DPC6430
STANDARD EQUIPMENT INCLUDES:
12˝ Cutting disc F/stone (966 121 120), Universal wrench 13/19, (941 719 140),Torx wrench (940 827 000), Screwdriver (944 340 001),
WaterAttachment Kit (394 365 630)
12˝ Cutting Wheel,Top Mount Decompression Valve Reduces
The Start Up Force Required By 70%
• Advanced 5 stage air filtration system for cleaner operation
• Large air intake space for increased engine cooling
• Air inlet ports reduce noise up to 40%
• Reversible cutting arm can be mounted in the center for flush cutting
• Electronic ignition with rev limiter
• Required to use 2 Cycle Synthetic Oil
Required to use
2 Cycle Synthetic Oil
(Part No. T-00739C)
Reduced Engine Emission With
Catalytic-Converter
12˝ / 4.4 H.P. 2 Stroke Power Cutter (20 mm Arbor)
SPECIFICATIONS
Displacement
3.9 cu.in (64 cc)
Maximum Power
3.2 kW (4.4 H.P.)
Fuel / Oil Mixture
50:1
Ignition System
Electronic
Fuel Tank Capacity
1.1 L
No Load Speed (Engine)
9,350 RPM
Max. Spindle Speed
4,300 RPM
Arbor
20 mm
Max. Cutting Depth 3-13/16˝ (97 mm)
Dry Weight
20.7 lbs. (9.4 kg)
STANDARD EQUIPMENT INCLUDES:
16" Cutting Disk F/Stone (20 mm) (966 161 020),Tool Kit (957 004 006), WaterAttachment Kit (394 365 630)
16˝ / 5.6 H.P. 2 Stroke Power Cutter (20 mm Arbor)
SPECIFICATIONS
Displacement
4.9 cu.in (81 cc)
Maximum Power
4.2 kW (5.6 H.P.)
Fuel / Oil Mixture
50:1
Ignition System
Electronic
Fuel Tank Capacity
1/3 Gal (1.1 L)
No Load Speed (Engine)
9,350 RPM
Max. Spindle Speed
3.820 RPM
Arbor
20 mm
Max. Cutting Depth
5-3/4˝ (147 mm)
Dry Weight
23.4 lbs (10.6 kg)
EK8100
Required to use
2 Cycle Synthetic Oil
(Part No. T-00739C)
16˝ Cutting Wheel
Compliant with CARB Tier 3, EPA Phase 2 and EU Stage 2 Regulations
• NEW Scavenging Losses Rejection (SLR) Muffler recycles exhaust unburnt gas emissions for
increased operational efficiency and cleaner emissions
• Advanced 5 Stage Air Filtration System for cleaner operation and enhanced operational life
• Large Air Intake for maximum engine cooling
• Reversible Cutting Arm enables cutting disc to be side or centre mounted
for optimal operational versatility in a variety of applications
• Electronic Ignition with Rev Limiter
• Always use with 2 Cycle Synthetic Oil
Top Mount Decompression Valve
Reduces Required Start Up Force By 70%
2 STROKE
POWER
4 STROKE
POWER
The FIRST 4-Stroke Power Cutters Available On The Market!
Save The Cost Of The Power Cutter With Fuel Savings Alone!
• Reduced noise and fuel consumption versus competitive 2-stroke models for maximum operator comfort and reduced operational costs
• No fuel mixing prevents damage due to improper fuel mixture and eliminates need to carry separate mixed fuel
• Cleaner 4-stroke emissions limits environmental impact and reduced carbon buildup in engine
• Automatic decompression valve reduces required start up force by 40% versus competitive 2-stroke models
SPECIFICATIONS
Displacement
4.6 cu.in (75.6 cc)
Maximum Power
3.0 kW (4.1 H.P.)
Ignition System
Non-Contact, magnet type
Fuel Tank Capacity
1/3 Gal (1.1 L)
No Load Speed (Engine)
9,100 RPM
Maximum Spindle Speed
4,300 RPM
Maximum Cutting Depth
4-13/16˝ (122 mm)
Dry Weight
28.4 lbs (12.9 kg)
Arbor:
EK7651HD
1˝ (25.4 mm)
EK7651H
20 mm
EK7651HD
1˝ Arbor,
EK7651H
20 mm Arbor
14˝ / 4.1 H.P. 4 Stroke Power Cutters
STANDARD EQUIPMENT INCLUDES:
EK7651HD:
Tool Kit (195488-8), WaterAttachment Kit (195533-9), Oil Bottle Set (195532-1), Prefilter Set (195945-6), Spark Plug (168652-4), Starter Rope (444040-2), Dust Bag (166106-5)
EK7651H:
Tool Kit (195488-8), WaterAttachment Kit (195533-9), Oil Bottle Set (195532-1), Prefilter Set (195945-6), Ring Set (196588-7), Spark Plug (168652-4), Starter Rope (444040-2), Dust Bag (166106-5)
Automatic
Decompression
Reduces
Required Start
Up Force
By 40%
Shown With Blade,
Sold Separately
14˝ Cutting Wheel
Compliant with CARB Tier 3, EPA Phase 2 and EU Stage 2 Regulations
• NEW Scavenging Losses Rejection (SLR) Muffler recycles exhaust unburnt gas emissions for increased operational efficiency and cleaner emissions
• Advanced 5 Stage Air Filtration System for cleaner operation and enhanced operational life
• Reversible Cutting Arm enables cutting disc to be side or centre mounted for optimal operational versatility in a variety of applications
• Electronic Ignition with rev limiter
• Always use with 2 Cycle Synthetic Oil
SPECIFICATIONS
Displacement
4.5 cu.in (73 cc)
Maximum Power
3.8 kW (5.1 H.P.)
Fuel / Oil Mixture
50:1
Ignition System
Electronic
Fuel Tank Capacity
1/3 Gal (1.1 L)
No Load Speed (Engine)
9,400 RPM
Maximum Spindle Speed
4,300 RPM
Maximum Cutting Depth
4-13/16˝ (122 mm)
Dry Weight
22.5 lbs. (10.2 kg)
Arbor:
EK7301HD
1˝ (25.4 mm)
EK7301
20 mm
EK7301HD
1˝ Arbor,
EK7301
20 mm Arbor
14˝ / 5.1 H.P. 2 Stroke Power Cutters
STANDARD EQUIPMENT INCLUDES:
EK7301HD:
14˝ Cutting Disk For Stone 1˝ (966 144 120),Tool Kit (957 004 006), WaterAttachment Kit (394 365 630)
EK7301:
14˝ Cutting Disk For Stone (20 mm) (966 141 120),Tool Kit (957 004 006), WaterAttachment Kit (394 365 630)
Top Mount
Decompression
Valve Reduces
Required Start Up
Force by 70%
Required to use
2 Cycle Synthetic Oil
(Part No. T-00739C)
