DCG180RFEB
DCG180ZB
STANDARD EQUIPMENT INCLUDES:
DCG180RFEB:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3),Charger
(DC18RC),BatteryCover(450128-8),Nozzle,SafetyGoggle(195246-2),ToolBag(831278-2)
DCG180ZB:
ToolOnly.BatteriesandChargerSoldSeparately.
Nozzle,SafetyGoggle(195246-2),ToolBag(831278-2)
Ideal For Quick and Precise
Application of Caulking and Sealants
Accepts Standard 600 ml Cartidges, Sausage Packs
and Bulk Caulking or Sealants
• Anti-drip function eliminates residual pressure on
caulking tube to prevent caulking from escaping
when the trigger is released
• Variable speed dial allows operator to set
maximum dispensing speed while the variable
speed trigger enables fine adjustment for maximum
control and precision in a wide range of applications
• Overload protection feature with warning light
prevents motor burnout caused by overloading
600 ml Cordless Caulking Gun
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Max Pushing Force
1,100 lb (5,000 N)
Compatible Sealant Size:
600 ml Cartridge,
Sausage Pack, Bulk Sealant
Dimensions (L x W x H)
26˝ x 4-1/4˝ x 11-1/8˝
(659 mm x 108 mm x 281 mm)
Net Weight
5.9 lbs (2.7 kg)
DCG180RFE
DCG180Z
STANDARD EQUIPMENT INCLUDES:
DCG180RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3),Charger(DC18RC),BatteryCover(450128-8),
SafetyGoggle(195246-2),ToolBag(831278-2)
DCG180Z:
ToolOnly.BatteriesandChargerSoldSeparately.
SafetyGoggle(195246-2),ToolBag(831278-2)
Ideal For Quick and Precise Application
of Caulking and Sealants
Accepts Standard 300 ml Cartidges
• Anti-drip function eliminates residual pressure on caulking tube
to prevent caulking from escaping when the trigger is released
• Variable speed dial allows operator to set maximum dispensing
speed while the variable speed trigger enables fine adjustment
for maximum control and precision in a wide range of applications
• 360
°
rotating tube tray allows operator to adjust positioning based
on materials or application
• Overload protection feature with warning light prevents motor burnout caused by overloading
300 ml Cordless Caulking Gun
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Max Pushing Force
1,100 lb (5,000 N)
Compatible Sealant Size
300 ml Cartridge
Dimensions (L x W x H)
16-1/4˝ x 4-1/4˝ x 11-1/8˝
(411 mm x 108 mm x 281 mm)
Net Weight
4.8 lbs (2.2 kg)
Anti-Drip Function,
Variable Speed
Anti-Drip Function,
Variable Speed
DPT351RFE
STANDARD EQUIPMENT INCLUDES:
DPT351RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RA), NoseAdaptor (419525-7), Safety Goggles
(195246-2), Hex Wrench (783201-2), Hook (324705-1), Plastic Carrying Case (141134-1)
DPT351F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3), NoseAdaptor (419525-7), Safety Goggles (195246-2),
Hex Wrench (783201-2), Hook (324705-1)
DPT351Z:
Tool Only. Batteries and Charger Sold Separately.
NoseAdaptor (419525-7), Safety Goggles (195246-2),
Hex Wrench (783201-2), Hook (324705-1)
• Double Trigger enables accuracy, precision and prevents accidental firing for increased operator safety
• Anti-Dry Fire Mechanism prevents added wear on drive pin
• On-Board Depth Control for quick and easy adjustment
• LED Job Light illuminates work area
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
23 ga Cordless Pin Nailer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Magazine Capacities
130 nails
Gauge
23 ga
Pin Length
11/16˝, 1˝, 1-3/16˝, 1-3/8˝
Overall Length
9-3/4˝ (249 mm)
Net Weight
4.6 lbs. (2.1 kg)
DPT351F
DPT351Z
DST221RFEX
STANDARD EQUIPMENT INCLUDES:
DST221RFEX:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RA), Safety Goggles (195246-2),
Hook (324705-1), 14˝Tool Bag (821010-X)
DST221F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3), Safety Goggles (195246-2), Hook (324705-1)
DST221Z:
Tool Only. Batteries and Charger Sold Separately.
