26 / 220
DHR171RYJB
STANDARD EQUIPMENT INCLUDES:
DHR171RYJB:
Two 18V (Compact) Li-ion Batteries
BL1815N (196235-0), Rapid Charger (DC18RC), Side Handle (158057-6),
Depth Gauge (415486-9), Battery Cover (450128-8), Interlocking Case (197212-5)
DHR171ZB:
Tool Only. Batteries and Charger Sold Separately.
Side Handle (158057-6), Depth Gauge (415486-9)
Lightweight, 2-Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Rotation Only
• Sub-compact size and weight ideal for fast and fatigue free drilling of holes in concrete and masonry
• Ideal for overhead anchor / installation applications
• Rubber joint construction suppresses transmission of vibration to battery, minimizing battery failures due to
terminal breakage or poor electrical contact
• Brushless DC motor with high power to weight
and size ratio
• One touch SDS-PLUS sliding chuck enables quick
and easy bit changes
• LED job light
with afterglow
feature illuminates
drilling area
5/8" Sub-Compact Rotary Hammer
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Capacities:
Concrete
11/16" (17 mm)
Steel
3/8" (10 mm)
Wood
1/2" (13 mm)
Impact Energy 1.1 J (0.81 ft. lbs)
No Load Speed 0 - 680 RPM
Blows Per Minute 0 - 4,800 BPM
Overall Length 10-3/4" (273 mm)
Net Weight
4.0 lbs (1.8 kg)
DHR171ZB
Variable 2-Speed,
Reversible
makita.ca
24
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
18V LXT
Concrete Tools / Drills
Makita offers a wide variety of
ACCESSORIES!
DHR165Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Side Handle (158057-6), Depth Gauge (415486-9)
Lightweight, 2-Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Rotation Only
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Torque limiter stops rotation if bit jams for increased operator safety and enhanced motor protection
• Easily accessible forward / reverse switch for operator convenience
• Electric brake stops bit rotation immediately for maximum operator safety
• 2 operating modes: Rotation / Rotation + Hammer
• One touch SDS-PLUS sliding chuck enables quick and easy bit changes
Variable Speed, Reversible
5/8" Rotary Hammer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
5/8" (16 mm)
Steel
1/2" (13 mm)
Wood
15/16" (24 mm)
Impact Energy
1.3 J (1 ft. lbs)
No Load Speed
0 - 1,600 RPM
Blows Per Minute
0 - 5,300 BPM
Overall Length
11-3/4" (297 mm)
Net Weight
4.2 lbs (1.9 kg)
Ideally Suited For Concrete Footings And Wall Construction
• Multi-Directional Trigger enables operation from two directions for increased maneuverability
• Protective Battery and Switch Covers prevent damage due to contamination
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Vibrations Per Minute
12,500 VPM
Vibrator Diameter
1" (2.5 cm)
Shaft Length 94-1/2" (240 cm)
Overall Length
105-1/2" (268 cm)
Net Weight
11.5 lbs (5.2 kg)
DVR850RFE, DVR850Z, DVR450RFE, DVR450Z, DVR350RFE, DVR350Z
Concrete Vibrators
DVR850RFE
STANDARD EQUIPMENT INCLUDES:
DVR850RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3), Rapid Charger (DC18RC),
Battery Cover (450128-8), FlexibleAssembly (126208-9),
Plastic Carrying Case (821766-7)
DVR850Z:
Tool Only. Batteries and Charger Sold Separately.
FlexibleAssembly (126208-9)
DVR850Z
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Vibrations Per Minute
13,000 VPM
Vibrator Diameter
1" (2.5 cm)
Shaft Length 47-1/4" (120 cm)
Overall Length
58-1/2" (148 cm)
Net Weight
7.7 lbs (3.5 kg)
DVR450RFE
STANDARD EQUIPMENT INCLUDES:
DVR450RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3), Rapid Charger (DC18RC),
Battery Cover (450128-8), FlexibleAssembly (126206-3),
Plastic Carrying Case (141481-0)
DVR450Z:
Tool Only. Batteries and Charger Sold Separately.
FlexibleAssembly (126206-3)
DVR450Z
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Vibrations Per Minute
13,000 VPM
Vibrator Diameter
1" (2.5 cm)
Shaft Length 31-1/2" (80 cm)
Overall Length
42-3/4" (108 cm)
Net Weight
6.6 lbs (3.0 kg)
DVR350RFE
STANDARD EQUIPMENT INCLUDES:
DVR350RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3), Rapid Charger (DC18RC),
Battery Cover (450128-8), FlexibleAssembly
(126207-1), Plastic Carrying Case (821766-7)
DVR350Z:
Tool Only. Batteries and Charger
Sold Separately.
FlexibleAssembly (126207-1)
DVR350Z
DVR350RFE
Battery
Cover
DHP451RFE
STANDARD EQUIPMENT INCLUDES:
DHP451RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8),
Side Handle (122750-8),Two Double Ended Bits 2-45 (784637-8), Stopper Pole (122576-8), 1/2" Keyless Chuck (763191-5),
Bit Holder (452947-8), Hook (346449-3), Plastic Carrying Case (140354-4)
DHP451Z:
Tool Only. Batteries and Charger Sold Separately.
Side Handle (122750-8),Two Double Ended Bits 2-45 (784637-8), Stopper Pole (122576-8), 1/2" Keyless Chuck (763191-5),
Bit Holder (452947-8), Hook (346449-3)
Features 3 Speed RPM Range
• 16 Clutch Settings deliver up to 560 in. lbs of torque
• Three Speed Gearing for more efficiency
• Dual LED Lights with Afterglow feature
• Shift-Lock drive converts from Hammer to Drill to Driver mode
• All Metal Gears for more
efficient power
transmission
1/2" Hammer Drill / Driver
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Capacities:
Steel
1/2" (13 mm)
Masonry
5/8" (15.8 mm)
Wood
2 - 9/16" (65 mm)
No Load Speed:
1st Speed
0 - 300 RPM
2nd Speed
0 - 600 RPM
3rd Speed 0 - 1,700 RPM
Blows Per Minute:
1st Speed
0 - 4,500 BPM
2nd Speed 0 - 9,000 BPM
3rd Speed 0 - 25,500 BPM
Maximum Torque
560 in. lbs (63 Nm)
Overall Length 9 - 7/8" (250 mm)
Net Weight
5.5 lbs (2.5 kg)
DHP451Z
Variable 3-Speed,
Reversible
DUT131Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Side Handle (140G50-6), 1/2" Drill Chuck (766016-2),
Chuck Key (763448-4), Front Cover (459241-9)
Makita's FIRST Cordless Mixing Tool!
• Brushless DC motor with high power to weight and size ratio provides maximum power and run time
• Variable 2-speed (high / low ranges) suitable for a variety of materials, including mortar or paint
• Front guard, battery and switch covers protects tool from damage due to contamination by mixing materials
• Lock-on button for easy continuous operation
• Soft start motor eliminates splash back when mixing at high speeds
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
Mixer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Blade Diameter
6-1/2" (165 mm)
No Load Speed:
Low
0 - 350 RPM
High
0 - 1,300 RPM
Overall Length
12-1/8" (307 mm)
Net Weight
5.3 lbs (2.4 kg)
Variable 2-Speed, Soft Start
