STANDARD EQUIPMENT INCLUDES:
20-21" Chain (523 099 072), 20" Guide Bar (445 050 655),
Chain Cover (952 020 660),Tool Kit (957 004 002), Starter Rope (108 164 020), Spark Plug (965 603 021)
20" / 72.6cc Environment-Friendly 2-Stroke Chainsaw with Winter Operation Mode
• SLR / Scavenging Losses Rejection Muffler
producing much Cleaner Emissions
• Half Throttle-lock start position with
Decompression Valve for Reduced Start-Up Force
• Steel Spring / Advanced Vibration Dampening
System is engineered for reducing vibration
transfer to the operator
• Dual Mount, Aggressive Large Metal Spike Bars
for Safety and Hinge Action Cutting
• Easy Remove Air Filter and Spark Plug Cover
for quick maintenance access
• Electronic Ignition system incorporates
a Microprocessor
SLR + Decompression Valve
+ Winter Mode
20" / 72.6cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement
72.6cc (4.4 cu.in.)
Chain Pitch / Gauge
3/8" / 0.058"
Maximum Engine Speed 12,800 RPM
Power Rating
4.0 kW / 5.4 HP
Fuel Tank Capacity
750 ml
Oil Tank Capacity
420 ml
Fuel / Oil Mixture
50:1
Net Weight
13.8 lbs (6.3 kg)
EA7300PRFE
DCS5121REJ
18" / 50cc Environment-Friendly 2-Stroke Chainsaw with Easy Start
and Winter Operation Mode
• SLR / Scavenging Losses Rejection Muffler
producing much Cleaner Emissions
• Easy Start / Equipped with a Spring Assisted Recoil
Starter for 30% Less pulling force and Low RPM
Ignition Coil providing Faster, Easier Starting
• Touch & Stop / One Lever Control for Starting,
Running and Shut Down Operation
• Steel Spring / Advanced Vibration Dampening
System is engineered for reducing vibration
transfer to the operator
• Dual Mount, Aggressive Large Metal
Spike Bars for Safety and Hinge
Action Cutting
• Half Throttle-lock start
position with Easy
Start for Reduced
Start-Up Force
SLR + Easy Start
+ Winter Mode
18" / 50cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement
50cc (3.1 cu.in.)
Chain Pitch / Gauge
0.325" / 0.058"
Maximum Engine Speed 13,800 RPM
Power Rating
2.5 kW / 3.3 HP
Fuel Tank Capacity
470 ml
Oil Tank Capacity
269 ml
Fuel / Oil Mixture
50:1
Net Weight: Dry w/o Bar & Chain
12.1 lbs (5.4 kg)
18˝ Rescue Bar
& Chain Kit
Sold Separately
(Part No. 957 415 060)
See page 160
EA5600FREE
STANDARD EQUIPMENT INCLUDES:
18" Chain (523 099 064), 18" Sprocket Nose Bar
3/8" 58G (445 045 651), Chain Protector Cover (952 020 640), Universal Wrench 13/19 (941 719 141),Torx Wrench (782025-3),
Screwdriver (783012-5), Starter Rope (131 164 020), Spark Plug (965 603 021), Spike Bar (326648-3)
18" / 55.6cc Environment-Friendly 2-Stroke Chainsaw with Easy Start
and Winter Operation Mode
• SLR / Scavenging Losses Rejection Muffler
producing much Cleaner Emissions
• Easy Start / Equipped with a Spring Assisted Recoil
Starter for 30% Less pulling force and Low RPM
Ignition Coil providing Faster, Easier Starting
• Winter Mode (Optional) / Prevents Carburetor Icing
by providing a Higher Operating Engine
• Temperature during Cold Weather use and up to 5°C
• Heavy Duty Cartridge Filter System designed for
Extended Filter Life and Less Maintenance
• Touch & Stop / One Lever Control for Starting,
Running and Shut Down Operation
• Steel Spring / Advanced Vibration
Dampening System is
engineered for reducing
vibration transfer
to the operator
18" / 55.6cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement
55.6cc (3.4 cu.in.)
