STANDARD EQUIPMENT INCLUDES:
16" Cutting Disk For Stone (20 mm) (966 161 020),
Tool Kit (957 004 006), WaterAttachment Kit (394 365 630)
16" / 5.6 HP 2-Stroke Power Cutter
SPECIFICATIONS
Displacement
4.9 cu.in (81cc)
Maximum Power
4.2 kW / 5.6 HP
Fuel / Oil Mixture
50:1
Fuel Tank Capacity
1/3 Gal (1.1 L)
No Load Speed (Engine)
9,350 RPM
Max. Spindle Speed
3,820 RPM
Arbor
20 mm
Max. Cutting Depth
5-3/4" (147 mm)
Dry Weight
23.4 lbs (10.6 kg)
EK8100
Required to use 2 Cycle Synthetic Oil
(Part No. T-00739C)
16" Cutting Wheel
Compliant with CARB Tier 3, EPA Phase 2
and EU Stage 2 Regulations
• NEW Scavenging Losses Rejection (SLR) Muffler
recycles exhaust unburnt gas emissions for increased
operational efficiency and cleaner emissions
• Advanced 5 Stage Air Filtration System for cleaner
operation and enhanced operational life
• Large Air Intake for maximum engine cooling
• Reversible Cutting Arm enables cutting disc to be
side or conveniently mounted for optimal operational
versatility in a variety of applications
• Electronic Ignition with Rev Limiter
• Always use with 2 Cycle Synthetic Oil
Top Mount Decompression
Valve Reduces Required Start
Up Force By 70%
10L (2.5 Gal)
Pressurized
Water Tank
Sold Separately
Makita offers a wide variety of
ACCESSORIES!
SYNTHETIC 2-CYCLE ENGINE OIL
WITH FUEL STABILIZER
Required for all 2-StrokeMakita Power Cutters
For 3.8 L
1 GallonMix
For 9.5 L
2.5 GallonMix
(T-00745C) synthetic 2-Stroke Oil
For distributor: (T-00745-48) (48 Bottles / Case)
(T-00739C) synthetic 2-Stroke Oil
For distributor: ( T-00739C-48) (48 Bottles / Case)
T-00745C
T-00739C
2-Stroke
Power Cutters
EK6101
STANDARD EQUIPMENT INCLUDES:
14" Cutting Disk For Stone (20 mm) (966 141 120),
Tool Kit (957 004 006), WaterAttachment Kit (394 365 630)
14" / 5.1 HP 2-Stroke Power Cutter
SPECIFICATIONS
Displacement
4.5 cu.in (73cc)
Maximum Power
3.8 kW / 5.1 HP
Fuel / Oil Mixture
50:1
Fuel Tank Capacity
1/3 Gal (1.1 L)
No Load Speed (Engine)
9,400 RPM
Max. Spindle Speed
4,300 RPM
Arbor
20 mm
Max. Cutting Depth
4-13/16" (122 mm)
Dry Weight
22.5 lbs (10.2 kg)
EK7301
Required to use 2 Cycle Synthetic Oil
(Part No. T-00739C)
14" Cutting Wheel
Compliant with CARB Tier 3, EPA Phase 2
and EU Stage 2 Regulations
• NEW Scavenging Losses Rejection (SLR) Muffler
recycles exhaust unburnt gas emissions for increased
operational efficiency and cleaner emissions
• Advanced 5 Stage Air Filtration System for cleaner
operation and enhanced operational life
• Reversible Cutting Arm enables cutting disc to be
side or conveniently mounted for optimal operational
versatility in a variety of applications
• Electronic Ignition with rev limiter
• Always use with 2 Cycle Synthetic Oil
Top Mount Decompression
Valve Reduces Required Start
Up Force By 70%
STANDARD EQUIPMENT INCLUDES:
14" Cutting Disk For Stone (966 141 120),Tool Kit (198692-8),
WaterAttachment Kit (183J43-8), Coupling Sleeve (123120-4),
Starter Rope (394 164 020), Spark Plug (965 603 021)
14" / 4.4 HP 2-Stroke Power Cutter
SPECIFICATIONS
Displacement
3.7 cu.in (60.7cc)
Maximum Power
3.2 kW / 4.4 HP
Fuel / Oil Mixture
50:1
Fuel Tank Capacity
1/6 Gal (0.7 L)
No Load Speed (Engine)
9,850 RPM
Max. Spindle Speed
4,400 RPM
Arbor
20 mm
Max. Cutting Depth
5-1/8" (130 mm)
Dry Weight
19.6 lbs (8.9 kg)
EK6101
Required to use 2 Cycle Synthetic Oil
(Part No. T-00739C)
NEW! Lighter weight power cutter
in the 14" class!
Compliant with CARB Tier 3, EPA Phase 2
and EU Stage 2 Regulations
• NEW Scavenging Losses Rejection (SLR) Muffler
recycles exhaust unburnt gas emissions for increased
operational efficiency and cleaner emissions
• Enhanced 5 stage air filtration; cyclone pre-separation
system effectively removes dust particles away from
intake air and reduces dust stuck on the filter
• Rapid start pull force required to start the machine
is drastically reduced
with spring- assisted
recoil starter
Stratified Scavenging System
complies with exhaust
emission regulations
988 394 610
