General Catalogue

18V LXT

Saws /Woodworking Tools

makita.ca

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

When

QUALITY&SERVICE

Counts – ChooseMakita

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Blade (1 Ea. B-20432, 1 Ea. 723063-A-5), Hex Wrench 3 (783201-2)

Ultra-Compact And Lightweight Design For Maximum Versatility

and Maneuverability

• Multi-position switch (tool handle & tool body) with lock-off levers for easier operation, maximum

versatility and operator safety

• Battery protection system provides over-discharge, temperature and circuit protection for enhanced

performance, battery cycle life and overall battery life

• One-handed, fast tool-less blade changes

• LED joblight with afterglow feature

Reciprocating Saw

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Maximum Cutting Capacities:

Pipe

2" (50 mm)

Wood (12" Blade)

2" (50 mm)

Strokes Per Minute

0 - 3,000 SPM

Length of Stroke

1/2" (13 mm)

Overall Length

15-5/8" (398 mm)

Net Weight

2.7 lbs (1.2 kg)

DJR183Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

3-1/4" C.T. Mini Planer Blade (D-16966), Blade GuideAssembly (123010-1),

Socket Wrench 9 (782209-3), Guide Rule (195055-9)

Incorporates Makita's Battery Protection System

• Battery Protection System provides Over-Discharge, Temperature and Current Protection for

enhanced performance, battery cycle life and overall battery life

• Base Plate Foot protects materials and blade from damage

• Single Chamfering Groove enables quick and easy chamfering of corners

• Depth Adjustment Knob with Click Stops for precision planing applications

• Large Lock-Off Safety Lever prevents accidental start up

• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation

3-1/4" Planer

SPECIFICATIONS

Battery Capacities

18V Li-Ion

No Load Speed

14,000 RPM

Maximum Capacities:

Planing Width

3-1/4" (82 mm)

Planing Depth

5/64" (2 mm)

Shiplapping

11/32" (9 mm)

Overall Length

13-1/8" (333 mm)

Net Weight

7.5 lbs (3.4 kg)

Electric Brake

DKP180Z

DRT50ZJX6

Compact Router

STANDARD EQUIPMENT INCLUDES:

DRT50ZJX6:

Tool Only. Batteries and Charger Sold Separately.

1/4" Collet Cone (763637-1), 3/8" Collet Cone (763619-3),

Trimmer Guide (122703-7), Straight Guide (122965-7),Template Guide 10 (343577-5),Template Guide 16 (193043-0), Wrench 13 (781039-9),

Wrench 22 (781011-1), Plunge Base Set (196094-2), Guide Holder Set (195564-8), Offset Base Set (196093-4),

Dust Nozzle Set-Plunge Base (P-80011), Dust Nozzle Set (195559-1), Side Handle (153489-2), Interlocking Case (197213-3)

DRT50ZX4:

Tool Only. Batteries and Charger Sold Separately.

1/4" Collet Cone (763637-1), 3/8" Collet Cone (763619-3),

Trimmer Guide (122703-7),Template Guide 10 (343577-5), Wrench 13 (781039-9), Wrench 22 (781011-1), Dust Nozzle Set (195559-1)

Makita's FIRST CORDLESS ROUTER!!

• Accepts Makita and other industry standard 2 piece template guides

• Brushless (BL) DC motor generates less heat buildup and is ideal for

prolonged use in manufacturing and production applications

• Soft start feature gradually increases speed to eliminate start up shock

• Constant speed control maintains constant speed under heavy load

• Variable speed dial allows operator to adjust speed based on materials

• Flat top design provides a stable platform when changing bits

• Shaft lock button enables quick and easy bit changes and

eliminates the need for dual wrenches

• Aluminum base and housing offer increased durability

and accuracy

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Collet Capacity

1/4", 3/8" (6.35 mm, 9.53 mm)

No Load Speed

10,000 - 30,000 RPM

Overall Height

8-7/8" (226 mm)

Net Weight

3.4 lbs (1.5 kg)

Variable Speed

DJR188RMEB

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Blade (1 Ea. B-20432, 723063-A-5)

SUB-COMPACT Size - PROFESSIONAL Power

• Sub-compact size and weight ideal for fast and fatigue free cutting

• Shorter overall length enables easy access between 16" on-centre studs

• Brushless DC motor with high power to weight and size ratio

• eXtreme Protection Technology (XPT) offers maximum protection against dust, dirt and debris for optimal

performance in extreme conditions

• Electric brake stops blade immediately for maximum operator safety

• Constant speed control maintains constant speed under heavy load

• Variable speed trigger allows operator to adjust speed based on materials or application

• Tool-less blade change feature enables fast and easy blade changes on the jobsite

• LED job light with pre-glow and after-glow features

illuminates work area

Sub-Compact Reciprocating Saw

DJR188ZB

Toolless Blade Change,

Variable Speed

SPECIFICATIONS

Battery Capacities 18V Li-Ion

Maximum Cutting Capacities:

Pipe

5-1/8" (130 mm)

Wood (w/11-3/4˝ blade)

10" (255 mm)

Strokes Per Minute 0 - 3,000 SPM

Length of Stroke 13/16" (20 mm)

Overall Length 12-1/2" (316 mm)

Net Weight

5.1 lbs (2.3 kg)

DPJ180Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

4" CTCutter Blade 6T (A-95118),Angle Guide (123148-2), Dust Bag (123150-5),

Lock Nut Wrench 20 (782401-1), Set Plate (415579-2)

Lightweight and Compact Design with Enhanced Ergonomics

for Maximum Maneuverability

• Anti-Restart feature prevents accidental start up of tool during battery changing when the switch

is locked in the on position

• Electronic Current Limiter with Warning Light prevents

motor burnout caused by overloading

• Depth Adjustment Knob enables quick

adjustment for #0, #10 and #20 biscuits

• Rack-and-Pinion Angle Guide enables

precise adjustment of fence

• Cast Aluminum

Adjustable Fence

with positive stops at

0°, 45° and 90°

Plate Joiner

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Blade Diameter

4" (100 mm)

Maximum Cutting Depth

3/4" (20 mm)

No Load Speed

10,000 RPM

Overall Length

13-3/4" (351 mm)

Net Weight

7.1 lbs (3.2 kg)

DBO180Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

5"Abrasive Disc 120G (1 Ea. 794520-1), Dust BagAssembly (135222-4),

Hook & Loop Pad (743081-8)

Hook And Loop Pad

• 3-Stage (Low - Medium - High) Electronic Speed

Selection Button adjusts sanding speed based on

materials or application

• Pad Brake quickly stops motor after tool is

turned off

• Fast Random-Orbit Action for aggressive

stock removal

• Efficient Dust Extraction Rate for more

efficient operation

5" Random Orbit Sander

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Pad Diameter

4-7/8" (123 mm)

Abrasive Disc Diameter

5˝" (125 mm)

Orbits Per Minute 7,000 - 11,000 OPM

Orbit Diameter

1/8" (2.8 mm)

Overall Length

6-7/8" (175 mm)

Net Weight

2.4 lbs (1.1 kg)

3-Stage Speed Range

(Low - Medium - High)

DRT50ZX4
