STANDARD EQUIPMENT INCLUDES:
Two 7.2V Li-Ion Batteries
BL7010 (194356-2), Charger (DC10WB),
Plastic Carrying Case (821512-8), Safety Goggles (195246-2), Hex Wrench (783230-5), Spark Plug (162269-5)
Ideal For Installing Drywall Track, Plywood
Sheathing or Plastic Wrap to Concrete
• Utilizes industry
standard fuel cells
• Utilizes 7.2V Li-Ion
Battery BL7010 with
30 minute charging time
• Slim nose design
provides access into
tight spaces including
narrow metal channels as
well as maximum visibility
during operation
1-9/16˝ Cordless Concrete Nailer
SPECIFICATIONS
Battery Type
7.2V (1.0 Ah) Li-Ion
Charging Time
30 Minutes
Battery Life
Approx. 4000 Nails
Fuel Cell Life
Approx. 1200 Nails
Nail Type
Straight / Plastic
Driving Speed
Nails/sec. 2 - 3
Dimensions (L x W x H)
12-3/8˝ x 4-1/4˝ x 15-3/8˝
(315 mm x 108 mm x 390 mm)
Net Weight
7.9 lbs (3.6 kg)
GN01
Makita's First Cordless Concrete Nailer
FUEL POWERED NAILER ACCESSORIES
Contents
Contents
For Model
Part No.
Fuel Cell
Approx. 1,200 nails
per fuel cell
GN01
GN900S 242080-2
Approx. 1,000 nails
er fuel cell
FG01
242090-9
Aerosol
Lubricating
Oil
100 mL
GN900S
FG01
242077-1
Aerosol
Cleaner
500 mL
242075-5
Cleaning
Kit
Includes: Aerosol
Cleaner, Lubricating Oil,
Cleaning Brush, Hex Key,
Cleaning Cloth in Cloth
Carrying Case
194852-0
Superior Power To Weight Ratio Versus 90-130 PSI
• 2 mode - Sequential or Bump Fire
• Limited recoil and operator strain ideal for use over prolonged periods
• Increased drive power ideal for hardwoods or laminated materials
and ensures consistent depth of drive
• Adjustable depth of drive up to 1/4˝ (6.35 mm)
• Recessed mode selector switch eliminates accidental engagement
• Quick adjust, tilting nail tray reduces downtime when loading nails
• Adjustable Exhaust Port for optimal positioning during operation
• Adjustable belt hook for operator convenience
SPECIFICATIONS
Nail Size
1-1/4˝ - 2-1/2˝
(32 mm – 65 mm)
Nail Type
15° Round Head
Wire Collated
.083˝ - .099˝
Plastic Collated
.086˝ - .099˝
Magazine Capacity
200 - 400 Nails
Operating Pressure
140 – 320 PSI
Dimensions (L x W x H)
11-1/8˝ x 5-3/8˝ x 10-7/8˝
(282 mm x 136 mm x 277 mm)
Net Weight
4.2 lbs. (1.9 kg)
+
STANDARD EQUIPMENT INCLUDES:
NoseAdapter (421574-2),
Safety Goggle (195246-2), Oil Supply (194381-3),
Plastic Carrying Case (824490-1)
AN610H
INCLUDES:
High PressureAir Compressor (AC310HX)
2-1/2˝ High Pressure Coil Siding Nailer (AN610H)
High Pressure Hose (B-80014)
AC310HX2
Combo Kit
AN610H, AC310HX2
2-1/2
˝
High Pressure Coil Siding Nailers
Superior Power To Weight
Ratio Versus 90-130 PSI
• 2 mode - Sequential Fire or Lock-Off
• Limited recoil and operator strain ideal for use over prolonged periods
• Increased drive power ideal for hardwoods or laminated materials and ensures
consistent depth of drive
• Adjustable depth of drive up to 3/8˝ (10 mm)
• Recessed mode selector switch eliminates accidental engagement
• One-touch magazine opens quickly and easily for rapid nail loading
• Slim contact arm and vertical magazine enables easy operation in narrow spaces
• Adjustable belt hook for operator convenience
SPECIFICATIONS
Nail Size
3/4˝ - 1˝
(19 mm - 25 mm)
Nail Type
0.099˝ - 0.120˝
Plastic Sheet Collated Concrete Nails
Magazine Capacity
100 Nails
Operating Pressure
170 - 320 PSI
Dimensions (L x W x H)
11-5/8˝ x 5˝ x 11-1/2˝
(295 mm x 128 mm x 291 mm)
Net Weight
4.6 lbs. (2.1 kg)
+
STANDARD EQUIPMENT INCLUDES:
NoseAdapter(424234-5),NoseAdapterB(424237-9),
SafetyGoggles(195246-2),OilSupplySet(194381-3),
PlasticCarryingCase(824792-5)
AN250HC
INCLUDES:
High PressureAir Compressor (AC310HX) 1˝ High Pressure Coil
Concrete Nailer (AN250HC) High Pressure Hose (B-80014)
AC310HX4
Combo Kit
Nails Metal Studs & Track To Concrete
AN250HC, AC310HX4
1
˝
High Pressure Coil Concrete Nailers
HIGH PRESSURE COLLATED CONCRETE PINS
Length Shank
Diameter
Shank /
Thread
Head
Diameter
Notes
Application
Box Qty.
For Model
Part No.
3/4"
0.12"
Stepped
0.25"
High Density Concrete Metal Stud or
Track to
Concrete
1,000
(10 Strips of 100) AN250HC
F-33591
3/4"
0.098"
Spiral
Regular Density
Concrete
F-33562
1"
F-33588
COLLATED CONCRETE PINS
Length Shank Diameter Head Diameter
Grade
Coating
Box Quantity
Part No.
3/4"
0.102"
1/4"
Standard Galvanized
1,000 Pins
(100 Strips of 10)
+ 1 ea. 242080-2
Fuel Cell
196290-2
1"
196291-0
1-1/8"
196292-8
1-3/8"
196293-6
1-9/16"
196294-4
5/8"
0.122"
Premium Mechanical
Zinc Plated
196285-5
3/4"
196286-3
7/8"
196287-1
1"
196288-9
1-1/4"
196289-7
