Electric
Power Tools
makita.ca
131
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
1/4˝ Quick Coupler, (10TT-8),Air Filter (171006), Compressor Oil (0.3L) (181122-A)
Low Noise At Only 79 db
• Oil lubricated for cooler operation and reduced noise
• High output cast iron pump delivers maximum performance and operational life
• Big Bore
TM
cylinder and piston feature high output at lower RPM with reduced heat buildup, less noise
and longer operational life
• Low amperage draw reduces incidents of tripped breakers and voltage drops that cause
premature motor failure
• Easy view oil gauge and large pressure gauges for quick identification
• Air pressure regulator enables easy adjustment of line pressure
• Features 2 quick connect air hose fittings
• Finned discharge tube promotes safe and efficient cooling
Oil Lubricated
2.5 H.P. Air Compressor
SPECIFICATIONS
Motor
2.5 H.P.
Pump
Oil-Lubricated
Tank
2 x 2.1 Gallon
Performance (90 PSI)
4.2 CFM
AMPS (120 V)
12.3 A
Dimensions (L x W x H)
20-1/2˝ x 19-5/8˝ x 20-7/8˝
(520 mm x 497 mm x 530 mm)
Maximum Pressure
130 PSI
Net Weight
77.0 lbs. (34.9 kg)
MAC2400
STANDARD EQUIPMENT INCLUDES:
7˝ D.C.W. 24 Grit (741413-B), Wheel Guard (122767-1), Side Handle (152539-0), Inner Flange (224317-9), Lock Nut (224568-4),
Lock Nut Wrench (782412-6)
INCLUDES:
• 18 Gauge Brad Nailer (AF505)
• 2 H.P. Compressor (MAC700)
• 25 ft. Hose (YYVAH25)
• Air Fitting (YY311018-A), (YY311002-A)
• Quick coupler 1/4˝ (447013)
• Air filter (171002)
• Compressor oil (0.3L) (181122-A)
Oil Lubricated
2 H.P. Air Compressor And Brad Nailer Kit
SPECIFICATIONS
(MAC700) Motor
2.0 H.P.
Pump
Oil-Lubricated
Tank
2.6 gal ( 9.8 L)
Performance (90 PSI)
3.3 CFM
AMPS (120V)
12.4 A
Dimensions (L x W x H)
19-5/16˝ x 12-1/8˝ x 24-1/8˝
(491 mm x 310 mm x 615 mm)
Maximum Pressure
130 PSI
Net Weight
52.0 lbs. (23.6 kg)
MAC700-KIT3
STANDARD EQUIPMENT INCLUDES:
1/4˝ Quick Coupler, (10TT-8),Air Filter (171002), Compressor Oil (0.3 L) (181122-A)
Low Noise At Only 80 db
• Oil lubricated for cooler operation and reduced noise
• High output cast iron pump delivers maximum performance and operational life
• Big Bore
TM
cylinder and piston feature high output at lower RPM with reduced heat buildup,
less noise and longer operational life
• Low amperage draw reduces incidents of tripped breakers and voltage drops that cause
premature motor failure
• Easy view oil gauge and large pressure gauges for quick identification
• Air pressure regulator enables easy easy adjustment of line pressure
• Features 1 quick connect air hose fitting
• Finned discharge tube promotes safe and efficient cooling
Oil Lubricated
2 H.P. Air Compressor
SPECIFICATIONS
Motor
2.0 H.P.
Pump
Oil-Lubricated
Tank
2.6 gal ( 9.8 L)
Performance (90 PSI)
3.3 CFM
AMPS (120 V)
12.4 A
Dimensions (L x W x H)
19-5/16˝ x 12-1/8˝ x 24-1/8˝
(493 mm x 310 mm x 615 mm)
Maximum Pressure
130 PSI
Net Weight
52.0 lbs. (23.6 kg)
MAC700
STANDARD EQUIPMENT INCLUDES:
1/4˝ Quick Coupler (447013)
Ultra-Compact and Lightweight Design Ideal For Trim, Cabinetry,
Hobby and DIY Applications
• Oil-less design requires no day to day maintenance
• Integrated roll cage design protects motor, tank and switch from damage during storage,
transport and operation
• Low noise level suitable for interior use
• Large pressure gauges for quick identification on the jobsite
• Air pressure regulator enables easy adjustment of line pressure
• Features 1 quick connect air hose fitting
1 H.P. Peak Air Compressor
SPECIFICATIONS
Motor
1.0 H.P. (Peak)
Pump
Oil-free
Tank
1.0 gal ( 4.0L )
Performance (90 PSI)
0.45 CFM
AMPS (120V)
1.8 A
Dimensions (L x W x H, with Handle Folded)
13˝ x 15˝ x 11-1/2˝
(330 mm x 381 mm x 292 mm)
Maximum Pressure
125 PSI
Net Weight
23.1 lbs (10.5 kg)
AC001
Oil-less
STANDARD EQUIPMENT INCLUDES:
Oil Supply 30cc (181434-7), Safety Goggles (195246-2)
28° Round Head Framing Strip Nailer
• Large capacity air chamber for increased power
• 2 Mode - Sequential & Bump
• Depth setting knob for adjustment of nailing depth
• Convenient Collapsible Rafter Hook
• Nose piece with sure-grip spikes prevents slipping
Uses 28° Round Head Framing Nails
3-1/2˝ Framing Nailer
SPECIFICATIONS
Nail Type 0.113˝ - 0.131˝, 28° Round Head
Magazine Capacity
60 - 84 Nails
Operating Air Pressure
70-120 PSIG
Nail Size 2-1/2˝- 3-1/2˝, 28° Round Head
Dimensions (L x W x H)
17-1/2˝ x 4-31/32˝ x 13-11/32˝
(445 mm x 126 mm x 339 mm)
Net Weight
7.0 lbs. (3.2 kg)
AN944
STANDARD EQUIPMENT INCLUDES:
1/4˝ Quick Coupler (10TT-8),Air Filter (171006), Compressor Oil (0.3L) (181122-A)
Designed Especially For Framing Nailers
• Oil lubricated for cooler operation and reduced noise
• High output cast iron pump delivers maximum performance and operational life
• Big Bore
TM
cylinder and piston feature high output at lower RPM with reduced heat buildup, less noise
and longer operational life
• Low amperage draw reduces incidents of tripped breakers and voltage drops that cause
premature motor failure
• Easy view oil gauge and large pressure gauges for quick identification
• Air pressure regulator enables easy adjustment of line pressure
• Features 2 quick connect air hose fittings
Oil Lubricated
3 H.P. Air Compressor
SPECIFICATIONS
Motor
3.0 H.P.
Pump
Oil-Lubricated
Tank
5.2 gal ( 19.7L )
Performance (90 PSI)
6.5 CFM
AMPS (120 V)
13.8 A
Dimensions (L x W x H, with Handle Folded)
30-5/16˝ x 20˝ x 21-13/16˝
(770 mm x 510 mm x 553 mm)
Maximum Pressure
140 PSI
Net Weight
88.0 lbs. (39.9 kg)
MAC5200
