130
STANDARD EQUIPMENT INCLUDES:
Punch(792728-1),Die(792292-2),Hexwrench(783201-2),Wrench(781019-5),PlasticCarryingCase(821550-0)
Powerful Motor For Continuous Operation In Up To 10 Gauge
Mild Steel and 13 Gauge Stainless Steel
• All ball and needle bearings for longer life
• Built-in thickness gauge for operator convenience
• Easy punch and die replacement for less down time
• Low noise level - Just 81 dB
• Lock-On Button enables easy continuous operation
10 ga Nibbler
SPECIFICATIONS
Maximum Capacities:
Mild Steel
10 ga. (3.2 mm)
Stainless
13 ga. (2.5 mm)
Aluminum
10 ga. (3.5 mm)
AMPS (120V)
6.2 A
Strokes Per Minute
1,300 SPM
Minimum Cutting Radius:
Outside Edge
5-1/16˝ (128 mm)
Inside Edge
4-3/4˝ (120 mm)
Overall Length
8-7/8˝ (225 mm)
Net Weight
7.4 lbs (3.4 kg)
JN3201J
Powerful Motor For
Continuous Operation In Up
To 10 Gauge Mild Steel and
13 Gauge Stainless Steel
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
Wrench (781028-4), Hex Wrench (783208-8), Die (A-15051), Punch (A-83951)
Clean, Precise Work In Keystone Plate, Deck Plate And
Other Corrugated Sheet Materials
• Die rotates 360
°
with positive stops at 0
°
, 90
°
Left, 90
°
Right and 180
°
for simple and accurate
adjustment on the jobsite
• Large 1/4˝ stroke
• Ergonomic slim body design for easy gripping
• Built-in thickness gauge for operator convenience
• Easy punch and die replacement for less down time
• Sliding lock-on switch for operator convenience
16 ga Nibbler
SPECIFICATIONS
Maximum Capacities:
Mild Steel
16 ga. (1.6 mm)
Stainless
18 ga. (1.2 mm)
Aluminum
13 ga. (2.5 mm)
AMPS (120V)
5.0 A
Strokes Per Minute
2,200 SPM
Minimum Cutting Radius:
Outside Edge
2˝ (50 mm)
Inside Edge
1-3/4˝ (45 mm)
Overall Length
10-1/4˝ (261 mm)
Net Weight
3.5 lbs. (1.6 kg)
JN1601
STANDARD EQUIPMENT INCLUDES:
JS1000:
Side Blade Set (792536-0), Center Blade (792537-8), Hex Wrench (783201-2)
JS1601:
Side Blade Set (792536-0), Center Blade (792537-8), Hex Wrench (783201-2)
Fast Cutting Action In Steel And
Aluminum With Increased Comfort,
Maneuverability And Control
• JS1000 - Minimum outside cutting radius of just 9-7/8˝
• JS1601 - Minimum outside cutting radius of just 1-3/16˝
• Small circumference motor housing for increased
comfort, maneuverability and control
• Ribbed motor housing and rear cover for improved
gripping during operation
• Powerful motor with 380 W Continuous Input Rating
• Sliding On / Off thumb switch
• On-board hex wrench storage
• Removes continuous metal curl with no distortion
• 360° rotatable shear head
Straight Shears
JS1000 SPECIFICATIONS
Maximum Capacities:
Steel
20 ga. (1.0 mm)
Aluminum
12 ga. (2.5 mm)
AMPS (120V)
3.3 A
Strokes Per Minute
4,500 SPM
Minimum Cutting Radius 1-3/16˝ (30 mm)
Overall Length
12-5/8˝ (322 mm)
Net Weight
3.1 lbs. (1.4 kg)
JS1601 SPECIFICATIONS
Maximum Capacities:
Steel
16 ga. (1.6 mm)
Aluminum
12 ga. (2.5 mm)
AMPS (120V)
3.3 A
Strokes Per Minute
4,500 SPM
Minimum Cutting Radius 9-7/8˝ (250 mm)
Overall Length
12-5/8˝ (320 mm)
Net Weight
3.1 lbs. (1.4 kg)
JS1000 - 20 ga Straight Shear
JS1601 - 16 ga Straight Shear
SHEAR & NIBBLER ACCESSORIES
Part No.
Description
For Model(s)
A-83951
Punch
JN1601, DJN161RFE / F / Z
A-15051
Die
792728-1
Punch
JN3200, JN3201J
792292-2
Die
792536-0
Left / Right Blade Set
JS1000, JS1670
792537-8
Center Blade
792742-7
Right Blade
JS1300, DJS130RFE / F / Z
792744-3
Center Blade
792743-5
Left Blade
191383-0
Blade Set
JS1600, JS1602
792533-6
Left / Right Blade Set
DJS161RFE
792534-4
Center Blade
792287-5
Blade Set
JS3200, JS3201J
135168-4
Shear Blade Set
JS8000
STANDARD EQUIPMENT INCLUDES:
Quick Coupler (10TT-8)
MAC5500GS : Powered By Subaru SP-170 Engine
MAC5500G : Powered By 4 Stroke Honda GX160 Engine
• Oil lubricated for cooler operation and reduced noise
• High output V-twin cast iron pump runs cooler than inline pumps and delivers maximum performance
and operational life
• Big Bore
TM
cylinder and piston feature high output at lower RPM with reduced heat buildup, less noise
and longer operational life
• Easy view oil gauge and large pressure gauges for quick identification
• Air pressure regulator enables easy adjustment of line pressure
• Features 3 quick connect air hose fittings
6.0 H.P Gas Power Air Compressor
SPECIFICATIONS
Gas Motor
6.0 H.P.
Pump
Oil-Lubricated
Tank
2 x 5 Gallon
Performance
12.5 CFM @ 100 PSI
Maximun Pressure
130 PSI
Dimensions (L x W x H with handle )
50˝ x 18˝ x 24˝
(127 cm x 46 cm x 61 cm)
Net Weight
190 lbs. (86.2 kg)
MAC5500G
MAC5500GS
STANDARD EQUIPMENT INCLUDES:
Quick Coupler (10TT-8)
Requires Minimum 15 AMP Circuit
• Oil lubricated for cooler operation and reduced noise
• High output V-twin cast iron pump runs cooler than inline pumps and delivers maximum performance
and operational life
• Big Bore
TM
cylinder and piston feature high output at lower RPM with reduced heat buildup,
less noise and longer operational life
• Low amperage draw reduces incidents of tripped breakers and voltage drops that cause premature
motor failure
• Easy view oil gauge and large pressure gauges for quick identification
• Air pressure regulator enables easy adjustment of line pressure
• Features 3 quick connect air hose fittings
Oil Lubricated
3 H.P. Electric Air Compressor
SPECIFICATIONS
Motor
3 H.P.
Pump
Oil-Lubricated
Cut In Pressure
100 PSI
Cut Out Pressure
125 PSI
Tank
2 x 4 Gallon
Performance
6 CFM @ 100 PSI
Maximum Pressure
150 PSI
Dimensions: (L x W x H, with handle)
42˝ x 18˝ x 26˝
(1,067 mm x 457 mm x 660 mm)
Net Weight
160 lbs. (72.6 kg)
MAC3001
