100 18-gauge brad nails
• Dual windows enable fast identification of remaining nail capacity
• Convenient, adjustable belt hook for operator convenience
2˝ Brad Nailer
SPECIFICATIONS
Operating Air Pressure 70 - 120 PSIG
Nail Size (18 ga)
5/8" - 2" (15 - 50 mm)
Nail Type
18 ga Brad Nails
Magazine Capacity
100
Dimensions (L x W x H)
9-7/8" x 2-3/4" x 10-1/8"
(250 mm x 70 mm x 256 mm)
Net Weight
2.9 lbs (1.3 kg)
AF506
Makita offers a wide variety of
ACCESSORIES!
STANDARD EQUIPMENT INCLUDES:
Two NoseAdapter (HY00000422), Oil Supply, Plastic Carrying Case, Safety Goggles
15-Gauge Finish Nailer
• 2 mode - sequential & bump fire
• 360° exhaust system directs exhaust away from operator
• Air blower feature cleans material of dust and debris
• Toolless depth adjustment for quick and easy adjustment
• Quick release toolless nose enables easy clearing of jammed nails
• Contact arm design prevents accidental engagement of
trigger for maximum operator safety
• High visibility slim nose tip enables precise positioning of nails
2-1/2" Angled Finishing Nailer
SPECIFICATIONS
Operating Air Pressure 70 - 120 PSIG
Nail Size (15 ga)
1-1/4" - 2-1/2" (32 - 64 mm)
Nail Type
15 ga Finishing Nails
Magazine Capacity
100
Dimensions (L x W x H)
13-3/8" x 3-15/16" x 12-1/8"
(339 mm x 100 mm x 309 mm)
Net Weight
4.0 lbs (1.8 kg)
AF635
STANDARD EQUIPMENT INCLUDES:
Two NoseAdapter (HY00000560), Oil Supply, Plastic Carrying Case, Safety Goggles
16-Gauge Straight Finish Nailer
• 2 mode - sequential & bump fire
• 360° exhaust system directs exhaust away from operator
• Air blower feature cleans material of dust and debris
• Toolless depth adjustment for quick and easy adjustment
• Quick release toolless nose enables easy clearing of jammed nails
• Contact arm design prevents accidental engagement of trigger for
maximum operator safety
• High visibility slim nose tip enables precise positioning of nails
2-1/2" Straight Finishing Nailer
SPECIFICATIONS
Operating Air Pressure 70 - 120 PSIG
Nail Size (16 ga) 1" - 2-1/2" (25 - 64 mm)
Nail Type
16 ga Finishing Nails
Magazine Capacity
100
Dimensions (L x W x H)
12" x 3-3/4" x 11-3/4"
(304 mm x 95 mm x 297 mm)
Net Weight
3.8 lbs (1.7 kg)
AF601
AF635
