METALWORKING
makita.ca
118
STANDARD EQUIPMENT INCLUDES:
4˝ Depressed Centre Wheel (D-20775), Lock Nut Wrench (782420-7), Lock Nut (224573-1), Inner Flange (224377-1) ,
Wheel CoverAssembly (125885-4), Side Handle (153504-2), Plastic Carrying Case (824736-5)
Thumb Switch with Lock-On (AC)
• Labyrinth construction seals motor and bearings from contamination
• Zig - Zag varnish on armature and powder coating on field to protect motor from abrasion
• Engineered for durability – double protection against dust, high quality motor and machined gears
• Ergonomic soft rubber grip for vibration absorption and comfortable operation
• Slim housing design for easy handling and maneuverability
• Thumb switch conveniently located for operator comfort
Labyrinth Construction,
Lightweight Only 3.1 Lbs, Toggle Switch
4˝ Angle Grinder With Slim Motor Housing
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
4˝ (100 mm)
Sanding Disc
4˝ (100 mm)
Wire Cup Brush
3˝ (75 mm)
Spindle Thread
M10 x 1.25
No Load Speed
11,000 RPM
AMPS(120V)
6.0 A
Overall Length
10-1/2˝ (266 mm)
Net Weight
3.7 lbs. (1.7 kg)
GA4030K
STANDARD EQUIPMENT INCLUDES:
4˝ Depressed Center Wheel (D-20775), Lock Nut Wrench (782420-7), Wheel Cover (135476-3), Inner Flange (224377-1), Lock Nut (224573-1),
Side Handle (153489-2)
Two Stage Safety Paddle Switch (AC/DC)
• Labyrinth construction seals motor and bearings from contamination
• Large paddle switch for easy operation right or left handed
• Removable side handle can be mounted on left or right side of tool
4˝ Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
4˝ (100 mm)
Sanding Disc
4˝ (100 mm)
Wire Cup Brush
3˝ (75 mm)
Spindle Thread
M10 x 1.5
No Load Speed
11,000 RPM
AMPS (120V)
7.5 A
Overall Length
10-3/4˝ (273 mm)
Net Weight
4.4 lbs. (2.0 kg)
9556PB
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
MAKITA ANGLE GRINDER FEATURES QUICK REFERENCE CHART
Model No.
Wheel
Diameter
Power
Source
Rated
Amperage
Switch
Type
Two-Stage
Safety
Switch
Lock-On
Switch
No
Lock-On
Switch
Super Joint
System
(SJS)
Electric or
Mechanical
Brake
Anti-
Restart
Feature
Soft Start
Feature
Constant
Speed
Control
Electronic
Current
Limiter
Torque
Limiter
Variable
Speed
GA4030K
4"
AC 6.0 A Thumb
●
9556PB
AC/DC 7.5 A Paddle
●
●
DGA451RFE / F / Z
4-1/2"
18V Li-Ion
Thumb
●
●
●
GA4530K
AC 6.0 A Thumb
●
GA4534
AC/DC 6.0 A Paddle
●
GA4542C01
AC 12.0 A Thumb
●
●
●
●
●
●
GA4543C01
AC 12.0 A Thumb
●
●
●
●
●
●
●
SA4542C
AC 12.0 A Thumb
●
●
●
●
●
●
9557NB
AC/DC 7.5 A Thumb
●
9557PB / K
AC/DC 7.5 A Paddle
●
●
9564CV
AC 12.0 A Thumb
●
●
●
●
●
●
9564P
AC/DC 10.0 A Paddle
●
●
9564PCV
AC 13.0 A Paddle
●
●
●
●
●
●
GA5010
5"
AC/DC 10.5 A Trigger
●
GA5010Z
AC/DC 10.5 A Trigger
●
GA5020
AC/DC 10.5 A Trigger
●
●
●
GA5020C
AC 12.5 A Trigger
●
●
●
●
●
●
●
GA5020Y
AC/DC 10.5 A Trigger
●
●
●
GA5030K
AC 6.0 A Thumb
●
GA5042C01
AC 12.0 A Thumb
●
●
●
●
●
●
GA5043C01
AC 12.0 A Thumb
●
●
●
●
●
●
●
9005B
AC/DC 10.0 A Trigger
●
9005BY
AC/DC 10.0 A Trigger
●
9005BZ
AC/DC 10.0 A Trigger
●
9015DB
AC/DC 12.5 A Paddle
●
9015DBZ
AC/DC 12.5 A Trigger
●
9558NB
AC/DC 7.5 A Thumb
●
9558PB
AC/DC 7.5 A Paddle
●
●
9565CV
AC 12.0 A Thumb
●
●
●
●
●
●
9565PCV
AC 13.0 A Paddle
●
●
●
●
●
●
GA6010
6"
AC/DC 10.5 A Trigger
●
GA6010Z
AC/DC 10.5 A Trigger
●
GA6020
AC/DC 10.5 A Trigger
●
●
●
GA6020C
AC 12.5 A Trigger
●
●
●
●
●
●
●
GA6020Y
AC/DC 10.5 A Trigger
●
●
●
GA6042C01
AC 12.0 A Thumb
●
●
●
●
●
●
GA6043C01
AC 12.0 A Thumb
●
●
●
●
●
●
●
9016DB
AC/DC 12.5 A Paddle
●
9016DBZ
AC/DC 12.5 A Trigger
●
9566CV
AC 12.0 A Thumb
●
●
●
●
●
●
GA7010C
7"
AC 15.0 A Paddle
●
●
●
●
GA7020
AC/DC 15.0 A Paddle
●
GA7031
AC/DC 15.0 A Trigger
●
●
GA7031Y
AC/DC 15.0 A Trigger
●
●
GA7050
AC/DC 15.0 A Paddle
●
GA7911
7" / 9" AC/DC 15.0 A Trigger
●
GA9031
9"
AC/DC 15.0 A Trigger
●
●
GA9031Y
AC/DC 15.0 A Trigger
●
●
