General Catalogue

185 / 220

Large capacity
air chamber
for increased
power
AN923
Electric Power Tools
makita.ca 183
When QUALITY&SERVICE Counts – ChooseMakita
STANDARD EQUIPMENT INCLUDES:
Hook (122742-7), Oil Supply (181434-7), Safety Goggles (195246-2)
21° Round Head Framing Nailer
• Large capacity air chamber for increased power
• 3 Mode - Sequential, Bump, Lock-Off
• 9 depth nailing setting in 1/16" increments
with adjustment knob
• Convenient Collapsible Rafter Hook
• Nose piece with sure-grip spikes prevents slipping
• Dry fire prevention system prolongs life of tool
• Silent sheet reduces noise when
disconnecting coupler
3-1/2" Framing Nailer
SPECIFICATIONS
Operating Air Pressure 65 - 120 PSIG
Nail Size 2" - 3-1/2"
Nail Type 0.113" - 0.162" 21° Round Head
Magazine Capacity 64 - 74 Nails
Dimensions (L x W x H)
22" x 4-1/4" x 13-11/16"
(559 mm x 109 mm x 347 mm)
Net Weight 8.6 lbs (3.9 kg)
AN923
STANDARD EQUIPMENT INCLUDES:
HookAssy (122742-7), Oil Supply (181434-7), Safety Goggles (195246-2)
34° Clipped Head Framing Strip Nailer
• Large capacity air chamber for increased power
• 3 Mode - Sequential, Bump, Lock-off
• 9 depth nailing setting in 1/16" increments
with adjustment knob
• Convenient Collapsible Rafter Hook
• Nose piece with sure-grip spikes prevents slipping
• Dry fire prevention system prolongs life of tool
• Silent sheet reduces noise
when disconnecting coupler
3-1/2" Framing Nailer
SPECIFICATIONS
Nail Type 0.113" - 0.131" 34° Clipped Head
Nail Size 2" - 3-1/2" 34° Clipped Head
Operating Air Pressure 65-120 PSIG
Magazine Capacity 60 - 84 Nails
Dimensions (L x W x H)
17-7/8" x 4-1/4" x 14-3/8"
(455 mm x 109 mm x 365 mm)
Net Weight 8.8 lbs (4.0 kg)
AN943
Uses 34° Clipped Head
Framing Nails
Uses 21° Round Head
Framing Nails
STANDARD EQUIPMENT INCLUDES:
Oil Supply (181434-7), Safety Goggles (195246-2)
28° Round or Clipped Head
Framing Strip Nailer
• Large capacity air chamber for increased power
• 2 Mode - Sequential & Bump
• Depth setting knob for adjustment of nailing depth
• Convenient Collapsible Rafter Hook
• Nose piece with sure-grip
spikes prevents slipping
Uses 28° Round or Clipped
Head Framing Nails
3-1/2" Framing Nailer
SPECIFICATIONS
Nail Type 0.113" - 0.131", 28° Round Head
Magazine Capacity 60 - 84 Nails
Operating Air Pressure 70-120 PSIG
Nail Size
2-1/2"- 3-1/2", 28° Round or Clipped Head
Dimensions (L x W x H)
17-1/2" x 4-31/32" x 13-11/32"
(445 mm x 126 mm x 339 mm)
Net Weight 7.0 lbs (3.2 kg)
AN944
STANDARD EQUIPMENT INCLUDES:
Oil Supply (181434-7), Safety Goggles (195246-2), Protective Casing (BA00000372)
15° Round Head Coil Framing Nailer
• Reduced size for improved handling and optimal maneuverability during operation
• 2 Mode - Sequential, Bump Fire
• 8 depth nailing settings in 1/32" increments with adjustment knob
• One touch and easy to load magazine
• Rubberized Grip for increased comfort during prolonged use
3-1/2" Framing Coil Nailer
SPECIFICATIONS
Operating Air Pressure 70 - 120 PSIG
Nail Size 1-3/4" - 3-1/2" (45 mm - 90 mm)
Nail Type 0.099" - 0.150" 15° Round Head
Magazine Capacity 150 - 300 Nails
Dimensions (L x W x H)
12-1/2" x 5" x 14-1/4"
(318 mm x 128 mm x 363 mm)
Net Weight 7.7 lbs (3.5 kg)
AN902
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
ManufacturingAnd Assembly
STANDARD EQUIPMENT INCLUDES:
Hex Wrench 4 (783202-0), Plastic Carrying Case (824490-1), Safety Goggles (195246-2), Oil Supply (181434-7)
15° Round Head Coil Siding Nailer
• 360° exhaust system directs exhaust away from the operator
• 3 Mode - Sequential, Bump, Lock-Off
• Easy load magazine provides maximum versatility
• 9 depth nailing settings in 1/16" increments with adjustment knob
• Convenient adjustable Belt Hook
• One touch and easy to load magazine
• Rubberized Grip for increased comfort during prolonged use
2-1/2" Coil Siding Nailer
SPECIFICATIONS
Operating Air Pressure 65 - 120 PSIG
Nail Size:
Wire Collated 1-1/4" - 2-1/2"
(32 mm - 65 mm)
Plastic Collated 1-1/4" - 2"
(32 mm - 50 mm)
Nail Type 0.080" - 0.099" 15° Round Head
Magazine Capacity 200 - 400 Nails
Dimensions (L x W x H)
13-1/16" x 5" x 12-1/2"
(332 mm x 317 mm x 127 mm)
Net Weight 5.1 lbs (2.3 kg)
AN611
