HOWTOCONNECT:
NAILER / FITTINGS
PNEUMATIC AIR HOSE / COMPRESSOR
MALE FITTING
Nailer to Hose
FEMALE UNIVERSAL
COUPLER
Nailer to Hose
PNEUMATIC
AIR HOSE
YYRAH25
YYRAH50 / YYRAH100
YYVAH25 / YYVAH50
FEMALE FITTING
Hose to
Compressor
MALE UNIVERSAL
COUPLER
Hose to
Compressor
PNEUMATICHOSE FITTINGS
Style
Thread Type
Size
Part No.
Industrial
Male
3/8" x 1/4"
YY311014-A
3/8" x 3/8"
YY311015-A
Female
1/4" x 1/4"
YY311002-A
1/4" x 3/8"
YY311003-A
3/8" x 1/4"
YY311010-A
3/8" x 3/8"
YY311011-A
Universal Air
Coupler
Male
1/4" x 1/4" Plug
YY036003-1
Female
1/4" x 1/4"
YY311018-A
1/4" x 1/4" Plug
YY311002-X
PNEUMATICAIRHOSES
Material
Diameter
Length
Part No.
Rubber
3/8"
25'
YYRAH25
50'
YYRAH50
100'
YYRAH100
Vinyl
3/8"
25'
YYVAH25
50'
YYVAH50
PNEUMATICMAINTENANCE ACCESSORIES
Description
For Model(s)
Part No.
Air Leak
Repair Set
AN451
192393-0
AN611
193007-4
AN923, AN943
194522-1
AN942
193006-6
AN944
BA00000262
Air Compressor
Oil 0.3 L
Makita
Pneumatic
Compressors
181122-A
Air Compressor
Oil 1 L
EAOIL10
Pneumatic Oil
30cc
Makita
Pneumatic
Nailers
181434-7
Pneumatic Oil
30 ml
194381-3
GN900S
STANDARD EQUIPMENT INCLUDES:
7.2VLi-IonBattery
BL0715 (198001-1),Charger (DC07SA),PlasticCarryingCase (824875-1),SafetyGoggles (195246-2),
HexWrench4 (783230-5)
Makita's First Cordless 34° Clipped Head Framing Nailer
• Utilizes industry standard fuel cells
• Utilizes 7.2V (1.5Ah) Li-Ion Battery BL0715 with 35 minute charging time
• LED Warning System indicates low battery capacity or tool malfunction for quick identification on the jobsite
• Anti-Slip Sure Grip Spikes provide optimal hold against material
• Dual Position Rafter Hook for operator convenience
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
3-1/2" Cordless Framing Nailer
SPECIFICATIONS
Battery Capacities
7.2V Li-Ion
Charging Time
30 Minutes
Battery Life
Approx. 4,000 Nails
Fuel Cell Life
Approx. 1,200 Nails
Nail Type
0.113" - 0.131" (2.9 - 3.3 mm)
34° Clipped Head
Driving Speed:
Nails / sec. 2 - 3
Dimensions (L x W x H)
12-5/8" x 4-1/4" x 14-1/2"
(321 mm x 108 mm x 368 mm)
Net Weight
7.5 lbs (3.4 kg)
STANDARD EQUIPMENT INCLUDES:
Two 7.2V Li-Ion Batteries
BL0715 (198001-1), Pod / Stick Charger (DC10WB), Safety Goggles (195246-2),
Two NoseAdapter (424443-6), Hex Wrench 3 (783201-2), Hex Wrench 4 (783202-0), Short NailAdapter Set (346488-3),
Spark Plug (162326-9), Plastic Carrying Case (824990-1)
Makita's First Cordless Finishing Nailer
• Utilizes industry standard compact sized fuel cells
• Utilizes 7.2V (1.5Ah) Li-Ion Battery BL0715 with 35 minute charging time
• LED Warning System indicates low battery capacity or tool malfunction for quick identification on the jobsite
2-1/2" Cordless Finishing Nailer
SPECIFICATIONS
Battery Capacities
7.2V Li-Ion
Charging Time
30 Minutes
Battery Life
Approx. 4,000 Nails
Fuel Cell Life
Approx. 1,000 Nails
Nail Type
16 Ga. Straight
Driving Speed
Nails / sec. 2 - 3
Dimensions (L x W x H)
11-7/8" x 3-1/2" x 10-1/2"
(303 mm x 90 mm x 267 mm)
Net Weight
4.8 lbs (2.2 kg)
