STANDARD EQUIPMENT INCLUDES:

DHR400T2N:

Two 18V (5.0Ah)Li-IonBatteries

BL1850B (196675-2),DualPortRapidCharger (DC18RD),StraightSideHandle (123138-5),

D-StyleSideHandle (196792-8),CleaningCloth (443122-7),BitGrease (194683-7),DepthGauge (331955-1),PlasticCarryingCase (821746-3)

DHR400ZKN:

Tool Only. Batteries and Charger Sold Separately.

Straight Side Handle (123138-5), D-Style Side Handle (196792-8),

Cleaning Cloth (443122-7), Bit Grease (194683-7), Depth Gauge (331955-1), Plastic Carrying Case (821746-3)

1-9/16" Rotary Hammer with AWS

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

Capacities:

Concrete (TCT)

1-9/16" (40 mm)

Concrete (Core Bit)

4-1/8" (105 mm)

Impact Energy

11.4 J (8.4 ft. lbs)

No Load Speed

250 - 500 RPM

Blows Per Minute

1,450 - 2,900 BPM

Overall Length

18-5/8" (473 mm)

Net Weight

15.0 lbs (6.8 kg)

Auto-Start Wireless System (AWS) Technology Features

Wireless Dust Collection Technology!

SDS-MAX Shank / Hammer & Rotation / Hammer Only

• Advanced Anti-Vibration Technology (AVT

) system incorporates vibration absorbing housing, active

dynamic vibration absorber and damper spring to actively counteract the vibration of the tool for greatly

reduced transmission to the operator

• 2 Operating Modes: Rotation / Rotation + Hammer

DHR400T2N

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Side Handle (126882-3), Cleaning Cloth (443122-7), Bit Grease (194683-7),

Depth Gauge (331886-4)

1-1/8" Rotary Hammer with AWS

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

Capacities:

Concrete

1-1/8" (28 mm)

Steel

1/2" (13 mm)

Wood

1-1/4" (32 mm)

Impact Energy

3.2 J (2.4 ft. lbs)

No Load Speed

0 - 980 RPM

Blows Per Minute

0 - 5,000 BPM

Overall Length

14-3/4" (373 mm)

Net Weight

7.1 lbs (3.2 kg)

Auto-Start Wireless System (AWS) Technology Features

Wireless Dust Collection Technology!

SDS-PLUS Shank / Hammer & Rotation / Hammer Only / Rotation Only

• Anti-Vibration Technology (AVT

) system incorporates vibration absorbing housing, active

dynamic vibration absorber and damper spring to actively counteract the vibration of the tool for greatly

reduced transmission to the operator

• 3 Operating Modes: Rotation / Hammer / Rotation + Hammer

DHR282Z

Bluetooth

is a registered

trademark of Bluetooth

SIG

Variable

Speed,

Reversible

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Side Handle (126882-3), Cleaning Cloth (443122-7), Bit Grease (194683-7),

Depth Gauge (331886-4)

1-1/8" Rotary Hammer

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

Capacities:

Concrete (TCT)

1-1/8" (28 mm)

Concrete (Core Bit)

2-1/8" (54 mm)

Steel

1/2" (13 mm)

Wood

1-1/4" (32 mm)

Impact Energy

3.2 J (2.4 ft. lbs)

No Load Speed

0 - 980 RPM

Blows Per Minute

0 - 5,000 BPM

Overall Length

14-3/4" (373 mm)

Net Weight

7.1 lbs (3.2 kg)

SDS-PLUS Shank / Hammer & Rotation / Hammer Only / Rotation Only

• Anti-vibration technology (AVT

) actively counteracts vibration of tool for

greatly reduced transmission to operator

• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids

for optimal performance in extreme conditions

• Brushless DC motor generates less heat buildup and is ideal for prolonged use in

manufacturing / production applications

• 3 Operating Modes: Rotation / Hammer / Rotation + Hammer

• Trigger-lock button prevents accidental start-up for increased safety

DHR280Z

Variable Speed,

Reversible

STANDARD EQUIPMENT INCLUDES:

DHR263PF2:

Two 18V (3.0Ah)Li-IonBatteries

BL1830B (194205-3),Dual-PortRapidCharger (DC18RD),BatteryCover (450128-8),

SideHandle (158057-6),CleaningCloth (443122-7),BitGrease (194683-7),DepthGauge (324219-0),ToolBag (831284-7)

DHR263Z:

Tool Only. Batteries and Charger Sold Separately.

