25 / 220
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
18V LXT
Concrete Tools
makita.ca
23
When
QUALITY&SERVICE
Counts – ChooseMakita
Rotary Hammer HEPA Filter Dust Extraction Systems
DHR202Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Depth Gauge (324219-0), Side Handle (158057-6)
Lightweight, 3 Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Rubber Joint Construction suppresses transmission of vibration to battery, minimizing battery failures
due to terminal breakage or poor electrical contact
• 40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• LED Light with Afterglow feature
Variable Speed, Reversible
15/16" Rotary Hammer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
15/16" (24 mm)
Steel
1/2" (13 mm)
Wood
1" (26 mm)
Impact Energy
1.9 J (1.4 ft. lbs)
No Load Speed
0 - 1,100 RPM
Blows Per Minute
0 - 4,000 BPM
Overall Length
14-1/8" (358 mm)
Net Weight
7.7 lbs (3.5 kg)
DHR243Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Depth Gauge (324219-0), Quick Change Drill Chuck (194079-2), Side Handle (158057-6)
Lightweight 3-Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
Features Quick Change Drill Chuck
• Brushless DC Motor generates less heat buildup and is ideal for prolonged use
in high production applications
• Quickly attaches to Makita's DX02 Dust Extraction System for dustless drilling applications in sensitive
work environments (DX02 sold separately)
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
15/16" Rotary Hammer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
15/16" (24 mm)
Steel
1/2" (13 mm)
Wood
1-1/16" (27 mm)
Impact Energy
2.4 J (1.8 ft. lbs)
No Load Speed
0 - 950 RPM
Blows Per Minute
0 - 4,700 BPM
Overall Length
13-7/8" (353 mm)
Net Weight
6.4 lbs (2.9 kg)
Variable Speed, Reversible
Quick Change Drill Chuck
194079-2
DHR241RMJ
STANDARD EQUIPMENT INCLUDES:
DHR241RMJ:
Two 18V (4.0Ah) Li-Ion Batteries
BL1840B (196401-9), Rapid Charger (DC18RC), Battery Cover (450128-8),
Side Handle (158057-6), Depth Gauge (324219-0), Interlocking Case (197213-3)
DHR241RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8),
Depth Gauge (324219-0), Side Handle (158057-6), Plastic Carrying Case (141643-0)
DHR241Z:
Tool Only. Batteries and Charger Sold Separately.
Depth Gauge (324219-0), Side Handle (158057-6)
Lightweight, 3 Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Rubber Joint Construction suppresses transmission of vibration to battery, minimizing battery failures
due to terminal breakage or poor electrical contact
Variable Speed, Reversible
15/16" Rotary Hammer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
15/16" (24 mm)
Steel
1/2" (13 mm)
Wood
1-1/16" (26 mm)
Impact Energy
1.9 J (1.4 ft. lbs)
No Load Speed
0 - 1200 RPM
Blows Per Minute
0 - 4000 BPM
Overall Length
16-3/8" (417 mm)
Net Weight
7.7 lbs (3.5 kg)
DHR241Z
DHR241RFE
DX08 (Shown)
Dust Extraction
System
STANDARD EQUIPMENT INCLUDES:
DHR242RMEW:
Two18V (4.0Ah)Li-IonBatteries
BL1840B (196401-9), Rapid Charger (DC18RC), Battery Cover (450128-8),
Depth Gauge (324219-0), Side Handle (158057-6), Dust Extraction System (DX06), Plastic Carrying Case (140H96-8)
DHR242ZWX:
Tool Only. Batteries and Charger Sold Separately.
Side Handle (158057-6), Depth Gauge (324219-0),
Dust Extraction System (DX06)
15/16" Rotary Hammer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
15/16" (24 mm)
Steel
1/2" (13 mm)
Wood
1-1/16" (27 mm)
Impact Energy
2.4 J (1.8 ft. lbs)
No Load Speed
0 - 950 RPM
Blows Per Minute
0 - 4,700 BPM
Overall Length
12-7/8" (328 mm)
Net Weight
6.0 lbs (2.7 kg)
Variable Speed,
Reversible
Lightweight, 3-Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Brushless DC Motor generates less heat buildup and is ideal for prolonged use in high production applications
• Includes HEPA filter dust extraction system for dustless
drilling applications in sensitive work environments
DHR242ZWX
DHR242RMEW
DHR182Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Side Handle (158057-6), Depth Gauge (415486-9)
Auto-Start Wireless System (AWS) Technology Features Wireless Dust
Collection Technology!
SDS-PLUS Shank / Hammer & Rotation / Hammer Only / Rotation Only
• AWS (Auto-Start Wireless System) uses Bluetooth
®
technology to communicate between tool and
vacuum and enable wireless control when used with Makita AWS cordless tools
• Anti-vibration technology (AVT
TM
) actively counteracts vibration of tool for greatly reduced
transmission to operator
• Quickly attaches to Makita's DX05 dust extraction system for dustless drilling applications in sensitive
work environments (DX05 sold separately)
11/16" Rotary Hammer with AWS
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
11/16" (18 mm)
Steel
1/2" (13 mm)
Wood
15/16" (24 mm)
Impact Energy
1.7 J (1.2 ft. lbs)
No Load Speed
0 - 1,350 RPM
Blows Per Minute
0 - 5,000 BPM
Overall Length
11-7/8" (301 mm)
Net Weight
5.3 lbs (2.4 kg)
Bluetooth
®
is a registered
trademark of Bluetooth
®
SIG
Variable Speed,
Reversible
• DX06 -
For use with model DHR242
• DX05 -
For use with model DHR182
• DX07 -
For use with model DHR243
• DX08 -
For use with model DHR280
• HEPA filter certified to 99.99% efficiency (0.01% permeability) at 0.3 - 0.5 microns (µm)
• Provides effective dust extraction for drilling applications in sensitive work environments
• Transparent dust box allows operator to quickly reference current dust level
• One-touch attachment/removal system enables canister to be quickly emptied of accumulated dust
• Large dust canister provides extended operating time between cleaning
• Easily removable HEPA filter for fast and effective cleaning
• Integrated depth gauge is fully adjustable for precise depth setting
• Easily removable from rotary hammer when not immediately required
• Double lock function prevents accidental removal from Rotary Hammer
• Automatic operation in conjunction with Rotary Hammer using integrated DC motor
• Dust filter cleaning dial removes excess dust from filter, maintaining
vacuum efficiency and performance
(DX05, DX06, DX07, DX08 only)
• Built-in twin LED job light
illuminates the work area
(DX08 only)
