Electric
Power Tools
makita.ca
129
STANDARD EQUIPMENT INCLUDES:
Hook and Loop Backing Pad (743052-5), Hex Wrench (783204-6), Sleeve (262542-4)
Ideally Suited For Professional Polishing Applications
• Variable Speed Dial enables operator to adjust speed based on exact polishing application.
Ideal for maximum control during slow polish applications
• Electronic Speed Control maintains constant speed under load
• Soft Start feature gradually increases speed to eliminate start up shock
• 3 Prong Plug prevents static electricity accumulation
• Lock-On Button enables comfortable continuous operation during periods of prolonged use
• Can be easily converted to a Sander
Electronic Speed Control, Variable Speed
7˝ Electronic Polisher
SPECIFICATIONS
Maximum Capacities:
Sanding Disc
7˝ (180 mm)
Wool or Foam Polishing Pad
7˝ (180 mm)
No Load Speed
0 - 3,000 RPM
AMP (120V)
10.0 A
Spindle Thread
5/8˝-11 UNC
Overall Length
18-1/2˝ (470 mm)
Net Weight
6.6 lbs. (3.0 kg)
9227CZ
STANDARD EQUIPMENT INCLUDES:
Blade Set (135168-4), Shear Head (125354-5), Hex Wrench 5/32˝ (783221-6), Plastic Carrying Case (824780-2)
• Pistol grip design for increased operator comfort and control
• Lightweight cast aluminum gear housing for optimal jobsite durability
• Easily accessible carbon brushes for quick replacement on the jobsite
• Retractable belt clip for operator convenience
• Lock-On button enables comfortable continuous operation during periods of prolonged use
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Variable Speed Trigger Switch For
Controlled Cutting
Fibre Cement Board Shear
SPECIFICATIONS
Max. Capacity:
Cement
5/16˝ (8 mm)
AMPS (120V)
6.5 A
Strokes Per Minute
0 - 2,500 SPM
Overall Length
13-5/8˝ (346 mm)
Net Weight
4.9 lbs. (2.2 kg)
JS8000
STANDARD EQUIPMENT INCLUDES:
Hex Wrench (783215-1), Shear HeadAssembly (125849-8)
• Pistol grip design for comfort and convenience
• Lightweight cast aluminum gear housing for durability
• Retractable belt clip for operator convenience
• Lock-on button for easy continuous operation
• Shear head attachment rotates 360°
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Variable Speed Trigger Switch For
Controlled Cutting Speed
18 ga Straight Shear
SPECIFICATIONS
Maximum Capacities:
Steel
18 ga. (1.3 mm)
Stainless
20 ga. (1.0 mm)
AMPS (120V)
6.5 A
Strokes Per Minute
0 - 2,500 SPM
Overall Length
11-7/8˝ (302 mm)
Net Weight
4.0 lbs. (1.8 kg)
JS1300
STANDARD EQUIPMENT INCLUDES:
HexWrench(783201-2),ShearBladeSet(191383-0)
Fast Cutting Action In Steel And Aluminum With Increased Comfort,
Maneuverability And Control
• Built-in thickness gauge for operator convenience
• Sliding On / Off thumb switch
• 360
°
rotatable shear head
• Small circumference, ergonomic motor housing for increased comfort, maneuverability and control
16 ga Straight Shear
SPECIFICATIONS
Maximum Capacities:
Steel
16 ga. (1.6 mm)
Aluminum
13 ga. (2.5 mm)
AMPS (120V)
3.3 A
Strokes Per Minute
4,000 SPM
Minimum Cutting Radius 1-3/16˝ (30 mm)
Overall Length
10˝ (255 mm)
Net Weight
3.4 lbs (1.6 kg)
JS1602
STANDARD EQUIPMENT INCLUDES:
ShearBladeSet(792287-5),Gauge(762007-1),HexWrench(783202-0),PlasticCarryingCase(821550-0)
For Heavy Duty Cutting In Up To 10 Gauge Mild Steel
• Cuts with no material loss in the kerf as with nibblers
• Replaceable blades offer 4 cutting edges for maximum precision
• Built-in thickness gauge for operator convenience
• Highly visible sight line for precise following of patterns
• Scrap Guide protects tool and operator from sheared material
10 ga Shear
SPECIFICATIONS
Maximum Capacities:
Steel
10 ga. (3.2 mm)
Aluminum
9 ga. (4.0 mm)
AMPS (120V)
6.2 A
Strokes Per Minute
1,600 SPM
Minimum Cutting Radius
2˝ (50 mm)
Overall Length
8-3/8˝ (213 mm)
Net Weight
7.4 lbs (3.4 kg)
JS3201J
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
COLLAPSED CELL SYSTEM (CCS)
FOAM POLISHING PADS
Density Colour Application Diameter
Backing Pad
Part No.
For
Model
Part No.
Soft
Black Finessing
7-1/2"
743052-5 9227CZ
T-01242
Medium White Polishing
T-01236
Hard Yellow Cutting
T-01220
Areas of partially closed
foam cells (CCS)
Independent columns
evenly disperse
compound / polish
from CCS pockets
onto working
surface
