LITHIUM-ION
makita.ca
28
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
RJ01
STANDARD EQUIPMENT INCLUDES:
RJ01:
Two 12V MAX (1.3Ah) Li-Ion Batteries
BL1014 (195332-9), Charger (DC10WB), 1 Ea. Blade (B-20432, 723063-A-5),
Plastic Carrying Case (824993-5)
RJ01Z:
ToolOnly.BatteriesandChargerSoldSeparately.
1Ea.Blade(B-20432,723063-A-5)
Ultra-Compact and Lightweight Design for Maximum Versatility and Application
• Multi-Position Switch (Tool Handle & Tool Body) with Lock-Off Levers for easier operation,
maximum versatility and operator safety
• Battery Protection System shuts tool off when battery capacity is low
• One-Handed, Fast Tool-Less Blade Changes
• LED Joblight with Pre-Glow feature
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Cordless Reciprocating Saw
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Maximum Cutting Capacities:
Wood
2˝ (50 mm)
Pipe
2˝ (50 mm)
Length of Stroke
1/2˝ (13 mm)
Strokes Per Minute
0 - 3,300 SPM
Overall Length
14˝ (355 mm)
Net Weight
2.6 lbs. (1.2 kg)
RJ01Z
VJ01
STANDARD EQUIPMENT INCLUDES:
VJ01:
Two 12V MAX (1.3Ah) Li-Ion Batteries
BL1014 (195332-9), Charger (DC10WB), 1 Ea. Blade (792529-7),
Hex Wrench 3 (783201-2), Guide Rule (192732-4), Plastic Carrying Case (821508-9)
VJ01Z:
ToolOnly.BatteriesandChargerSoldSeparately.
1Ea.Blade(5pk-792529-7),HexWrench3(783201-2),GuideRule(192732-4)
Compact and Lightweight Design for Maximum Maneuverability
• Variable Speed Trigger Switch
• Battery Protection System shuts tool off when battery capacity is low
• 3 Orbital Settings enable operator to obtain a more aggressive cut
• Blower feature keeps cutting line free of saw dust
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Cordless Jig Saw
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Maximum Cutting Capacities:
Wood
2˝ (50 mm)
Pipe
2˝ (50 mm)
Length of Stroke
1/2˝ (13 mm)
Strokes Per Minute
0 - 3,300 SPM
Overall Length
14˝ (355 mm)
Net Weight
2.6 lbs. (1.2 kg)
VJ01Z
Variable Speed
LC01ZX
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Floor NozzleAssembly (122859-6), Pipe (451244-9), Sash Nozzle (451243-1),
Sash Nozzle Holder (451245-7)
Lightweight & Portable Vacuum Cleaner For Shop, Office Or Home Use
• 2 Stage Nylon and Cloth Filter
• Easy to Empty Dust Canister
• Very Quiet Operation (71 dB)
• On Board Sash Nozzle Storage
• Improved Floor Nozzle Swivel Joint for easier maneuverability
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
600 ml Cordless Vacuum Cleaner
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Capacity
1.3 pints (600 ml)
Air Flow
42.4 CFM
Static Water Lift
7.2˝ (18 mb)
Overall length with straight pipe and nozzle
38˝ (966 mm)
Net Weight
1.5 lbs. (0.7 kg)
3/8˝ Cordless Impact Wrench
STANDARD EQUIPMENT INCLUDES:
WT01:
Two 12V MAX (1.3Ah) Li-Ion Batteries
BL1014 (195332-9), Charger (DC10WB), Plastic Carrying Case (141104-0)
WT01Z:
Tool Only. Batteries and Charger Sold Separately.
Compact, Lightweight Impact Power
• 3/8˝ Square Drive ideal for machine bolts, anchors and industrial fasteners
• LED Job Light with Afterglow feature
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Variable Speed, Reversible
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Square Drive
3/8˝ Square
No Load Speed
0 - 2,300 RPM
Impacts Per Minute
0 - 3,000 IPM
Maximum Torque 1,000 in. lbs. (110 Nm)
Overall Length
6-3/8˝ (163 mm)
Net Weight
2.1 lbs (1.0 kg)
WT01
WT01Z
AD01
STANDARD EQUIPMENT INCLUDES:
AD01:
Two 12V MAX (1.3Ah) Li-Ion Batteries
BL1014 (195332-9), Charger (DC10WB), Drill Chuck (766018-8), Chuck Key (763450-7),
Phillips Bit 2-50(784244-7), Plastic Carrying Case (821556-8)
AD01Z:
Tool Only. Batteries and Charger Sold Separately.
Drill Chuck (766018-8), Chuck Key (763450-7), Phillips Bit 2-50(784244-7)
Compact Design For Optimal Versatility In Confined Spaces
• 2-5/8
˝
Head Height ideal for operation in confined spaces
• Industrial Aluminum gear housing for increased durability
• LED Job Light
• Ergonomic Soft Rubber Grip design with vibration absorption and comfortable operation
3/8˝ Cordless Angle Drill
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Capacities:
Steel
3/8˝ (10 mm)
Wood
1/2˝ (12 mm)
No Load Speed
0 - 800 RPM
Overall Length
11-3/4˝ (298 mm)
Net Weight
2.4 lbs (1.1 kg)
AD01Z
2-5/8˝
Variable Speed, Reversible
DT01
STANDARD EQUIPMENT INCLUDES:
DT01:
Two 12V MAX (1.3Ah) Li-Ion Batteries
BL1014 (195332-9), Charger (DC10WB), Battery Plastic Case (824781-0),
Phillips Bit 2-50 (784244-7), Holster (168467-9), Plastic Carrying Case (824842-6)
DT01Z:
Tool Only. Batteries and Charger Sold Separately.
Phillips Bit 2-50 (784244-7)
Lightweight & Compact With High Operational Efficiency
• LED Job Light with Afterglow feature
• Lightweight and Compact Design
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Variable Speed, Reversible
1/4˝ Cordless Impact Driver
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Hex Shank
1/4˝ Hex
No Load Speed
0 - 2,400 RPM
Impacts Per Minute
0 - 3,000 IPM
Maximum Torque 800 in. lbs. (90 Nm)
Overall Length
6-1/8˝ (155 mm)
Net Weight
2.0 lbs. (0.9 kg)
DT01Z
