OPTIMUM™ DIAMOND BLADES
Blade Diameter
Arbor
Rim Type
Wet / Dry
Material Type
Application
Max. RPM For Model(s)
Part No.
16"
1", 20 mm Segmented Rim Wet or Dry
Medium
Cured Concrete, Block, Brick, Masonry 4,800 RPM EK8100
A-94742
14"
1", 20 mm
Turbo Rim
Wet or Dry
Hard
Granite, Ceramic, Stone
5,400 RPM
4114
EK7301 / HD
EK7651H / HD
A-94627
Segmented Rim
Medium
Cured Concrete, Block, Brick, Masonry
A-94736
Medium & Soft (Dual Purpose)
Concrete & Asphalt
T-01270
Soft
Asphalt, Unset Concrete, Sandstone
A-94655
12"
1", 20 mm Segmented Rim Wet or Dry
Medium
Cured Concrete, Block, Brick, Masonry
6,300 RPM 4112H
DPC6430
A-94720
Medium & Soft (Dual Purpose)
Concrete & Asphalt
T-01264
ABRASIVE WHEELS
Wheel Diameter Arbor
Wet / Dry
Application
Max RPM For Model(s)
Part No.
16"
20 mm
Wet / Dry Concrete, Stone, Masonry & Asphalt
4,250
EK8100
966 161 020
Dry
Steel & Ferrous Metals
966 161 050
14"
1"
Wet / Dry Concrete, Stone, Masonry & Asphalt
5,500
EK7301HD
EK7651HD
966 144 120
Dry
Steel & Ferrous Metals
966 144 150
20 mm
Wet / Dry Concrete, Stone, Masonry & Asphalt
5,500
EK7301
EK7651H
966 141 120
Dry
Steel & Ferrous Metals
966 141 150
12"
20 mm
Wet / Dry Concrete, Stone, Masonry & Asphalt
5,400
DPC6430
966 121 120
Dry
Steel & Ferrous Metals
6,400
966 121 150
OPTIMUM™ DIAMOND BLADES
Faster. Longer. Smoother
.
Highest Quality
Diamonds
Superior Quality Steel Core
Optimum Bond Matrix Provides a Faster,
Smoother Cut and Longer Blade Life
Expansion Slots improve cooling
on segmented blades
Laser Welded to
ensure the
strongest joint
possible
OPTIMUM Series
Diamond Blades utilize
the optimum bond matrix
for faster, smoother,
longer blade life
Segmented Rim
Quick Cutting. Ideal for general purpose use in Concrete,
Tile, Brick and Stone. Does not produce as clean a cut as a
Turbo or Continuous Rim Blade.
Turbo Rim
Quick and Clean cutting. The ideal combination of a
Segmented and Continuous Rim. Ideal for all applications
including tile, brick, gypsum, plaster.
