Electric
Power Tools
makita.ca
127
“SJS” Technology Prevents Kickback If Bit
Jams Protecting Both The Operator And Tool
• High speed type, is a versatile straight grinder, ideal for grinding and sharpening (GD0800C Only)
• Low speed type,with very high torque is ideal for grinding and finishing
work using brushes, flap discs and points (GD0810C Only)
• “Zig - Zag” varnish on armature and powder coating on field to protect motor from abrasion
• Labyrinth Construction seals gear housing and bearings from contamination
• Electronic constant speed controller with soft start and variable speed dial
• Side handle is included for excellent operator control
SPECIFICATIONS
Collet Capacity
1/4˝ (6.4 mm)
GD0800C:
Maximum Wheel Point Diameter 1˝ (25 mm)
GD0800C:
No Load Speed
7,000 - 28,000 RPM
GD0810C:
Maximum Wheel Point Diameter 2˝ (50 mm)
GD0810C:
No Load Speed
1,800 - 7,000 RPM
AMPS (120V)
6.6 A
Overall Length
14-5/8˝ (371 mm)
Net Weight
3.7 lbs. (1.7 kg)
High Speed Type
Low Speed Type
STANDARD EQUIPMENT INCLUDES:
Collet Cone Set 1/4˝(192986-3),Wrench 13 (781203-2),
Wrench 19 (781206-6), Side Handle Set (192985-5) shown with optional accessory
GD0800C
STANDARD EQUIPMENT INCLUDES:
Collet Cone Set 1/4˝(192986-3),Wrench 13 (781203-2),
Wrench 19 (781206-6), Side Handle Set (192985-5) shown with optional accessory
GD0810C
“SJS” Technology
Light Weight And Slim Housing For Easy Handling
• Conveniently located thumb switch for operator comfort (GD0601 Only)
• Large paddle switch with lock-off feature (GD0600 Only)
• Protective Zig-Zag varnish seals the motor from dust and debris for longer life
• Round-shaped collet nut reduces the possibility of damage or scratches to workpiece
• High heat resistance
• Vent Slots designed to direct air exhaust away from the user
• AC/DC switch for use with alternative power source
Anti-Slip Rubber Cover, AC/DC
SPECIFICATIONS
Collet Capacity
1/4˝ (6.4 mm)
Maximum Wheel Point Diameter 1-1/2˝ (38 mm)
No Load Speed
25,000 RPM
AMPS (120V)
3.5 A
Overall Length
14-1/8˝ (359 mm)
Net Weight
3.7 lbs. (1.7 kg)
Thumb Switch
Paddle Switch
STANDARD EQUIPMENT INCLUDES:
1/4˝ Collet Cone (763625-8), 2 Ea.Wrench (781039-9)
GD0601
STANDARD EQUIPMENT INCLUDES:
1/4˝ Collet Cone (763625-8), 2 Ea.Wrench (781039-9)
GD0600
GD0800C, GD0810C
1/4˝ Die Grinders
GD0601, GD0600
1/4˝ Die Grinders
STANDARD EQUIPMENT INCLUDES:
WheelCover(123200-6),WrenchHolder(410047-0),Wrench24(781030-7),HexWrench6(783204-6)
Two-Stage Safety Paddle Switch (AC)
• Designed for maximum durability and ease of operation on the jobsite
• Low profile design ideal for use in constricted spaces
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
6˝ Straight Grinder
SPECIFICATIONS
Maximum Capacities:
Wheel
6˝ (150 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
5,600 RPM
AMPS (120V)
7.0 A
Overall Length
23-1/4˝ (590 mm)
Net Weight
11.5 lbs (5.2 kg)
GS6000
STANDARD EQUIPMENT INCLUDES:
WheelCover(123199-5),WrenchHolder(410047-0),Wrench24(781030-7),HexWrench6(783204-6)
Two-Stage Safety Paddle Switch (AC)
• Designed for maximum durability and ease of operation on the jobsite
• Low profile design ideal for use in constricted spaces
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
5˝ Straight Grinder
SPECIFICATIONS
Maximum Capacities:
Wheel
5˝ (125 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
5,600 RPM
AMPS (120V)
7.0 A
Overall Length
23-1/4˝ (590 mm)
Net Weight
11.1 lbs (5.0 kg)
GS5000
Anti-Slip Rubber Cover
Anti-Slip Rubber Cover
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Grinder Wheel
Shown Not Included
Grinder Wheel
Shown Not Included
