201 / 220
makita.ca
199
OUTDOOR
Power Equipment
Features Extreme Protection Technology (XPT™) to provide increased dust and water resistance in harsh job site conditions
• Delivers up to 60 minutes of run time under load using one 18V LXT (6.0 Ah) BL1860 battery
• Holds (2) 18V LXT Lithium-Ion batteries but operates using (1) 18V battery at a time; utilizes second battery when needed
• Makita-built BL™ Brushless Motor for optimal performance
• 2-speed with maximum speed up to 2.5 MPH on a 12º incline
• Maximum load capacity up to 287 lbs (130 kg)
• 7" mechanical disc brake for faster stopping
• Rear wheel spacing is adjustable from 19" to 30" to accommodate the work environment
• L-shaped legs can be easily installed to replace rear wheels
• L.E.D. lights on each side of frame to illuminate the work area
DCU180ZX1, DCU180ZX2
Power-Assisted Wheelbarrows
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Speed:
Forward, High / Low
0 - 3.5 km/h / 0 - 1.5 km/h
Reverse
0 - 1.0 km/h
Minimum Turning Radius
(Outer diameter when turning with front wheel as axis) 110 cm
Maximum Climbing Capacity
12°
Maximum Load Capacity
287 lbs (130 kg)
DCU180ZX1:
Overall Dimensions during operation (L x W x H)
61-1/2" x 41-3/4" x 35-1/2"(156 cm x 106 cm x 90 cm)
Net Weight
97.5 lbs (44.2 kg)
DCU180ZX2:
Overall Dimensions during operation (L x W x H)
51-1/2" x 31-1/8" x 35-1/2" (131 cm x 79 cm x 90 cm)
Net Weight
86 lbs (39 kg)
Convenient
solution for
material
transport
on job sites
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and
Charger Sold Separately.
Support Foot (2 Ea. 144675-6),
Key (643890-4),
Wrench 13 (2 Ea. 781006-4),
Bucket (198494-2)
DCU180ZX2
with Bucket
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Support Foot (2 Ea. 144675-6), Key (643890-4),
Wrench 13 (2 Ea. 781006-4), FlatbedTray (199116-7)
DCU180ZX1
with Flatbed Tray
18V x2 LXT POWER-ASSISTED
WHEELBARROWACCESSORIES
FLATBED TRAY
199116-7
BUCKET
198494-2
Description
• Easy four bolt installation and removal
• Side rails install in up or down position;
large knob for easy adjustment
• Ideal for loading heavy duty bulky
material such as bricks, concrete
bags and more
• For use with Makita Power Assisted
Wheelbarrow model DCU180Z
•
INCLUDES:
Flatbed Tray
• Easy four bolt installation
and removal
• Heavy duty steel based bucket
for tough workloads
• Ideal for transporting material
on job sites
• For use with Makita Power Assisted
Wheelbarrow model DCU180Z
•
INCLUDES:
Bucket
DLM380Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Offset Wrench 13 (782016-4), Blade Set (196863-1), Grass Catcher (DA00000357)
Clean, Quiet and Powerful Grass Mowing using Makita's
270+ Tool Battery Platform
• Perfect for lawns up to 6000 square feet (550 sq meters)
• Powerful 36 Volt (18Vx2) cutting performance while remaining environmentally friendly
• Single lever with 6 setting cutting height adjustment -
variable from 20 - 75 mm (1 inch - 3 inches)
• Folding handle for compact storage
• Dual battery charge level indicators
• XPT (eXtreme Protection Technology)
built in for maximum protection to
the motor against dirt, moisture
and debris
• Lawn Mower can be used
with or without Grass
Catcher Bag
15" / 18Vx2 LXT Cordless Lawn Mower
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Cutting Width
15" (380 mm)
Range of Height
1" - 2-15/16"
(25 - 75 mm)
Step
6 Steps
Grass Box Capacity
40 L
No Load Speed
3,700 RPM
Dimensions (L x W x H)
53-1/2" x 18-1/4" x 40-1/4"
(1,361 mm x 465 mm x 1,023 mm)
Net Weight
31.7 lbs (14.4 kg)
Grass
Catcher with
Grass Level
Indicator
When
QUALITY&SERVICE
Counts – ChooseMakita
Cordless
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
DLM431Z
STANDARD EQUIPMENT INCLUDES:
DLM431PT2:
Two 18V (5.0Ah) Li-Ion Batteries
BL1850B (196675-2), Dual Port Rapid Charger (DC18RD), Blade Set (197761-2),
Socket Wrench 17 (782210-8)
DLM431Z:
Tool Only. Batteries and Charger Sold Separately.
Blade Set (196061-7), Socket Wrench 17 (782210-8)
Clean, Quiet and Powerful Grass Mowing using Makita's
270+ Tool Battery Platform
• Perfect for lawns up to 10,000 square feet (950 sq meters)
• Powerful 36 Volt (18Vx2) cutting performance while remaining environmentally friendly
• Single lever with 13 setting cutting height adjustment - variable from 20 - 75 mm (13/16 inch - 3 inches)
• Ball bearing wheels for less effort required while mowing
• Folding handle for compact storage
• Dual battery charge level indicators
• XPT (eXtreme Protection
Technology) built in for maximum
protection to the motor
against dirt, moisture
and debris
• Lawn Mower can
be used with or
without Grass
Catcher
Bag
17" / 18Vx2 LXT Cordless Lawn Mower
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Cutting Width
17" (430 mm)
Range of Height
13/16" - 2-15/16"
(20 - 75 mm)
Step
13 Steps
Grass Box Capacity
50 L
No Load Speed
3,600 RPM
Dimensions (L x W x H)
58-3/4" x 18-1/8" x 40-1/4"
(149 cm x 46 cm x 102 cm)
Net Weight
38.2 lbs (17.3 kg)
Single Lever Height Adjustment
with 13 Cutting Positions
DLM431PT2
DLM460Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Blade Set (199367-2), Socket Wrench 17 (782210-8)
Clean, Quiet and Powerful Grass Mowing using Makita's
270+ Tool Battery Platform
• Heavy duty durable steel deck provides 18" cut
• Mulching and rear bagging capabilities
• Powerful 36 Volt (18Vx2) cutting performance while remaining environmentally friendly
• Brushless motor delivers 2,500 - 3,300 RPM for faster cutting
• Quiet mode reduces noise by providing constant speed control at 2,500 RPM
• Cuts up to 7,300 square feet using two 5.0 Ah batteries (batteries not included)
• Single lever with 10 setting cutting height
adjustment - variable from 20 - 75 mm
(13/16 inch - 2-15/16 inches)
• Ball bearing wheels for less effort
required while mowing
18" / 18Vx2 LXT Cordless Lawn Mower
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Cutting Width
18" (460 mm)
Range of Height
13/16" - 2-15/16"
(20 - 75 mm)
Step
10 Steps
Grass Box Capacity
60 L
No Load Speed
2,500 RPM
Dimensions (L x W x H)
66-1/8"˝ x 21˝ x 49-3/4˝
(168 cm x 53 cm x 126 cm)
Net Weight
57.8 lbs. (26.2 kg)
Perfect for Large
Lawns Providing
Mulching and
Rear Bagging
Capabilities