Side Handle(158057-6), Cleaning Cloth (443122-7),

Bit Grease (194683-7), Depth Gauge (324219-0)

Makita's FIRST 18Vx2 Direct 1˝ Rotary Hammer

SDS-PLUS Shank

Hammer & Rotation / Hammer Only / Rotation Only

• Accepts two x 18V Li-Ion batteries without a battery converter for use with existing 18V Li-Ion battery platform

• Center of gravity located close to rear handle resulting in ideal tool balance during operation

• Torque limiter stops rotation if bit jams for increased operator safety and enhanced motor protection

• 40 angle bit positions enable chisels to be positioned at optimum angle of operation

• Rubber housing bumper protects mode selector

switch and gear housing from damage

• LED job light with afterglow feature

• One touch sliding chuck enables quick

and easy bit changes

1" Rotary Hammer

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

Capacities:

Concrete

1" (26 mm)

Steel

1/2" (13 mm)

Wood

1-1/4" (32 mm)

No Load Speed

0 - 1,250 RPM

Blows Per Minute

0 - 5,000 BPM

Impact Energy

3.0 J (2.2 ft. lbs)

Overall Length

13-3/4" (363 mm)

Net Weight

7.5 lbs (3.4 kg)

DHR263PF2

Variable

Speed,

Reversible

DHR263Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Side Handle (158057-6), Cleaning Cloth (443122-7), Bit Grease (194683-7), Depth Gauge (324219-0), Quick Change Drill Chuck (194079-2)

Makita's FIRST 18Vx2 Direct

1˝ Rotary Hammer

SDS-PLUS Shank

Hammer & Rotation / Hammer Only / Rotation Only

Features Quick Change Drill Chuck

• Accepts two x 18V Li-Ion batteries without a battery converter for use with existing 18V Li-Ion battery platform

• Center of gravity located close to rear handle resulting in ideal tool balance during operation

• Torque limiter stops rotation if bit jams for increased operator safety and enhanced motor protection

• 40 angle bit positions enable chisels to be positioned at optimum angle of operation

• Rubber housing bumper protects mode selector switch and gear housing from damage

• LED job light with afterglow feature

• One touch sliding chuck enables quick and

easy bit changes

1" Rotary Hammer

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

Capacities:

Concrete

1" (26 mm)

Steel

1/2" (13 mm)

Wood

1-1/4" (32 mm)

No Load Speed

0 - 1,250 RPM

Blows Per Minute

0 - 5,000 BPM

Impact Energy

3.0 J (2.2 ft. lbs)

Overall Length

14-3/4" (374 mm)

Net Weight

7.7 lbs (3.5 kg)

DHR264Z

Variable

Speed,

Reversible

Quick Change Drill Chuck

194079-2

Makita offers a wide variety of

ACCESSORIES!

STANDARD EQUIPMENT INCLUDES:

DHR242RTJ:

Two 18V (5.0Ah) Li-Ion Batteries

BL1850B (196675-2), Rapid Charger (DC18RC),

Battery Cover (450128-8), Side Handle (158057-6), Depth Gauge (324219-0), Interlocking Case (197213-3)

DHR242Z:

Tool Only. Batteries and Charger Sold Separately.

Depth Gauge (324219-0), Side Handle (158057-6)

15/16" Rotary Hammer

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Capacities:

Concrete

15/16" (24 mm)

Steel

1/2" (13 mm)

Wood

1-1/16" (27 mm)

Impact Energy

2.4 J (1.8 ft. lbs)

No Load Speed

0 - 950 RPM

Blows Per Minute

0 - 4,700 BPM

Overall Length

12-7/8" (328 mm)

Net Weight

6.0 lbs (2.7 kg)

Variable

Speed,

Reversible

Lightweight, 3-Mode Rotary Hammer

SDS-PLUS Shank / Hammer & Rotation / Hammer Only / Rotation Only

• Brushless DC motor with high power to weight and size ratio

• Quickly attaches to Makita's DX01 Dust Extraction System for dustless drilling applications in sensitive

work environments (DX01 sold separately)

• Torque limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection

• Rubber joint construction suppresses transmission of vibration to battery, minimizing battery failures due to

terminal breakage or poor electrical contact

• 40 angle bit positions enable chisels to be positioned

at optimum angle of operation

DHR242RTJ

DHR242Z

Bluetooth

is a registered

trademark of Bluetooth

SIG

Variable

Speed

DHR400ZKN
