EA3501SRDB
STANDARD EQUIPMENT INCLUDES:
16" Guide Bar (165202-6), 16" Chain (196444-1), Chain Cover 14"-16" (419560-5), Spike Bar (346301-5),
Universal Wrench 13/16 (782026-1), Starter Rope (444038-9), Spark Plug (0650109950), Screwdriver (783012-5)
16˝ / 35cc Environment-Friendly 2-Stroke Chainsaw with
Intelligent Ignition Coil + Easy Start
• Intelligent Ignition Coil controls Stable Idling,
increases Output Power, protects against Engine
Overrun and enables Easier Restarting
• Toolless Chain Tensioner for quick and
easy adjustments
• Touch & Stop / One Lever Control for Starting,
Running and Shut Down Operation
• Steel Spring / Advanced Vibration Dampening
System is engineered for reducing vibration
transfer to the operator
• Fuel Primer Bulb for Improved
and Quicker Cold Starts
• Aggressive Large Metal
Spike Bar for Safety
and Hinge Action
Cutting
16" / 35cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement
35cc (2.1 cu.in)
Chain Pitch / Gauge
3/8" / 0.050"
Maximum Engine Speed 13,100 RPM
Power Rating
1.7 kW / 2.3 HP
Fuel / Oil Mixture
50:1
Fuel Tank Capacity
400 ml
Oil Tank Capacity
290 ml
Net Weight: Dry w/o Bar & Chain
9.9 lbs (4.5 kg)
Intelligent Ignition Coil
+ Easy Start
EA3201SRDB
STANDARD EQUIPMENT INCLUDES:
16" Guide Bar (165202-6), 16" Chain (196444-1), Chain Cover 16" (419560-5), Spike Bar (346301-5), Universal Wrench 13/16 (782026-1),
Screwdriver (783012-5), Spark Plug (0650109950), Starter Rope (444038-9)
16" / 32cc Environment-Friendly 2-Stroke Chainsaw with
Intelligent Ignition Coil + Easy Start
• Intelligent Ignition Coil controls Stable Idling,
increases Output Power, protects against Engine
Overrun and enables Easier Restarting
• Toolless Chain Tensioner for quick and
easy adjustments
• Touch & Stop / One Lever Control for Starting,
Running and Shut Down Operation
• Steel Spring / Advanced Vibration Dampening
System is engineered for reducing vibration
transfer to the operator
• Fuel Primer Bulb for Improved
and Quicker Cold Starts
• Aggressive Large Metal
Spike Bar for Safety
and Hinge Action
Cutting
Intelligent Ignition Coil
+ Easy Start
16" / 32cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement
32cc (1.95 cu.in.)
Chain Pitch / Gauge
3/8" / .050"
Maximum Engine Speed 12,800 RPM
Power Rating
1.35 kW / 1.8 HP
Fuel / Oil mixture
50:1
Fuel Tank Capacity
400 ml
Oil Tank Capacity
280 ml
Net Weight: Dry w/o Bar & Chain
9.4 lbs (4.2 kg)
DUC400Z
DUC400Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
16" Chain (196742-3), 16" Guide Bar (165247-4), Chain Cover (419242-9), Oil Supply (182229-1), Spike Bumper (347078-5)
16˝ / 18Vx2 LXT Cordless Chainsaw
with Specialized Battery Positioning
for Optimum Balance and Control
• Fast, Variable Speed (3,940 Feet Per Minute)
Equivalent to a 30cc Gasoline Chainsaw
• Specialized 18Vx2 Battery Positioning is the Makita
Industry Game Changer within the Cordless
Product line offering Premium Balance, Control
and Cutting Performance
• Makita Built Outer Rotor Brushless Motor Direct
Drive System for High Power & Speed equivalent
to a 30cc Gasoline Chainsaw
16" / 18Vx2 LXT Cordless Chainsaw
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Guide Bar Length
16" (400 mm)
Chain Pitch / Gauge
3/8" / 0.043"
Chain Speed 0-3,940 FPM (0-1 200 m/min)
Overall Length
32-1/4" (818 mm)
Net Weight
9.3 lbs (4.2 kg)
Brushless Outer Motor
+ XPT + 3 Year Limited Warranty
Toolless Chain Tension
Adjustment
DUC405Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
16" Chain (196742-3), 16" Guide Bar (165247-4), Chain Cover (419242-9), Spike Bumper (347078-5), Box Wrench (782027-9),
Oil Supply (182229-1)
16˝ / 18Vx2 LXT Cordless Chainsaw
with Specialized Battery Positioning
for Optimum Balance and Control
• Fast, Variable Speed (3,940 Feet Per Minute)
Equivalent to a 30cc Gasoline Chainsaw
• Specialized 18Vx2 Battery Positioning is the Makita
Industry Game Changer within the Cordless
Product line offering Premium Balance, Control
and Cutting Performance
• Makita Built Outer Rotor Brushless Motor Direct
Drive System for High Power &
Speed equivalent to a 30cc
Gasoline Chainsaw
16" / 18Vx2 LXT Cordless Chainsaw
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Guide Bar Length
16" (400 mm)
Chain Pitch / Gauge
3/8" / 0.043"
Chain Speed 0-3,940 FPM (0-1 200 m/min)
Overall Length
31-1/2" (800 mm)
Net Weight
9.0 lbs (4.1 kg)
Brushless Outer Motor
+ XPT + 3 Year Limited Warranty
Captive Bar Nuts
For Chain Tensioning
DUC355Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
14" Chain (196741-5), 14" Guide Bar (165246-6), Chain Cover (419288-5), Spike Bumper (347078-5), Box Wrench (782027-9),
Oil Supply (182229-1)
14˝ / 18Vx2 LXT Cordless Chainsaw
with Specialized Battery Positioning
for Optimum Balance and Control
• Fast, Variable Speed (3,940 Feet Per Minute)
Equivalent to a 30cc Gasoline Chainsaw
• Specialized 18Vx2 Battery Positioning is the Makita
Industry Game Changer within the Cordless
Product line offering Premium Balance, Control
and Cutting Performance
• Makita Built Outer Rotor Brushless Motor Direct
Drive System for High Power &
Speed equivalent to a 30cc
Gasoline Chainsaw
14" / 18Vx2 LXT Cordless Chainsaw
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Guide Bar Length
14" (350 mm)
Chain Pitch / Gauge
3/8" / 0.043"
Chain Speed 0-3,940 FPM (0-1 200 m/min)
Overall Length
30" (762 mm)
Net Weight
8.9 lbs (4.0 kg)
Brushless Outer Motor
+ XPT + 3 Year Limited Warranty
Captive Bar Nuts
For Chain Tensioning
