FLASHLIGHTS & BULBS QUICK REFERENCE CHART
Flashlight
LED Circuit Board
Fluorescent Tube
Incandescent Bulb
Model No.
Battery Type
Voltage
Part No.
Part No.
Part No.
BML360
Li-Ion Slide
36V
-
A-95015
-
BML185
18V
-
-
A-90261
LXLM03
18V
GM00001284
-
-
LXLM01
18V
GM00001187
-
-
LXRM01
18V
SE00000109
-
-
LXLM04
14.4V / 18V
GM00001213
-
-
BML184
14.4V / 18V
-
SM00000050
A-94502
BML145
14.4V
-
-
A-90233
LM02
Li-Ion Pod
12V
GM00001243
-
-
ML102
7.2V / 12V
TE00000122
-
-
BML240
Ni-MH Slide
24V
-
-
A-90984
ML902
Ni-Cad or Ni-MH Stick
9.6V
-
-
192545-3
ML702
7.2V
-
-
192242-1
ML183
Ni-Cad or Ni-MH Pod
18V
-
A-90978
-
ML180
18V
-
-
A-90261
ML143
14.4V
-
A-90978
-
ML140
14.4V
-
-
A-90233
ML123
12V
-
A-90978
-
ML120
12V
-
-
A-90233
ML903
9.6V
-
-
192545-3
ML901
9.6V
-
-
192545-3
LITHIUM-ION
makita.ca
32
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
LITHIUM-ION BATTERY CHARGERS
DC18SF
DC18RC
DC18SD
DC18SE
4-Port Li-Ion
Multi Charger
• Charges two 18V Li-Ion Batteries
at once
• Optimum Charging System
• Charges 2 x 18V (3.0Ah) Li-Ion
Batteries in 60 minutes
• Charges 4 x 18V (3.0Ah) Li-Ion
Batteries in 120 minutes
Li-Ion Rapid Charger
• Forced Cooling System
• Charges 18V (3.0 Ah) Li-Ion Battery
in 22 minutes
• Use with ADP04 to charge Ni-MH
and Ni-Cad Pod Batteries!
Li-Ion Standard Charger
• Charges 14.4V - 18V Li-Ion and
Ni-MH Slide Style Batteries
• Charges 18V (3.0 Ah) Li-Ion Battery
BL1830 in 30 minutes
• Digital Power Display indicates
condition of battery and current charge
level (-80%, +80%, 100%)
• Adapters cannot be used with
this charger
Li-Ion Automotive
Charger
• Plugs into 12V Automotive outlets to
enable charging on the go
• Optimum Charging System
• Forced Cooling System
• Charges 18V 3.0Ah Li-Ion Battery
in 60 minutes
• Use with ADP04 to charge Ni-MH and
Ni-Cad Pod Batteries
ML183
• Ideal where wide illumination is required.
• Great for automotive use, camping and hiking
• BATTERY NOT INCLUDED
Fluorescent Flashlight
SPECIFICATIONS
Battery
ML183
18V Ni-Cd / Ni-MH
ML143
14.4V Ni-Cd / Ni-MH
ML123
12V Ni-Cd / Ni-MH
Continuous Use
up to 280 Minutes
Overall Length
16-1/4˝ (441 mm)
Net Weight (no battery)
0.9 lbs. (0.4 kg)
ML123
ML143
ML901
• Ideal where wide illumination is required
• Great for automotive use, camping and hiking
• BATTERY NOT INCLUDED
Fluorescent Flashlight
SPECIFICATIONS
Battery
9.6V Ni-Cd / Ni-MH
Continuous Use
up to 120 Minutes
Overall Length
10˝ (254 mm)
Net Weight (no battery)
0.1 lbs. (0.2 kg)
ML180
• 4 Position Adjustable Head
• BATTERY NOT
INCLUDED
Flashlight
SPECIFICATIONS
Battery
ML180
18V Ni-Cd / Ni-MH
ML140
14.4V Ni-Cd / Ni-MH
ML120
12V Ni-Cd / Ni-MH
ML903
9.6V Ni-Cd / Ni-MH
Continuous Use
up to 270 Minutes
Overall Length
11-5/8˝ (294 mm)
Net Weight
0.7 lbs. (0.3 kg)
ML120
ML140
ML903
OPTIMUM
Charging System