Chain Pitch / Gauge
3/8" / 0.058"
Maximum Engine Speed 13,800 RPM
Power Rating
3.0 kW / 3.9 HP
Fuel Tank Capacity
570 ml
Oil Tank Capacity
320 ml
Fuel / Oil Mixture
50:1
Net Weight Dry w/o Bar/Chain
12.8 lbs (5.8 kg)
SLR + Easy Start
+ Winter Mode
Bar & Chain Fasteners remain
fixed to cover when loosened
STANDARD EQUIPMENT INCLUDES:
18" Chain (523 686 072),18" Guide Bar (445 045 631), Chain Cover (952 020 650),
Starter Rope (108 164 020), Spark Plug (965 603 021),Tool Kit (957 004 002)
EA5000PREL
18˝ / 50cc Environment-Friendly 2-Stroke Chainsaw with Easy Start
and Winter Operation Mode
• SLR / Scavenging Losses Rejection Muffler
producing much Cleaner Emissions
• Easy Start / Equipped with a Spring Assisted Recoil
Starter for 30% Less pulling force and Low RPM
Ignition Coil providing Faster, Easier Starting
• Touch & Stop / One Lever Control for Starting,
Running and Shut Down Operation
• Steel Spring / Advanced Vibration Dampening
System is engineered for reducing vibration
transfer to the operator
• Dual Mount, Aggressive Large Metal
Spike Bars for Safety and Hinge
Action Cutting
• Half Throttle-lock start
position with Easy
Start for Reduced
Start-Up
Force
SLR + Easy Start
+ Winter Mode
18" / 50cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement
50cc (3.1 cu.in.)
Chain Pitch / Gauge
0.325" / 0.058"
Maximum Engine Speed 13,800 RPM
Power Rating
2.8 kW / 3.9 HP
Fuel Tank Capacity
470 ml
Oil Tank Capacity
270 ml
Fuel / Oil Mixture
50:1
Net Weight: Dry w/o Bar & Chain
11.9 lbs (5.4 kg)
STANDARD EQUIPMENT INCLUDES:
18" Chain (523 686 072),18" Guide Bar (445 045 631), Chain Cover (952 020 650),
Starter Rope, Spark Plug (965 603 021),Tool Kit (957 004 011)
EA4300FREC
STANDARD EQUIPMENT INCLUDES:
.325" Chain 18" 50G (512 484 672), 18" Sprocket Nose Bar .325" 50G (444 045 141), Chain Protector Cover (419560-5), Spike Bar (346301-5),
Universal Wrench 13/16 (782026-1),Torx Wrench (782025-3), Screwdriver (for CarburetorAdjustment) (783012-5), Spark Plug (0650109950)
18" / 43cc Environment-Friendly 2-Stroke Chainsaw with Easy Start and
Winter Operation Mode
• SLR / Scavenging Losses Rejection Muffler
producing much Cleaner Emissions
• Easy Start / Equipped with a Spring Assisted Recoil
Starter for 30% Less pulling force and Low RPM
Ignition Coil providing Faster, Easier Starting
• Touch & Stop / One Lever Control for Starting,
Running and Shut Down Operation
• Steel Spring / Advanced Vibration Dampening
System is engineered for reducing vibration
transfer to the operator
• Dual Mount, Aggressive Large
Metal Spike Bars for Safety and
Hinge Action Cutting
Catalytic Converter Muffler
+ Easy Start + Winter Mode
18" / 42.4cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement
42.4cc (2.6 cu.in.)
Chain Pitch / Gauge
0.325" / 0.050"
Maximum Engine Speed 13,500 RPM
Power Rating
2.1kW / 2.9 HP
Fuel / Oil Mixture (Makita Oil)
50:1
Fuel Tank Capacity
480 ml
Oil Tank Capacity
280 ml
Net Weight: Dry w/o Bar & Chain
10.8 lbs (4.9 kg)
All Makita
Gasoline Powered Chainsaws
now feature
New
HIGH VISIBILITY SAFETY COLOUR!
Makita offers a wide variety of
ACCESSORIES!
EA3601FRDB
STANDARD EQUIPMENT INCLUDES:
16" Guide Bar (165202-6), 16" Chain (531 492 656), Chain Cover (419560-5), Box Wrench (782027-9), Starter Rope (SG00000025),
Spark Plug (649500-1)
16" / 35.2cc Environment-Friendly 2-Stroke Chainsaw with Easy Start and
Winter Operation Mode
• Stratified Air Scavenging engine for lower emissions
and improved fuel efficiency
• "Tool-less" chain tensioning for quick and
convenient chain adjustment
• Touch & Stop single lever control shuts off engine
with just a touch
• Compact design with less weight
(only 9.3 lbs / 4.2 kg)
• High power-to-weight ratio 2.4 HP engine
• Centrifugal air cleaner for
enhanced air filtration
• Advanced vibration dampening
system engineered to
reduce vibration
• Fuel level view window
SAS + Easy Start + Winter Mode
16" / 35.2cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement
35.2cc (2.15 cu.in.)
Chain Pitch / Gauge
3/8" / 0.050"
Maximum Engine Speed 13,500 RPM
Power Rating
1.7 kW / 2.4 HP
Fuel / Oil Mixture
50:1
Fuel Tank Capacity
310 ml
Oil Tank Capacity
260 ml
Net Weight Dry w/o Bar/Chain
9.3 lbs (4.2 kg)
