203 / 220
EM2650UH
makita.ca
201
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
EBH341U
STANDARD EQUIPMENT INCLUDES:
10˝StarBlade (B-14124),Bump&FeedTrimmerHead (B-05131),ProtectiveGuard (452259-9),TrimmerHeadProtectiveGuardAttachment
(135398-7), BoxDriver16-17 (783013-3),HexWrench4 (783202-0),HexWrench5 (783217-7),ShoulderHarness (122906-3),
EngineOilSet,StarterRope (444018-5),SparkPlug (168534-0),ToolCover (456924-2),AccessoryBag (831304-7)
Save The Cost Of The Brush Cutter With Fuel Savings Alone!
• Patented lubrication system enables Makita 4-Stroke Brushcutters & Line Trimmers to be
used on any angles and slopes
• Heavy duty solid steel straight shaft
• Clean exhaust emissions and lower fuel consumption
• Equipped with ˝Swivel System˝ U-handle for
maximum operator comfort
• 40% less fuel consumption
compared to 2-stroke equivalent
Low Vibration, Extreme
Fuel Cost Savings
10" / 33.5cc 4-Stroke Brush Cutter / Line Trimmer
SPECIFICATIONS
Cutting Width: 10" (254 mm) With Blade
16" (406 mm) With Line Head
Displacement
33.5cc
Maximum Engine Power 1.07 Kw / 1.44 HP
Carburetor
Diaphragm Type
Fuel / Oil Mixture
Not Required
Fuel Tank Capacity
0.65 L
Oil Tank Capacity
0.1 L
4-Stroke Crank Case Oil
10W-30
Overall Length
71-1/4" (181 cm)
Dry Weight
15.7 lbs (7.1 kg)
EBH253U
STANDARD EQUIPMENT INCLUDES:
9˝ Star Blade (B-14118), Shoulder Harness (122906-3), Box Driver 16-17 (783013-3), Hex Wrench 4 (783202-0), Hex Wrench 5 (783217-7),
Tool Cover (456924-2), Engine Oil Set, Starter Rope (444020-8), Spark Plug (168534-0),Accessory Bag (831304-7),
Trimmer Head Protective GuardAttachment (135753-3)
Save The Cost Of The Brush Cutter With Fuel Savings Alone!
• Patented lubrication system enables Makita 4-Stroke Brushcutters & Line Trimmers to be used
on any angles and slopes
• Anti-vibration system for fatigue free use
• Clean exhaust emissions and lower fuel consumption
• Easy starting
• 40% less fuel consumption
compared to 2-stroke equivalent
Quiet, Low Vibration,
Extreme Fuel Cost Savings
9" / 24.5cc 4-Stroke Brush Cutter
SPECIFICATIONS
Cutting Width
9" (228 mm)
Displacement
24.5cc
Maximum Engine Power 0.71 Kw / 0.97 HP
Carburetor
Diaphragm Type
Fuel / Oil Mixture
Not Required
Fuel Tank Capacity
0.5L
Oil Tank Capacity
0.08L
4-Stroke Crank Case Oil
10W-30
Overall Length
69-3/4" (177 cm)
Dry Weight
13.0 lbs (5.9 kg)
When
QUALITY&SERVICE
Counts – ChooseMakita
OUTDOOR
Power Equipment
Bump & Feed
Trimmer Head
(Standard Equipment)
(Part No. B-05131)
STANDARD EQUIPMENT INCLUDES:
Bump & FeedTrimmer Head (B-05131), Protective Guard (452259-9),Trimmer Head Protective GuardAttachment (135398-7),
Box Driver 16-17 (783013-3), Hex Wrench 4 (783202-0), Hex Wrench 5 (783217-7), Engine Oil Set, Starter Rope (444018-5),
Spark Plug (168534-0), Shoulder Harness (125516-5),Accessory Bag (831304-7)
Makita's Most Powerful 4-Stroke Line Trimmer for Professional Applications
• Patented Lubrication System enables Makita 4-Stroke
Line Trimmer to be used on any Angle and Slopes
• MM4 Engine uses 40% Less Fuel when compared
to a 2-Stroke equivalent
• Equipped Easy Start System with
Auto Decompression for Faster
Easier Starting
• Adjustable Loop Handle with
Extension Bar for Optional Brush
Cutter Operation
• Clean Exhaust Emissions and
Lower Fuel Consumption
Heavy Duty Inner
Solid Steel Straight
Shaft Design
16" / 33.5cc 4-Stroke Line Trimmer
SPECIFICATIONS
Cutting Width: 10" (254 mm) With Blade
16" (406 mm) With Line Head
Displacement
33.5cc
Maximum Engine Power 1.07 Kw / 1.44 HP
Carburetor
Diaphragm Type
Fuel / Oil Mixture
Not Required
Fuel Tank Capacity
0.65 L
Oil Tank Capacity
0.1 L
4-Stroke Crank Case Oil
10W-30
Overall Length
71-1/4" (181 cm)
Dry Weight
14.8 lbs (6.7 kg)
EBH341L
Low Vibration, Extreme
Fuel Cost Savings
SPLIT SHAFT UNIT &ATTACHMENTS TOOL BAG
195638-5
Description
Specifically Designed for Split Shaft Engine
Units and Attachments
• Weather Resistant Durable Nylon Cordura Construction
• External Pockets for storage of Accessories and more
• Dual and Single inside pockets for maximum storage versatility
• Internal straps retain Tool and Accessories during transit
• Approximately 48" x 14" x 12" (120 cm x 35 cm x 12 cm)
Split Shaft Units
Sold Separately
EM2650UH
STANDARD EQUIPMENT INCLUDES:
9˝ Star Blade (B-14118),Trimmer Head Protective GuardAttachment (135398-7), Shoulder Harness (123143-2), Box Driver 16-17 (783013-3),
Hex Wrench 5 (783232-1), Hex Wrench 4 (783223-2), Starter Rope (444023-2), Spark Plug (168534-0), Oil Bottle (242072-1),
Tool Cover (456924-2),Accessory Bag (831304-7)
9" / 25.4cc 4-Stroke Brush Cutter
SPECIFICATIONS
Cutting Width
9" (228 mm)
Displacement
25.4cc
Maximum Engine Power 0.77 Kw / 1.1 hp
Carburetor
Diaphragm Type
Fuel / Oil Mixture
Not Required
Fuel Tank Capacity
0.6L
Oil Tank Capacity
0.08L
4-Stroke Crank Case Oil
10W-30
Overall Length
69-1/2" (177 cm)
Dry Weight
12.1 lbs (5.5 kg)
Quiet, Low Vibration,
Extreme Fuel Cost Savings
Multi-position lubrication system enables engine to be inclined to
any angle for continuous operation
• Patented lubrication system enables Makita 4-Stroke Brushcutters & Line Trimmers to be used
on any angles and slopes
• Anti-vibration system for fatigue free use
• Clean exhaust emissions and
lower fuel consumption
• Easy starting
• 40% less fuel consumption
compared to 2-stroke equivalent