Safety Goggles (195246-2), Hook (324705-1)
Machined Aluminum Magazine Ensures Smooth Staple Loading And Feeding
• Contact Arm enables bump firing for quick operation
• Depth Control Dial enables precise setting of staple depth
• Belt Clip for operator convenience
• Easy to Repair Construction
• Magazine Window shows quantity of staples remaining
• Ergonomic Soft Rubber grip design for vibration absorption and comfortable operation
Cordless Stapler
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Staple:
Width
3/8˝ (10 mm)
Length 3/8˝ - 7/8˝ (10 mm - 22 mm)
Gauge 1/32˝ x 1/16˝ (0.6 mm x 1.2 mm)
Magazine Capacity:
Pcs. Per Sheet
84
Maximum
98
Overall Length
9-7/8˝ (251 mm)
Net Weight
5.3 lbs. (2.4 kg)
DST221F
DST221Z
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
HexWrench5(783233-9),3-1/2"BIMSawBlade(B-21325),1-1/8"PlungeSawBlade(B-21353),
SandingPad(B-21537),AdapterA(313248-8),AdapterC(313249-6),AccessoryToolBox(821538-0),PlasticCarryingCase(141562-0)
Makita's First Cordless Multi Tool
• Battery Protection System provides Over-Discharge, Temperature and Current Protection
for enhanced performance, battery cycle life and overall battery life
• Accepts standard Oscillating Interface System (OIS) Accessories
• Battery Capacity Warning Light indicates ideal time to recharge battery
• Compact design allows access to restricted work areas
• Soft Start feature gradually increases speed to eliminate start up shock
• Variable Speed Dial enables operator to adjust tool speed based on materials or application
• Sliding Lock-On Switch ideal for operation during periods of prolonged use
• LED Job Light
Cordless Multi Tool
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Strokes Per Minute
6,000 - 21,000 SPM
Oscillation Angle
3.2°
Circumference
7-1/2˝ (190 mm)
Overall Length
12˝ (305 mm)
Net Weight
7.8 lbs. (3.5 kg)
LXMT02ZKX1
SEE PAGES 64-65 FOR
MULTI TOOL ACCESSORIES
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Abrasive Paper 60G (B-21565),Abrasive Paper 120G (B-21593),
Abrasive Paper 240G (B-22931), (1-1/8" Plunge Saw Blade
(B-21353), Sanding Pad (B-21537),AccessoryTool Box (142257-8)
Plastic Carrying Case (821608-5)
Features Tooless Quick Change Accessory Mounting System
• Features toolless quick change accessory mounting system for fast and easy blade
changes on the jobsite
• Battery Protection System provides over-discharge, temperature and current Protection for
enhanced performance, battery cycle life and overall battery life
• Accepts standard Oscillating Interface System (OIS) accessories
• Battery capacity warning light indicates ideal time to recharge battery
• Compact design allows access to restricted work areas
• Soft start feature gradually increases speed to eliminate start up shock
• Variable speed dial enables operator to adjust tool speed based on materials or application
• Sliding lock on switch ideal for operation during periods of prolonged use
• LED job light
Cordless Toolless Multi Tool
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
7/8” (22 mm)
Steel
1/2" (13 mm)
Wood
1-1/16" (26 mm)
Impact Energy
1.9 J (1.4 ft. lbs.)
No Load Speed
0 - 1,100 RPM
Blows Per Minute
0 - 4,000 BPM
Overall Length
16-3/8" (417 mm)
Net Weight
7.7 lbs. (3.5 kg)
DTM51ZKX7
SEE PAGES 64-65 FOR
MULTI TOOL ACCESSORIES
Battery Shown
Not Included
