EK7651H

14" / 4.1 HP 4-Stroke Power Cutter

makita.ca

OUTDOOR

Power Equipment

189

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

The FIRST 4-Stroke Power Cutter Available On The Market!

Save The Cost Of The Power Cutter With Fuel Savings Alone!

• Reduced noise and fuel consumption versus competitive 2-stroke models for maximum operator comfort and reduced operational costs

• No fuel mixing prevents damage due to improper fuel mixture and eliminates need to carry separate mixed fuel

• Cleaner 4-stroke emissions limits environmental impact and reduced carbon buildup in engine

• Automatic decompression valve reduces required start up force by 40% versus competitive 2-stroke models

• Pressure compensated carburetor prevents flooding by automatically

adjusting to ensure the proper amount of fuel delivery

• Advanced five stage air filtration system provides cleaner air for

maximum engine performance

SPECIFICATIONS

Displacement

4.6 cu.in (75.6cc)

Maximum Power

3.0 kW / 4.1 HP

Fuel Tank Capacity

1/3 Gal (1.1 L)

No Load Speed (Engine)

9,100 RPM

Maximum Spindle Speed

4,300 RPM

Arbor

20 mm

Maximum Cutting Depth

4-13/16" (122 mm)

Dry Weight

28.4 lbs (12.9 kg)

STANDARD EQUIPMENT INCLUDES:

Tool Kit (195488-8), WaterAttachment Kit (195533-9), Oil Bottle Set, Pre Filter Set (198172-4), Ring Set (196588-7), Spark Plug (168652-4), Starter Rope (444040-2), Dust Bag (166106-5)

Automatic

Decompression

Reduces

Required Start

Up Force By 40%

Shown with

Optional Blade

(T-02836)

MM4 Premium

4-Stroke Engine Oil

(Part No. T-02484)

4-Stroke

Power Cutter

PREMIUM4-STROKE ENGINE OIL

0.2 L / 200ml size

0.08 L / 80ml size

Ideal for use with MM4 Power Cutters

and Backpack Blowers

For distributor: (T-02490) (12 Bottles / Case)

Ideal for use with MM4 Line Trimmers,

Hedge Trimmers, Brush Cutters, Pole Chain Saw,

Hand Held Blowers and 1" Water Pump

(195826-4) (single bottle) / For distributor: (195826-4-48) (48 Bottles / Case)

When

QUALITY&SERVICE

Counts – ChooseMakita

EK7651H
